Manual

Model MC722MT-2
10/100 FIBER MEDIA CONVERTER
Installation and
Operation Manual
Introduction
The MC722MT‐2 auto‐negotiating Fast Ethernet Media Converter set which is designed to translates between 10/100Base‐TX
copperand100Base‐FXfastEthernetfibercabling.TheMediaConverterenablesyoutoextendthedistanceofyour10/100BaseTX
Ethernetnetworkupto2kilometersoverMulti‐Modefiber.
TheConvertersare
equippedwith[1]duplexSCfiberconnectortransmitdataovertwofibersupto2km.
SixLEDindicatorsarebuiltinforeasymonitoringandsystemdiagnosticsforpower,fiberandUTP,linkandactivity.
MC722MT‐2FiberMediaConverterInstallationDrawing
InstallingtheMC722MT‐2FiberMediaConverters
Refertotheabovediagramwheninstalling.Usebestindustrypracticesandfollowalllocalbuildingcodes.
1)Connectanetworkpatchcablefromthenetworkequipment’sEthernetstothereceiver.
2)ConnectaSingleModefibercablebetweenthetransmitterandthereceiverusingSCfiberconnectors.
3)Connect
anetworkpatchcablefromthetransmitter’sEthernetjacktotheremoteIPdevice(IPcamerainthisexample).
4)Connectthesuppliedpowertransformerstothetransmitterandreceiver.
