Chapter 6
Advanced Features
E-DOC-CTC-20051017-0169 v0.1
217
Local selector
[localselector]
The local selector expresses a static IPSec policy for access to the IPSec tunnel at
the local end. This setting can optionally be filled out manually. In a basic
configuration it is left unset. In such a case, the SpeedTouch™ uses its dynamic
policy capabilities to derive a static policy as a result of the Phase 2 negotiation. A
cloned connection is automatically created, with the localselector derived by the
SpeedTouch™.
In an advanced application it may in some cases be useful to manually fill in a static
policy. Entering a symbolic network name in the localselector parameter does this.
Remote selector
[remoteselector]
The remote selector expresses a static IPSec policy for access to the IPSec tunnel at
the remote end. This setting can optionally be filled out manually. In a basic
configuration it is left unset. In such a case, the SpeedTouch™ uses its dynamic
policy capabilities to derive a static policy as a result of the Phase 2 negotiation. A
cloned connection is automatically created, with the remoteselector derived by the
SpeedTouch™.
In an advanced application it may in some cases be useful to manually fill in a static
policy. Entering a symbolic network name in the remoteselector parameter does
this.
Advanced Connection
commands
The following commands are available in the Advanced Connection command
group:
add
modify
delete
list
The functionality of these commands is identical to the commands described in the
basic connection command group. The only difference is the enhanced control over
the parameters in the
modify command.
