User's Manual

Nexxt Solutions – Wireless-N 3G router
65
Then you will go back to the Access Control Rule Management page where the list below will
be displayed.
Go to menu Access Control Host, in order to visualize and set a Host list in the screen,
as shown in figure 10-4 below. The host list is necessary for the Access Control Rule.
Figure 10-3
Figure 10-4 Host settings
To add a new entry, please follow the steps below.
10.1 Host
Click the Add New button.
In the Mode field, select IP Address or MAC Address.
In the Host Description field, create a unique description for the host (e.g. Host_1).
In the MAC Address field, enter the corresponding address.
Click the Save button to complete your settings.
Click the Delete All button to erase all the entries in the table.
Click the Next button to go to the following page, or click the Previous button to return to the
last page.
1.
2.
1.
2.
3.
Host Description - The description of the host, which is unique, is displayed here.
Information - The data about the host is displayed in this field. It can be IP or MAC.
Modify – Use this link edit or delete an existing entry.
If you select an IP Address, the screen shown in figure 10-5 will be opened.
•
•
•
•
