Chapter 4
Configuration via the Command Line Interface
E-DOC-CTC-20051017-0169 v0.1
138
4.6.2 Create a New Network Descriptor
add command A new Network Descriptor is created with the ipsec connection network
add
command.
Example In the following example, a new Network descriptor is created, named net1:
The result of this operation can be verified with the
list command.
For the newly created Network Descriptor in this example, all parameters are unset.
Setting of the parameters is described in the next section.
[ipsec]=>
[ipsec]=>connection
[ipsec connection]=>network
[ipsec connection network]=>add
name = net1
:IPSec connection network add name=net1
[ipsec connection network]=>
[ipsec connection network]=>list
[net1] : <unset>
[ipsec connection network]=>
