AL-1950-EDPB / AL-2050-EDPB OLED Color 2-way Alarm & Remote Start July 12, 2012 Operation Guide Temporary cover. Color cover is in a separate file.
Table Of Contents Introduction ������������������������������������������������������������������������������������������������������������������� 3 Controller & Transmitter Overview ������������������������������������������������������������������������������� 4 The 2-Way Controller ����������������������������������������������������������������������������������������������� 4 The Controller Status Screen ����������������������������������������������������������������������������������� 4 The 1-Way Tr
Introduction Congratulations for choosing one of the most versatile, fully-featured vehicle security and convenience systems available today. Omega Research & Development has been a leader in vehicle security products for nearly 4 decades. Please take the time to read this manual thoroughly so you can fully enjoy the benefits and features this system offers.
Controller & Transmitter Overview The 2-Way Controller AL-1950-EDPB Controller part number: 155-03 AL-2050-EDPB Controller part number: 156-03 1 1) Antenna: Sends commands to the system and receives confirmations for 2-way functions. 2) OLED Display: Displays all controller functions as well as the status of your system. 2 3) Backlit Buttons: Flashes while transmitting and indicates battery charging status. 4) Control Buttons: These are the primary use buttons LOCK, UNLOCK, TRUNK, & START.
Controller & Transmitter Overview (cont’d) NOTE: The 2-way Controller is shipped from the factory in POWER OFF mode. If you connect the charger before powering it, perform POWER OFF, then POWER ON again. POWER ON: Press and hold the “P” button for at least 1 second POWER OFF: Press the “P” and “ “ buttons for at least 1 second The 1-Way Transmitter * AL-1950-EDPB part number: 148-03 AL-2050-EDPB part number: 1410-03 Call your dealer or visit www.caralarm.com to order replacement transmitters.
Controller & Transmitter Functions (cont’d) TRUNK RELEASE / CHANNEL 2: Press the “TRUNK” button for 3 seconds. • The system will disarm and the trunk will open (if equipped). • UPON RECEIVING CONFIRMATION FROM YOUR SYSTEM, the controller WILL PLAY the TRUNK RELEASE animation and beep twice (1-way transmitter: press AND hold the trunk button for 3 seconds) * REMOTE START: Press and release the “ ” button twice within 5 seconds.
Controller & Transmitter Functions (cont’d) * CHANNEL 3: Press and hold the “TRUNK” & “ “ buttons for 3 seconds. • YOUR SYSTEM will activate the channel 3 output. • UPON RECEIVING CONFIRMATION FROM YOUR SYSTEM, the controller WILL PLAY the CHANNEL 3 animation. (1-way transmitter: press AND hold the trunk & START buttons for 3 seconds) CHANNEL 4: Press and hold the “LOCK” & “TRUNK” buttons for 3 seconds. • YOUR SYSTEM Will activate the channel 4 output. • There is no 2-way confirmation for this function.
Controller & Transmitter Functions (cont’d) PANIC: Press and hold the “LOCK” or “UNLOCK” button for 3 seconds. • The siren/horn will sound, the parking lights will flash, and the doors will lock or unlock depending which button is pressed. (1-way transmitter: press AND hold the lock or unlock button for 3 seconds) OR SILENT ARM / DISARM: Press and release the “TRUNK” button twice in 5 seconds.
Controller & Transmitter Functions (cont’d) AUXILIARY FUNCTIONS 1-4: The actual operation of these functions will vary from car to car. They are designed to operate extra vehicle functions like automatic sliding doors or motorized hatches. Aux 1-4 are virtual outputs only available on certain vehicles when this system is integrated with the vehicle’s data network. Consult your installer to find out if any of these functions are available for your vehicle.
Other Remote Start Features (cont’d) Pit-Stop Feature This feature allows you to leave your engine running for making quick errands. To use this feature, have the engine running normally from the ignition switch and your foot off the brake pedal. Press the Valet Switch twice; the parking lights will flash and the horn chirps 5 times. Turn the key off and the engine will remain running for the programmed run time.
Security System Features (cont’d) When The System Triggers If the system were to be compromised while armed, it will trigger sounding the siren/horn and flashing the parking lights for 30 seconds (programmable). At this point you will also be notified on the controller as to which zone is violated (if in range of the system). When disarming the system after a trigger event, the siren/horn will chirp 4 times and the parking lights will flash 4 times instead of the standard 2 times.
Using The Valet Switch (cont’d) REMOTE START VALET MODE, while active, disables remote start. Keyless entry and alarm functions are still operable. To enter remote start valet mode, perform the following steps: STEP 1 - Disarm the system either with the controller or by performing an emergency override and hold the brake pedal. STEP 2 - Press and hold the valet switch (located in the window-mount antenna) for 2 seconds. The system will chirp once and the GREEN status light will turn on.
The Status Light (cont’d) AUTOMATIC TRANSMITTER VERIFICATION (RED LIGHT): Every time you turn on the ignition key, the status light will flash a number of times equal to the number of controllers/transmitters programmed to the system. This unique security feature protects you from a potential thief (valet attendant, mechanic, installer, etc.) from adding their own transmitter without your knowledge and accessing your vehicle and it’s contents at a later time (the perfect crime!).
