Configuring options

Selecting date/time format

Several date/time formats are available. Formats are based on the

12-hour and 24-hour clocks. To select a date/time format, press the

Services key and choose Date/Time… from the Telephone Option

menu.

To select date and time:

Enabling OnHook Default Path

The Onhook Default Path option allows you to use a headset or the

Handsfree feature to operate your IP Phone while it is on-hook.To enable

OnHook Default Path, press the Services key and select OnHook

Default Path from the Telephone Option menu.

To enable OnHook Default Path:

1. Press the Up/Down navigation keys to

scroll and highlight the desired format.

Sample formats appear on the upper-

right side of the display area.

2. Choose one of the following:

—Press the Select soft key to save the

format and return to the

Telephone Option menu.

— Press the Cancel soft key to keep

existing configurations.

1. Press the Up/Down navigation keys to

highlight one of the following:

— Handsfree enable

— Headset enable
