Table 1-3 describes the Basic Configuration pages in the browser interface.
The following buttons are available on both the Basic and Advanced Configuration pages:
• Apply. Accepts all configuration changes made on the current page.
• Save Configuration (appears in top right corner of the browser interface when the
Configuration tool is selected). Saves all applied configuration changes made during the
current configuration session. Saved settings are retained when the WFS709TP is rebooted or
powered off while unsaved configuration changes are lost.
• Clear. Resets options on current page to the last-applied or saved settings.
• Add. Adds a new item to the current page. Typically a set of relevant configuration fields for
the item to be added is displayed.
• Edit. Allows you to edit the configuration of the selected item.
• Delete. Removes the selected item from the page configuration.
Table 1-3. Configuration Pages (Basic)
Page Description
WLAN These pages allow you to configure an SSID and related WLAN options.
Security These pages allow you to configure the security Profile for Rogue AP detection.
Network These pages allow you to configure ports, VLANs, IP interfaces, and DHCP-
related information.
Management These pages allow you to configure the system clock, SNMP-related
information, and management access.
Access Point Installation
Wizard
This page allows you to discover and configure Light Access Points connected
to the Switch.
Note: By default, clicking Apply does not save the configuration. Once you finish
configuring the switch, always remember to click Save Configuration.
