MODEL: SFBC940 18 GAUGE 4 IN 1 BRAD NAILER/STAPLER AND FLOORING BRAD NAILER/STAPLER COMBO SFBC940-V1 04/19
MODEL: SFBC940 MODEL: SFBC940 GENERAL SAFETY RULES P3 UNPACKING P6 FEATURES P6 SYMBOLS ● The following signal words and meanings are intended to explain the levels of risk associated with this tool, and can be found in the manual, packaging, labeling, and all other information provided with this tool: SYMBOLS OPERATION ADJUSTING THE EXHAUST P7 CHANGING THE NOSE COVER P7 LOADING FASTENERS P8 UNLOADING FASTENERS P8 CLEARING JAMS P9 SETTING THE AIR PRESSURE P9 DEPTH ADJUSTMENT P9 ADJUSTI
MODEL: SFBC940 Do not use on a ladder or unstable supports. Stable footing on a solid surface enables better control of the tool in unexpected situations. M a k e s u re t h e h o s e i s f re e o f obstructions or snags. Entangled or snarled hoses can cause loss of balance or footing and may become damaged, resulting in possible injury. Do not overreach. Keep proper footing and balance at all times. Proper footing and balance enables better control of the tool in unexpected situations.
MODEL: SFBC940 Such precautionary measures reduce the risk of injury to persons. LOADING TOOL ● Do not load the tool with fasteners when any one of the operating controls is activated. ● Never place a hand or any part of body in fastener discharge area of tool. ● Never point the tool at anyone. ● Do not pull the trigger or depress the workpiece contact as accidental actuation may occur, possibly causing injury.
MODEL: SFBC940 MODEL: SFBC940 LOADING FASTENERS 1. Connect the tool to the air source. 2. Press down on the magazine latch button(F). Pull back on the magazine cover(G). 3. Brad nails: Insert a stick of fasteners into the magazine rail(H). Make sure the pointed ends of the fasteners are resting on the bottom edge of the magazine when loading. Make sure the fasteners are not dirty or damaged. Staples: Load a clip of fasteners with the crowns straddling the magazine rail(H). 4.
MODEL: SFBC940 MODEL: SFBC940 Plastic Screws (K) Adjustment wheel(J) Floor Plate (L) Flush Turn the adjustment knob clockwise ! WARNING: When use the tool as a flooring nailer, the depth adjustment wheel must be set at the top of the wheel bar. To set the wheel: 1.Turn the wheel right to move the wheel up. 2.Set the wheel at the top of the wheel.
MODEL: SFBC940 MODEL: SFBC940 RECOMMENDED HOOKUP CAUTION: The work surface can become damaged by excessive lubrication. Proper lubrication is the owner's responsibility. Failure to lubricate the tool properly will dramatically shorten the life of the tool and void your warranty. CLEANING Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from various types of commercial solvents and may be damaged by their use.
MODEL: SFBC940 MODEL: SFBC940 Repairs or alterations have been made, or attempted, by others, and/or the unauthorized use of non-conforming parts or accessories. Repairs are required due to normal wear and tear. The Nail Gun has been abused, misused, improperly maintained or operated, including: the failure to use clean, dry, regulated compressed air at the recommended pressure; accidents caused by use of the Numax Product after partial failure.
