Electronic user's guide released subject to "Nokia User's Guides Terms and Conditions, 7th June, 1998" User´s Guide 9355567 Issue 1
DECLARATION OF CONFORMITY We, NOKIA CORPORATION declare under our sole responsibility that the product NAM-2 is in conformity with the provisions of the following Council Directive: 1999/5/EC. A copy of the Declaration of Conformity can be found from http://www.nokia.com/phones/declaration_of_conformity/. Copyright© 2003 Nokia. All rights reserved.
Contents Contents FOR YOUR SAFETY ................................................................................................7 General information............................................................................................10 Stickers in the sales package .................................................................................................................10 Access codes ..........................................................................................................
Writing compound words ....................................................................................................................23 Using traditional text input....................................................................................................................24 4. Phone book (Names) .......................................................................................25 Searching for a name and phone number.........................................................................
Contents Call counters and call timers..............................................................................................................36 Profiles (Menu 3) .......................................................................................................................................37 Settings (Menu 4)......................................................................................................................................38 Tone settings (Menu 4-1) .........................
SIM services (Menu 9)..............................................................................................................................50 6. Battery information.........................................................................................51 Charging and Discharging.......................................................................................................................51 Care and Maintenance ...............................................................................
FOR YOUR SAFETY FOR YOUR SAFETY Read these simple guidelines. Breaking the rules may be dangerous or illegal. Further detailed information is given in this manual. Do not switch on the phone when wireless phone use is prohibited or when it may cause interference or danger. ROAD SAFETY COMES FIRST Do not use a hand-held phone while driving. INTERFERENCE All wireless phones may get interference, which could affect performance. SWITCH OFF IN HOSPITALS Follow any regulations or rules.
ACCESSORIES AND BATTERIES Use only approved accessories and batteries. Do not connect incompatible products. WATER-RESISTANCE Your phone is not water-resistant. Keep it dry. BACKUP COPIES Remember to make backup copies of all important data. CONNECTING TO OTHER DEVICES When connecting to any other device, read its user's guide for detailed safety instructions. Do not connect incompatible products. CALLING Ensure the phone is switched on and in service.
FOR YOUR SAFETY ■ Network Services The wireless phone described in this guide is approved for use on the EGSM 900 and GSM 1800 networks. Dualband is a network dependent feature. Check with your local service provider if you can subscribe to and use this feature. A number of features included in this guide are called Network Services. These are special services you arrange through your wireless service provider.
General information ■ Stickers in the sales package The stickers contain important information for service and customer support purposes. Keep these stickers in a safe place. Attach the package. sticker to the Club Nokia Invitation Card supplied in the sales Attach the sticker to your warranty card. ■ Access codes • Security code: This code, supplied with the phone, protects your phone against unauthorised use. The preset code is 12345.
General information • PIN2 code: This code is supplied with some SIM cards and is required to access certain services, such as charging unit counters. If you enter the PIN2 code incorrectly three times in succession, PIN2 code blocked appears on the display, and you will be asked for the PUK2 code. Change the security code, PIN code and PIN2 code in Change of access codes in the Security settings menu (see Security settings (Menu 4-7) on page 42).
1. Getting started ■ Inserting a SIM card • Keep all miniature SIM cards out of small children’s reach. • The SIM card and its contacts can easily be damaged by scratches or bending, so be careful when handling, inserting or removing the card. • Before installing the SIM card, make sure that the phone is switched off, disconnected from the charger and then remove the battery. 1. Press the back cover release button (1), open the back cover from the top (2) and remove it. 2.
Getting started 4. Align the gold-coloured connectors on the battery with the corresponding connectors on the phone, and push the opposite end of the battery until it snaps into place (7). 5. Align the bottom of the back cover with the bottom of the phone, press the top of the back cover to lock it into place (8). ■ Charging the battery Do not charge the battery if either of the phone covers have been removed. 1. Connect the lead from the charger to the base of the phone. 2.
■ Switching on or off Warning! Do not switch on the phone when wireless phone use is prohibited or when it may cause interference or danger. Press and hold the key. TIPS ON EFFICIENT OPERATION: Your phone has a built-in antenna. As with any other radio transmitting device, do not touch the antenna unnecessarily when the phone is switched on. Contact with the antenna affects call quality and may cause the phone to operate at a higher power level than otherwise needed.
