Chapter 6
Configuring AAA Servers
You can use an external authentication server or an internal user database to authenticate users who
need to access the wireless network.
This chapter describes how to configure theWFS709TP ProSafe Smart Wireless Switch to
interface with an external Remote Authentication Dial-In User Service (RADIUS) server, and how
to add entries into the internal database.
This chapter describes the following topics:
• “Configuring an External RADIUS Server” on page 6-1
• “Adding Users to the Internal Database” on page 6-3
• “Configuring Authentication Timers” on page 6-4
Configuring an External RADIUS Server
To configure RADIUS authentication servers on the WFS709TP:
1. Collect the following required information for RADIUS server configuration (Table 6-1).
Note: In order for an external authentication server to process requests from the
WFS709TP, you must configure the server to recognize the WFS709TP. Refer to
the vendor documentation for the external authentication server for information on
how to do this.
Table 6-1. RADIUS Server Configuration Information
Parameter Description
Server Name Name of the RADIUS authentication server
IP Address IP address of the authentication serve
Shared Secret Shared secret between the WFS709TP and the authentication server
Authentication Port Authentication port on the server (default is 1812)
Accounting Port Accounting port on the server (default is 1813)
