User's Manual

Nexxt Solutions – Wireless-N 3G router
72
Select Enabled or Disabled for this entry from the Status pull-down list.
Click the Save button to make the entry take effect.
Choose menu Advanced routing System routing table, you can configure the system rout-
ing table in the next screen (shown in Figure 11-4). System routing table views all of the valid
route entries in use.
System Routing Table Destination network - The Destination network is the address of the
network or host to which the static route is assigned.
Subnet mask - The Subnet mask determines which portion of an IP address is the network
portion, and which portion is the host portion.
Gateway - This is the IP address of the gateway device that allows for contact between the
Router and the network or host.
Interface - This interface tells you whether the Destination IP Address is on the LAN & WLAN
(internal wired and wireless networks), the WAN (Internet).
There are two submenus under the Bandwidth control menu as shown in Figure 12-1. Click
on any of these items in order to configure the corresponding function. Below you will find
detailed descriptions for each of these items.
Other configurations for the entries:
Click the Delete all button to erase all entries.
Click the Enable all button to activate all entries
Click the Disabled all button to cancel all entries.
Click the Previous button to view the information in the last screen, click the Next button to
view the information in the following screen.
11.2 System routing table
12. Bandwidth control
Figure 11-4 System routing table
Figure 12-1 Bandwidth control
3.
4.