Getting started 2. Shows the signal intensity of the cellular network at your current location. 3. Shows the battery charge level. 4. Shows the current function of the soft keys. ■ Changing the covers Before changing the cover, always switch off the power and disconnect the phone from the charger or any other device. Always store and use the phone with the covers attached. 1. Press the back cover release button (1), open the back cover from the top (2) and remove it. 2.
3. Insert the keymat into the new front cover (4). 4. Align the top of the front cover to the top of the phone and press the front cover to lock it into place (5). 5. Align the bottom of the back cover to the bottom of the phone and press the top of the back cover to lock it into place (6). Copyright © 2003 Nokia. All rights reserved.
Getting started ■ Inserting a photo into the back cover You can insert an up to 40 mm x 28.5 mm photo into the back cover. Remove the back cover as described above, see Changing the covers on page 15. 1. Lift the rubber photo holder gently from inside of the back cover (1). 2. Insert the photo with its image side facing the transparent window of the cover (2) . 3. Lock the rubber photo holder into its place (3). Copyright © 2003 Nokia. All rights reserved.
2. Call functions ■ Making a call 1. Key in the phone number including the area code. To make international phone calls: Add a "+" by pressing twice, and add the country (or region) code in front of the area code (delete the leading 0 if necessary). Press Clear to delete the digit to the left of the cursor; move the cursor to the desired position by pressing or if necessary. 2. Press to call the number. Press the volume of the earpiece or headset. 3.
Call functions 1. Make a call to the first participant. Key in the phone number or select it from the phone book and press Call. 2. To make a call to a new participant, press Options, and select New call. 3. When the new call has been answered, add it to the conference call by pressing Options and selecting Conference. 4. To add a another new participant to the call, repeat steps 1 to 3. 5. To end the conference call, press .
■ Answering a call In standby mode, press answering, press . . To end the call or to reject the call without ■ Listening to voice messages Voice mailbox is a Network Service. For more information and for the voice mailbox number, contact your service provider. To call your voice mailbox, press and hold in standby mode. To change the voice mailbox number, see Voice mailbox number (Menu 01-12) on page 35. To divert calls to your voice mailbox, refer to "Call divert" on page 38.
Call functions ■ Locking the keypad The keypad lock prevents keys from being pressed accidentally. To lock or unlock the keypad: In standby mode, press Menu and then quickly. You can also set the phone to automatically turn on the keylock after a certain period of time. Refer to Keyguard settings (Menu 4-5) on page 41. When the keypad is locked, the indicator is shown on the display. Note: When keypad is locked, calls may be possible to the emergency number programmed into your phone (e.g.
3. Writing text You can key in text in two different ways, using the traditional text input, indicated with , or another method called predictive text input indicated with . ■ Setting predictive text input on or off When writing text, press Options and select Dictionary. • To set the predictive text input on, select a language in the dictionary options list. Predictive text input is only available for the languages on the list. • To change back to the traditional text input, select Dictionary off.
Writing text • To delete the character to the left of the cursor, press Clear. To clear the screen, press and hold this key. • To switch between upper and lower cases, or between traditional and predictive text input, press repeatedly and check the indicator at the top of the display. • To switch between letters and numbers, press and hold • To get some punctuation marks, press . repeatedly. • To get a list of special characters, press and hold you want, and press Use.
■ Using traditional text input Press the key marked with the letter that you want repeatedly until the letter appears. Use the following functions to edit the text: • To add a space, press . • To add a punctuation mark or special character, press press , select the desired character, and press Use. • To move the cursor left or right, press or repeatedly, or , respectively. • To delete the character to the left of the cursor, press Clear. To clear the screen, press and hold this key.
Phone book (Names) 4. Phone book (Names) You can save names and phone numbers in the phone´s memory (internal phone book) and in the SIM card´s memory (SIM phone book). The internal phone book can store up to 100 names. To access the phone book, press Names in standby mode. To access the phone book during a call, press Options and select Phone book. ■ Searching for a name and phone number In standby mode, press Names and select Search.
• Info numbers to call the information numbers of your service provider if the numbers are included on your SIM card. (network service). • Add name to save names and phone numbers in the phone book. • Delete to delete names and phone numbers from the phone book one by one or all at once. • Copy to copy names and phone numbers all at once or one by one from the phone´s memory to the SIM card´s memory, or vice versa.
