Configuring options

Configuring Area Code set-up

The Area Code set-up menu enables a user to save up to 3 area codes.

When an incoming call arrives with an area code that matches one of the

3 stored area codes, the incoming call number is re-ordered to display the

telephone number followed by the area code (as opposed to the area

code followed by the telephone number).

This re-ordering is also performed when a user scrolls through their

Callers List. To configure the area code, press the Services key and

select Call Log Option from the Telephone Option menu.

To configure default area codes (3 maximum):

4. Choose one of the following:

—Press the Select soft key to save the

configuration.

— Press the Cancel soft key to keep

existing configurations.

1. Press the Up/Down navigation keys to

scroll and highlight Area Code Setup.

2. Press the Select soft key.

3. Press the Up/Down navigation keys to

scroll and highlight one of the following:

— Area Code # 1

— Area Code # 2

— Area Code # 3
