User's Manual

WFS709TP ProSafe Smart Wireless Switch Software Administration Manual
Configuring Network Parameters 3-7
v1.0, June 2007
1. Navigate to the Configuration > Advanced > Switch > General page on the browser interface
(Figure 3-5).
2. Modify the loopback IP address in the Loopback Interface section on this page as required.
Click Apply to apply this configuration.
3. Navigate to the Maintenance > Switch > Reboot Switch page (Figure 3-6) to reboot the
WFS709TP and apply the change of loopback IP address.
4. Click Continue to save the configuration.
5. When prompted that the changes were written successfully to flash (Figure 3-7), click OK.
The WFS709TP boots up with the changed loopback IP address.
Figure 3-5
Warning: If you are using the loopback IP address to access the browser interface,
changing the loopback IP address will result in loss of connectivity. Use
one of the VLAN interface IP addresses to access the browser interface.
Figure 3-6
Figure 3-7