Menu functions 5. Menu functions You can use the key features in the menus in the following ways: By scrolling 1. Press Menu in standby mode. 2. Press or to scroll to the main menu you want, and press Select to enter it. Press Exit to exit a main menu. 3. If the menu contains submenus, scroll to the one you want and press Select to enter it. Press Back to exit a submenu. If you do not want to save the changes you made to menu settings, press or press and hold Back.
Menu functions ■ List of menu functions 1. Messages 1. Write message 2. Inbox 3. Outbox 4. Chat 5. Picture messages 6. Distribution lists 7. Templates 8. Smileys 9. Delete messages 10.Message settings 11. Info service 12. Voice mailbox number 1 13. Service command editor 2. Call register 1. Missed calls 2. Received calls 3. Dialled numbers 4. Delete recent call lists 5. Call duration 6. Call costs 7. Call cost settings 8. Prepaid credit 3. Profiles 1. General 2. Silent 3. Discreet 4. Loud 5. My style 6.
Menu functions 4. Settings 1. Tone settings 2. Call settings 3. Phone settings 4. Time and date settings 5. Keyguard settings 6. Accessory settings 7. Security settings 8. Restore factory settings 5. Alarm clock 2. View all 3. Delete 7. Games 8. Extras 1. Calculator 2. Stopwatch 3. Countdown timer 4. Picture editor 5. Composer 9. SIM services 1 6. Reminders 1. Add new 1. The availability, name and contents depend on the SIM card used. Copyright © 2003 Nokia. All rights reserved.
■ Messages (Menu 01) Write messages (Menu 01-1) You can write and send multi-part text messages (network service). Invoicing is based upon how many ordinary messages are needed for any multi-part message. If you use special (Unicode) characters, more parts may be needed for the message than otherwise. Note that predictive text input may use Unicode characters. To send a message, the phone number of your message centre has to be saved in the phone. See Message settings (Menu 01-10) on page 34. 1.
Menu functions Note: When sending messages via the SMS network service, your phone may display the words "Message sent". This is an indication that the message has been sent by your phone to the message centre number programmed into your phone. This is not an indication that the message has been received at the intended destination. For more details about SMS services, check with your service provider.
Chat (Menu 01-4) You can have a conversation with other people using this faster text message service. To start a chat, press Menu, select Messages and Chat, or select Options and Chat when reading a received text message. 1. Key in the other person’s phone number or recall it from the phone book, and press OK. 2. Key in your nickname for the chat, and press Back. 3. Key in your message, press Options, and select Send. 4. The reply from the other person is displayed above the message you sent.
Menu functions When you receive a picture message To view the message immediately, press View. You can save the message in the folder by pressing Save or delete it by pressing Back and Exit. Options for a picture message Select a picture message and press View. Press Options and select Forward to send it without editing, Edit picture to edit the picture, Refer to Picture editor (Menu 8-4) on page 48, or select Edit text to edit before sending, or select Preview to view the whole message.
Templates (Menu 01-7) You can view, edit, or erase the preset messages (’templates’) that you can use for writing a message. Smileys (Menu 01-8) You can edit and store the smileys such as ":-)", and use them in compiling messages. Delete messages (Menu 01-9) Press Menu, select Messages and Delete messages. To delete all the read messages in a folder, scroll to the folder and press OK. Then press OK when Delete all read messages from folder? is displayed.
Menu functions Each set has the following settings: Message centre number, Messages sent as, Message validity, and Rename sending profile. You need the message centre number to send text and picture messages. You can obtain this number from your service provider. Common (Menu 01-10-2) 1 The settings in this submenu apply to all text messages that you send, irrespective of the chosen set. The available settings are: Delivery reports, Reply via same centre.
■ Call register (Menu 2) The phone registers the phone numbers of missed, received and dialled calls, and the approximate length and cost of your calls. You can also view and adjust the settings of a prepaid SIM card (network services). The phone registers missed and received calls if it is switched on and within the network’s service area, and if the network supports these functions.
