WFS709TP ProSafe Smart Wireless Switch Software Administration Manual

4-22 RF Plan

v1.0, June 2007

The Deployed Access Points and Air Monitors table displays information on each of these devices.

• To add a device, click Add Device.

• To delete a device, click Remove Device.

• To select a device, click Choose Devices.

RF Plan Example

This section guides you through the process of creating a building and using RF Plan to populate it

with APs and AMs.

Sample Building

The following planning summary shows the information to be used in this example.

Table 4-2.

Building Dimensions

Height: 100 Width: 100

Number of Floors: 2

User Information

Number of Users: Users per AP: N/A

Radio Types: a,. b, g

Overlap Factor: Medium (150%)

AP Desired Rates

802.11b|g: 48 Mbps 802.11a: 48 Mbps

AM Desired Rates

802.11b|g: 24 802.11a: 24

Don’t Care/Don’t Deploy Areas:

Shipping & Receiving = Don’t Care

Lobby = Don’t Deploy
