Operation Manual

2-10
2. Printer Settings
Item No.
28
29
30
31
32
33
34
35
Item
Emulation protocol
Sets the emulation protocol that will be used.
Code set selection
When PCL-5c is selected as the emulation
protocol, you can select the code set that
you want to be used.
Pen (1 - 8) settings
When KC-GL is selected, you can set the
parameters of pens (1) - (8). The thickness
and the color of the pens are selectable.
Pen thickness
Sets the thickness of the pen that was
selected under the “Pen (1 - 8)” setting (Item
No.: 30).
Pen color
Sets the color of the pen that was selected
under the “Pen (1 - 8)” setting (Item No.: 30).
Page set
Specifies the original size for the data. The
printer will automatically enlarge/reduce the
data based on the original size that is
specified here and the copy paper size. If
“SPSZ” is selected, the original size that was
designated in the application will be used.
KPDL Error Report print out ON/OFF
Sets whether an Error Report will be
automatically printed out whenever a KPDL
error occurs.
Auto emulation switching
Sets the back-up emulation that, depending
upon the type of data received, may be
switched to for printing out when
“KPDL(AUTO)” is selected under the
“Emulation protocol” setting (item No.: 28).
Display message
Emulation
PCL 5c : Code Set
KC-GL Pen Adjust
Pen Width
Pen Color
(PEN COLOUR)
KC-GL Page set
Print KPDL Errs
Alt. emulation
Available settings
PCL 5c, KC-GL,
KPDL, KPDL
(AUTO)
---
Pen (1) - (8)
1 - 99 dot (s)
Black, Red, Green,
Yellow, Blue,
Magenta, Cyan,
White
A2, A1, A0, B3, B2,
B1, B0, SPSZ
On, Off
PCL 5c, KC-GL
Remarks
Allows you to set a different
emulation protocol for each
interface. Select the desired
interface under the “Interface
selection” setting (Item No.: 11).