Menu functions • Call cost settings: With Call cost limit you can limit the call costs to the desired amount of charging units or units of currency (network service). With Show costs in you can select the units in which the phone shows the remaining talktime (contact your service provider for charging unit prices). • Prepaid credit: When using a prepaid SIM card, you can make calls only when there are enough credit units on the SIM card (network service).
Tip: To activate a profile quickly in standby mode or during a call: Press the key quickly, scroll to the desired profile, and press OK. ■ Settings (Menu 4) In this menu you can adjust various settings of the phone. You can also reset some menu settings to their default values by choosing Restore factory settings.
Menu functions Select the divert option you want, for example, select Divert if busy to divert the calls when you are on a call or when you reject a call. Several divert options may be active at the same time. When Divert all voice calls is activated, is shown on the display in standby mode. Set the selected option on (Activate) or off (Cancel), check whether the option is activated by selecting Check status, or specify a delay for certain diverts in Set delay (not available for all divert options).
network service. When line 2 is selected, "2" is shown on the display in the standby mode. Phone settings (Menu 4-3) Language: To select the language for the display texts. Cell info display: To set the phone to indicate when it is used in a cellular network based on Micro Cellular Network (MCN) technology (network service). For more information, contact your service provider. Welcome note: You can key in a message which will be shown briefly on the display when the phone is switched on.
Menu functions Date setting (Menu 4-4-2) To set the correct date. If the battery is removed from the phone, you may need to set the date again. Auto update of date & time (Menu 4-4-3) This network service updates the time and date according to the current time zone. Keyguard settings (Menu 4-5) You can set the phone to automatically lock the keypad after a preset time delay, Automatic keyguard, or you can lock the keypad manually by using the security code of your phone, Keyguard code.
Accessory settings (Menu 4-6) Accessory settings menu is shown only if the phone is or has been connected to an accessory such as the headsets or mobile inductive loopset LPS-3 . Press Menu, select Settings and Accessory settings. Select Headset, Handsfree or Loopset. • Select Default profile to select the profile the phone uses when the accessory is connected. • Select Automatic answer to set the phone to automatically answer an incoming call after five seconds.
Menu functions the option on (Activate) or off (Cancel) or check whether a service is activated (Check status). • Fixed dialling: You can restrict your outgoing calls to selected phone numbers (Network Service). • Closed user group: With this network service you can specify a group of people whom you can call and who can call you. • Security level: To set the phone to ask for the security code when a new SIM card is inserted in the phone, Phone, or when you select the phone’s internal phone book, Memory.
■ Alarm clock (Menu 5) You can set the alarm to sound at the time you want just once, or repeatedly, for example every working day. When alarm sounds, you can stop the alarm by pressing Stop. If you press Snooze, the alarm stops and rings again in five minutes. If the alarm sounds for one minute, the alarm will stop and sound again after about five minutes. If the alarm time is reached while the phone is switched off, the phone switches itself on and starts sounding the alarm tone.
Menu functions ■ Games (Menu 7) The phone offers you some games to play. Each game is provided with a brief help text. Note: Your phone must be switched on to use this function. Do not switch on the phone when wireless phone use is prohibited or when it may cause interference or danger. Adjusting common game settings Select Settings . You can set the sounds, lights, and vibrations (Shakes) for the game.
To access this menu: Press Menu in standby mode, and select Extras and Calculator. Making a calculation • The keys to insert a digit. inserts a decimal point. Press Clear to delete the last digit. To change the sign, press Options and select Change sign. • Press once for "+", twice for "-", three times for "*" and four times for "/". • To get the result, press Options and select Equals. Press and hold Clear to clear the display for a new calculation.
Menu functions Recording split or lap times Select Split timing or Lap timing, and press Start. Press Split to record a split time, Lap to record a lap time or Stop to finish timing. You can scroll through the recorded times shown below the overall time. When the timing is stopped, you can press Options for Start (split times only), Save, or Reset. If you select Start, timing continues from the previously timed event. If you select Reset, the split or lap times are reset.
Picture editor (Menu 8-4) You can create new pictures or modify existing pictures and save them in the phone. In standby mode, press Menu, select Extras, and Picture Editor. Select Create new to draw a new picture, or Edit existing to modify an existing picture. You can also edit pictures in the Picture messages menu by selecting Edit picture from the options list. Select the picture format: Picture msg. or Clip-art. Draw the picture.
