Configuring options

To select Display diagnostics:

Choosing local dialpad tone

The local dialpad tone option produces Dual-Tone Multi-Frequency

(DTMF) sounds, a single tone, or no sound when you press a key on the

dialpad. To choose a local dialpad tone, press the Services key and

select Local DialPad Tone from the Telephone Option menu.

To choose a Local DialPad Tone:

1. Press the Up/Down navigation keys to

scroll through the list to view display

capabilities.

2. Press the Cancel soft key to return to

the Telephone Option menu.

1. Press the Up/Down navigation keys to

scroll and highlight one of the following

dialpad tones:

— None to disable all tones.

— Short Click to enable a single tone

for all keys.

— DTMF to turn on a separate DTMF

tone for each key.

2. Choose one of the following:

—Press the Select soft key to save the

tone selection and return to the

Telephone Option menu.

— Press the Cancel soft key to keep

existing configurations.