Multi-Car Operation & Vehicle Profiles Multi-car Operation The controller can operate up to 2 different systems. When controlling 2 systems, it will receive all status updates on the currently selected vehicle profile and will receive only trigger alerts for the 2nd vehicle. You can switch from one car to the other at anytime as well as choose a unique image and name for each vehicle. Use the following steps to change vehicle profiles as well as select the vehicle image and name.
Programming Controller Options Each function button on the controller also serves for navigating through the option menus and making changes to the controller options. These secondary functions are indicated by small icons in the upper corners of each button. See below for an explanation of each button’s function. Programming Controls Return To Previous Screen Scroll Up Select Highlighted Option Scroll Down - Press for 3 seconds to access the options menu.
Programming Controller Options (cont’d) Setting The Clock 1) Press the “P” button to access the options menu. 2) Scroll down until “Set Clock” is highlighted 3) Press the 4 button to select. 4) Scroll to highlight either 12 (AM/PM) or 24 hour format. 5) Press the 4 button to select. (the hour is highlighted) 6) Scroll to select the desired hour. 7) Press the 4 button to select. (the hour is highlighted) 6) The hour digits will now be highlighted. Scroll to select the desired hour.
Programming Controller Options (cont’d) Selecting Button Beep With this option turned ON, the controller will beep to confirm each button press. The default setting is OFF. To turn ON/OFF, use the following procedure: 1) Press the “P” button for 3 seconds to access options. 2) Scroll down until “Button Beep” is highlighted 3) Press the 4 button to select. 4) Scroll up or down to highlight the desired setting. 5) Press the 4 button to select.
Anti-Carjacking Protection The system is equipped with two separate Anti-Carjacking protection features (ignition, open door, or both). All are programmable, and must be turned on to operate. Once activated, the user has 53 seconds to cancel the Anti-Carjacking protection process (described below). If Anti-Carjacking is not cancelled, 53 seconds after being activated the siren will begin to chirp for 7 seconds to alert the user that the system is about to enter into an alarm condition.
Programming Controllers/Transmitters (cont’d) Step 3 Press the “lock” button on each transmitter one at a time. The system will chirp the siren/horn once to confirm that each was learned. When programming the 2-way controller, the system’s ID is sent to the controller. Wait for the controller to beep twice, indicating it has learned the system’s ID*. If a code is not received within 10 seconds of Step 2, the learning process will automatically exit.
User Programmable Features Feature #1 - SecureCode DEFAULT - 1 Press SecureCode is a unique patented feature which allows you to custom select the number of Valet Switch presses in two stages, instead of a single “1 press”, which would be required in order to perform an Emergency Override. If any of the three anti-carjacking features are utilized, a customized SecureCode would also be required to turn it off once it is fully activated. The SecureCode operation is described on page 12.
User Programmable Features (cont’d) Feature #5 - Ignition Activated Override Off (press “unlock” button to program) - DEFAULT On (press “lock” button to program) This feature allows an activated system to be overridden and disarmed by simply turning the ignition switch on within 10 seconds of the system’s activation. After 10 seconds, the Emergency Override must be performed.
User Programmable Features (cont’d) Feature #11 - Flashing Light Confirmations On w/ Disarm, Flash w/ RS (press “unlock” button to program) - DEFAULT On w/ Disarm & Remote Start (press “lock” button to program) On During Remote Start (press “trunk” button to program) Flashing During Remote Start (press “start” button to program) This feature affects the parking light confirmations for system disarm & remote start functions.
User Programmable Features (cont’d) Feature #17 - Remote Start Activation Press “start” button 2 times (press “lock” button to program) - DEFAULT Press “start” button 1 time (press “unlock” button to program) Press Lock & Unlock (press “trunk” button to program) This feature changes how the remote start feature is activated using the controller or transmitter.
Installer Programmable Features (cont’d) Feature #3 - Horn Relay Functions Horn Output (press “lock” button to program) - DEFAULT Door Unlock (press “unlock” button to program) Trunk Release (press “trunk” button to program) Pulse After Start (press “start” button to program) The primary function of this second relay, is to operate the vehicle’s existing horn; either in conjunction with the electronic siren, or in place of the siren.
Installer Programmable Features (cont’d) Feature #7 - Starter Cranking Time 0.75 Second (press “lock” button to program) - DEFAULT 1.00 Second (press “unlock” button to program) 1.5 Seconds (press “trunk” button to program) 2.25 Seconds (press “start” button to program) This feature determines the crank time of the 1st start attempt when in “Tachless” mode. If the engine doesn’t start on the first attempt, it will retry up to 3 more times extending the crank time by an additional 0.
Installer Programmable Features (cont’d) Feature #12 Low Temp Crank Extender 0ms (Off) (press “lock” button to program) 200ms (press “unlock” button to program) - DEFAULT 300ms (press “trunk” button to program) 400ms (press “start” button to program) When the vehicle’s interior temperature is below freezing, this feature adds extra crank time to the base timing (see installer feature #7).
Programmable Features Matrix User Feature Programming: Ignition on, off, press valet 5 times # Feature Lock Button 1 Secure Code 1, 0 (default) Unlock button Trunk button 2 Last Door Arming 3 Automatic Rearming ”START” button Off On w/o lock On w/ Lock Off On w/o lock On w/ Lock Enhanced Rearm 4 Starter Interrupt Functions Alarm Anti-Grind Only Alarm+Anti-Grind Automatic 5 Ignition Override On Off 6 Ignition Lock/Unlock Off Lock w/ IGN ON Unlock w/ IGN Off Lock + Unlock w/ IGN On/
