WFS709TP ProSafe Smart Wireless Switch Software Administration Manual

7-4 Configuring 802.1x Authentication

v1.0, June 2007

In this scenario, the supplicant must be configured for Protected EAP (PEAP), as the WFS709TP

only supports PEAP. PEAP uses Transport Layer Security (TLS) to create an encrypted tunnel.

Within the tunnel, one of the following EAP methods is used:

• EAP-Generic Token Card (GTC): Described in RFC 2284, this EAP method permits the

transfer of unencrypted usernames and passwords from client to server. The main uses for

EAP-GTC are one-time token cards such as SecureID and the use of an LDAP or RADIUS

server as the user authentication server. You can also enable caching of user credentials on the

WFS709TP as a backup to an external authentication server.

• EAP-Microsoft Challenge Authentication Protocol version 2 (MS-CHAPv2): Described in

RFC 2759, this EAP method is widely supported by Microsoft clients. A RADIUS server must

be used as the backend authentication server.

If you are using the WFS709TP’s internal database for user authentication, you need to add the

names and passwords of the users to be authenticated. If you are using an LDAP server for user

authentication, you need to configure the LDAP server on the WFS709TP, and configure user IDs

and passwords. If you are using a RADIUS server for user authentication, you need to configure

the RADIUS server on the WFS709TP.

Configuring 802.1x Authentication

On the WFS709TP, use the following steps to configure a wireless network that uses 802.1x

authentication:

1. Configure the 802.1x RADIUS authentication server.

2. Configure 802.1x authentication. See “802.1x Authentication Page” on page 7-5.

3. Configure the VLANs to which the authenticated users will be assigned. See Chapter 3,

“Configuring Network Parameters”.

Note: You must install a server certificate in the WFS709TP for AAA FastConnect,

as described in “Installing a Server Certificate” on page 13-19.

Note: If you are using EAP-GTC within a PEAP tunnel, you can configure either an

LDAP or a RADIUS server as the authentication server. If you are using AAA

FastConnect, you can use a non-802.1x server or the WFS709TP’s internal

database. See Chapter 6, “Configuring AAA Servers”.
