Data Sheet

1. General description
The 74HC139; 74HCT139 decodes two binary weighted address inputs (nA0, nA1) to four
mutually exclusive outputs (nY
0 to nY3). Each decoder features an enable input (nE).
When nE
is HIGH all outputs are forced HIGH. The enable input can be used as the data
input for a 1-to-4 demultiplexer application. Inputs include clamp diodes. This enables the
use of current limiting resistors to interface inputs to voltages in excess of V
CC
.
2. Features and benefits
 Input levels:
 For 74HC139: CMOS level
 For 74HCT139: TTL level
 Demultiplexing capability
 2 independent 2-to-4 decoders
 Multifunction capability
 Suitable for memory decoding, data routing or code conversion
 Complies with JEDEC standard no. 7A
 Active LOW mutually exclusive outputs
 ESD protection:
 HBM JESD22-A114F exceeds 2000 V
 MM JESD22-A115-A exceeds 200 V
 Multiple package options
 Specified from 40 Cto+85C and from 40 Cto+125C
3. Ordering information
74HC139; 74HCT139
Dual 2-to-4 line decoder/demultiplexer
Rev. 4 — 11 December 2015 Product data sheet
Table 1. Ordering information
Type number Package
Temperature range Name Description Version
74HC139D 40 Cto+125C SO16 plastic small outline package; 16 leads;
body width 3.9 mm
SOT109-1
74 HCT139D
74HC139DB 40 Cto+125C SSOP16 plastic shrink small outline package; 16 leads;
body width 5.3 mm
SOT338-1
74HCT139DB
74HC139PW 40 Cto+125C TSSOP16 plastic thin shrink small outline package;
16 leads; body width 4.4 mm
SOT403-1
74HCT139PW
