NTS 54/02 NTS 50/10

•

Linear vibration

•

Resistant against aggressive environmental conditions

•

Nominal frequency from 827 min

-1

to 9.040 min

-1

•

Centrifugal force 32 N to 21.808 N

•

Frequency and amplitude can be adjusted separately

•

Synchronous operation possible (NTS 350 and higher)

•

Available in ATEX version or in stainless steel

Netter Pneumatic Linear Vibrators

Series NTS

NTS 120 NF

Summary of content (4 pages)

PAGE 1
25 • • • • • • • Serving industry with vibration Netter Pneumatic Linear Vibrators Series NTS Linear vibration Resistant against aggressive environmental conditions Nominal frequency from 827 min -1 to 9.040 min -1 Centrifugal force 32 N to 21.
PAGE 2
Netter Pneumatic Linear Vibrators Series NTS Type Housing material Working moment [ cmkg] 2 bar 4 bar 6 bar Nominal frequency [min -1] 2 bar 4 bar 6 bar Centrifugal force [N] 2 bar 4 bar 6 bar Air consumption [ l/min] Noise level [ dB(A) ] NTS 120 HF AL 0,018 0,018 0,018 6.280 7.920 8.960 40 63 81 10 36 68 73 NTS 120 NF AL 0,038 0,046 0,046 3.871 4.510 5.095 32 52 66 7 19 66 72 NTS 180 HF AL 0,035 0,045 0,046 5.520 6.880 9.
PAGE 3
Netter Pneumatic Linear Vibrators Series NTS Type A A1 B C D ØE F G H I K Outlet L Inlet Outlet on side Housing Piston Total Housing [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [kg] [kg] [kg] type NTS 120 HF 97,5 70,0 27,5 SW 21 – M8 11 16,5 34,5 – G1/8 G1/8 – 0,086 0,022 0,108 I NTS 120 NF 125,0 97,5 27,5 SW 21 – M8 11 16,5 48,5 – G1/8 G1/8 – 0,119 0,042 0,161 I NTS 180 HF 108,5 73,0 33,5 SW 27 – M10 10 19,5 35,5 – G1/4 G1
PAGE 4
Netter Pneumatic Linear Vibrators Series NTS Filling of powder products Maintaining material flow Conveying with Netter PowerPack = Compaction of form sand in foundry forms ^ééäáÅ~íáçåë= qÜÉ=éåÉìã~íáÅ=äáåÉ~ê=îáÄê~íçêë==ëÉêáÉë=kqp= ~êÉ= ÉëéÉÅá~ääó= ëìáí~ÄäÉ= Ñçê= ÅçåîÉóáåÖI= Åçãé~ÅíáåÖ= ~åÇ= äççëÉåáåÖ= Äìäâ= ã~íÉêá~äI= ÇìÉ=íç=íÜÉ=ÅçãéäÉíÉäó=äáåÉ~ê=îáÄê~íáçåK= qÜÉó=~êÉ=ìëÉÇ=íç=Éãéíó=Äáåë=~åÇ=~ë=ÇêáîÉë Ñçê=ÅçåîÉóçê=~åÇ=ÇçëáåÖ=íêçìÖÜëK=^=ëéÉÅá~ä= ÑÉ~íìêÉ=çÑ=kqp îáÄê~íçêë=áë=íÜÉ=éçëëáÄáäáíó=çÑ íÜÉ=ëóåÅÜêçå
