Owner manual

The new SECURE LOCK feature of the NL4MM adapter
enables to double lock the NL4FC cable connector on one
side.
The NL4MM LOCKING RING has to be on the back
position as shown.
( UNLOCKED = visible)
Insert the cable connector NL4FC 1 and turn clockwise
st
2 to lock (1 lock).
nd
Slide the NL4MM ring to the LOCK position (2 lock).
Slide the NL4MM ring to UNLOCK position.
To separate the NL4FC: Pull latch 1 and turn
counterclockwise 2 .
Connecting:
Release:
