User's Manual

Nexxt Solutions – Wireless-N 3G router

Figure 11-2 Static Routing

Figure 11-3 Add or Modify a Static route entry

To add static routing entries:

11.1 Static Routing

Click the Add new button as shown in ﬁgure 11-3. The following screen will open.

Enter the following data:

There are two submenus under the Advanced routing menu as shown in Figure 11-1: Static

Routing List and System Routing Table. Click any of them, and you will be able to conﬁgure the

corresponding function.

Go to Advanced routing Static routing list, in order to conﬁgure the static route as shown

in the next screen (Figure 11-2). A static route is a pre-determined path that network infor-

mation must travel to reach a speciﬁc host or network.

Destination IP Address - The Destination IP address is the address of the network or host

that you want to assign a static route to.

Subnet mask - The Subnet mask determines which portion of an IP Address is the network

portion, and which portion is the host portion.

Gateway - This is the IP Address of the gateway device that allows for contact between the

router and the network or host.

•