Menu functions Drawing options Press Options while drawing, to view the following options in addition to the pen state: Colour, Insert, Fill, Clear all, Invert colours, Save as, Save, Exit and Undo. Select • Colour: to change the colour of the line you are drawing. The options are Black, White or Dotted. You can quickly change the colour by pressing • Insert: to insert a line, a rectangle, a circle, text or clip art in your picture. Select the option you want and press Insert.
■ SIM services (Menu 9) This menu is shown only if your SIM card provides additional services. The name and contents of this menu depend on the services available. Note: For availability, rates and information on using SIM services, contact your SIM card vendor, e.g. network operator, service provider or other vendor. Copyright © 2003 Nokia. All rights reserved.
Battery information 6. Battery information ■ Charging and Discharging Your phone is powered by a rechargeable battery. Note that a new battery's full performance is achieved only after two or three complete charge and discharge cycles! The battery can be charged and discharged hundreds of times but it will eventually wear out. When the operating time (talk-time and standby time) is noticeably shorter than normal, it is time to buy a new battery.
work, even when the battery is fully charged. Batteries' performance is particularly limited in temperatures well below freezing. Do not dispose of batteries in a fire! Dispose of batteries according to local regulations (e.g. recycling). Do not dispose as household waste. Copyright © 2003 Nokia. All rights reserved.
Care and Maintenance Care and Maintenance Your phone is a product of superior design and craftsmanship and should be treated with care. The suggestions below will help you to fulfil any warranty obligations and to enjoy this product for many years. • Keep the phone and all its parts and accessories out of the reach of small children. • Keep the phone dry. Precipitation, humidity and all types of liquids or moisture can contain minerals that will corrode electronic circuits.
Important Safety Information ■ Traffic Safety Do not use a hand-held telephone while driving a vehicle. Always secure the phone in its holder; do not place the phone on the passenger seat or where it can break loose in a collision or sudden stop. Remember road safety always comes first! ■ Operating environment Remember to follow any special regulations in force in any area and always switch off your phone whenever it is forbidden to use it, or when it may cause interference or danger.
Important Safety Information Pacemakers Pacemaker manufacturers recommend that a minimum separation of 20 cm (6 inches) be maintained between a handheld wireless phone and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with the independent research by and recommendations of Wireless Technology Research.
Vehicles RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles (e.g. electronic fuel injection systems, electronic anti-skid (anti-lock) braking systems, electronic speed control systems, air bag systems). Check with the manufacturer or its representative regarding your vehicle. You should also consult the manufacturer of any equipment that has been added to your vehicle.
Important Safety Information ■ Vehicles Only qualified personnel should service the phone, or install the phone in a vehicle. Faulty installation or service may be dangerous and may invalidate any warranty which may apply to the unit. Check regularly that all wireless phone equipment in your vehicle is mounted and operating properly. Do not store or carry flammable liquids, gases or explosive materials in the same compartment as the phone, its parts or accessories.
Emergency calls may not be possible on all wireless phone networks or when certain network services and/or phone features are in use. Check with local service providers. To make an emergency call: 1. If the phone is not on, switch it on. Check for adequate signal strength. Some networks may require that a valid SIM card is properly inserted in the phone. 2. Press as many times as needed (e.g. to exit a call, to exit a menu, etc.) to clear the display and ready the phone for calls. 3.
Important Safety Information studies. The guidelines include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The exposure standard for mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit stated in the international guidelines is 2.0 W/kg*. Tests for SAR are conducted using standard operating positions with the phone transmitting at its highest certified power level in all tested frequency bands.
3310_en.qxd 12.12.2001 12:35 Page 1 LIMITED MANUFACTURER’S WARRANTY PART OF EUROPE & AFRICA REGION This limited warranty shall apply in part of Nokia Mobile Phones’ Europe & Africa Region unless a local warranty exists. Nokia Corporation, Nokia Mobile Phones (”Nokia”) warrants that this NOKIA product (”Product”) is at the time of its original purchase free of defects in materials, design and workmanship subject to the following terms and conditions: 1.
/ Page 2 / 12.12.2001 12:35 Date of Purchase (dd/mm/yy): / / Product Type (on phone type label under battery): Product Model (on phone type label under battery): Phone Serial No (on phone type label under battery): 3310_en.
