GPS NAVIGATION OPERATION
Enter Navigation Mode
Insert the SD card with pre-installed navigation map into the card slot on the panel of
the product, then press the function button on the panel or click the “ ”icon
(navigation) to enter GPS navigation mode.
Please read the content of Navigation Operation and Settings for details.
Language setting.
Click the “Language setting” button of system setting interface to enter Language setting
interface as shown in the figure.
The system supports Simplified Chinese,Traditional Chinese, English and
multi-languages.End user can select the local national language.
Enter “factory settings” on the top right of version information to choose from multi-
language version.
Steering Wheel Learning
Required Condition:
1)The steering wheel buttons of the product are appropriate for the original car steering
wheel with non-bus control mode.
2)The original car's steering wheel buttons should be voltage input control, that is,when
operating each button, the corresponding inputs of original car audio input different
voltage.
3)Before installation, find out the ground wire, original car steering wheel cables
(Caution: some cars have three wires and others have two) , and the steering wheel
button power supply line (+ 5 v),then connect with the corresponding steering wheel
cables which are supplied together with the product we offered.
(Remarks: After removing the the original car audio host, if the steering wheel buttons
power line still have power, no need to connect power line again. Otherwise,please
connect it with the "+5 V output of our product's steering wheel cables.
Please connect the "keying line 1" as priority when connecting them.If key control works
abnormally,please select "keying line 2" then and reset the steering wheel buttons function
to use.)
Click the “ steering wheel learning” icon on system setting interface to enter steering wheel
buttons setting interface.
- Steering Wheel Control Buttons Setting
Firstly click the steering wheel button which you want to set,as shown on the
figure.When the keypad on the right side is flashing,press the the corresponding button
of steering wheel.When you heard the beep sound,please release the steering wheel
button and finish setting.
After setting is complete, the system will prompt you to learn next function key.Please
operate them step by step till learn all control buttons of original car steering wheel.
After finishing learning all buttons,you can use the original car steering wheel buttons to
control the corresponding function of our product.
RADIO OPERATION
Entry/Exit Radio Operation Mode
Short press the function button on front panel or softly click the “ ”(Radio) icon
