Chapter 4
Configuration via the Command Line Interface
E-DOC-CTC-20051017-0169 v0.1
152
4.8.1 Config Command
What is it used for This command serves two different purposes. Without additional parameter, the
command displays the current VPN settings. When an additional parameter is
appended, the command controls the setting of this VPN parameter.
Display the VPN
configuration settings
Used without additional parameters, the command displays:
the VPN status
the general behaviour of the SpeedTouch™ as a VPN network node.
In the following example, the VPN software is running, and AutoRoute and
AutoProxyARP are enabled.
Control of general VPN
settings
The following VPN settings are controlled with the config command:
VPN state
AutoRoute
AutoProxyARP
Example In the following example the VPN settings are controlled:
AutoRoute The AutoRoute setting determines whether a route to the remote peer is
automatically injected in the routing table. By default, this option is enabled. When
disabled, routes for the Security Associations have to be added manually in the
routing table. This option is relevant in VPN client/server scenarios.
=>ipsec
[ipsec]=>config
VPN Status : running
VPN client/server : AutoRoute enabled, AutoProxyARP enabled
[ipsec]=>
[ipsec]=>config
state autoroute autoproxyarp
[ipsec]=>:IPSec config autoroute
enabled disabled
[ipsec]=>:IPSec config autoroute enabled
[ipsec]=>
