Slide the boot onto the cable.
Insert wires into the terminals and solder them.
Put chuck onto the cable.
Slide insert and chuck together into the housing.
Finish the installation by turning the bushing onto
the connector.
Prepare cable as shown.
Attention: Pay attention to the guiding key.
A
B
C
E
F
D
A
B
C
D
18 [0.71”]18 [0.71”]
4 [0.16”]4 [0.16”]
E
F
ORDER OF ASSEMBLY
NC FXX¬
bushing chuck insert housing
NC MXX¬
