User's Manual

BX5
9
 Remove both comfort cheek pads, left and right, from the helmet (see specific instructions in the
helmet user manual). (Fig. 4)
 Open the visor.
 Remove the rear section of the comfort padding, pulling on the neck roll until it is released from the
shell (see specific instructions in the helmet user manual).Reposition the padding on the outside of
the helmet for the time being. (Fig. 5)
 Remove the chin guard by pulling on the special red tab (Fig. 6a), then remove the plug from the
chin guard. (Fig. 6b)
 Gently remove the polystyrene cheek pads by pulling them upward. (Fig. 7)
Warning: In case the polystyrene cheek pad is damaged during this operation, please contact your
local dealer to replace it.
 In case the helmet is equipped with noise reducers on the comfort padding, lift them up.
 Take the comfort padding, left-hand and right-hand side and, if equipped, cut the pre-drilled tab as
shown in fig. 9 and fig. 10.
Fig. 6b
Fig. 7
Fig. 8
Only for X701 – X603 - X602 helmets :
 Take the polystyrene cheek pads that have
just been removed and, using a pair of
scissors, remove the round insert by cutting
the fabric securing points. (Fig. 8)
 Keep the foam used to cover the speakers
housing in case you wish to use the helmet
without the Bluetooth Kit system.
Fig. 9 helmets X702GT - X701 – X603 Fig. 10 helmets X702
