Operation Manual

2-12
2. Printer Settings
Item No.
45
46
47
48
49
50
51
52
Item
Smoothing ON/OFF
Allows you to have the jaggies that appear
around the edge of text or graphics to be
evened out through a smoothing process.
EcoPrint ON/OFF
Allows printing in a toner-saving mode. This
mode is especially suited for test pages, etc.,
where high printing quality is not required.
Tone
Selects between “Normal” and “Fine”.
Gloss mode
When “High” is selected, enables print out
with a glossy finish.
Reading data
Reads the selected data on the Hard disk.
Reading program data
Reads the selected program data on the
Hard disk.
Writing data
If “OK” is selected here, the machine will
enter a “waiting for data” state until data is
sent from the host computer. To exit this
state, select the “GO” command in the
printer mode and then press the Enter key.
Deleting data
Deletes the selected data from the Hard
disk.
Display message
KIR Mode
Ecoprint Mode
Tone
Gloss Mode
Read Data
Read Program
Write Data
Delete Data
Available settings
On, Off
On, Off
Normal, Fine
Low, High
Select the name of
the partition which
holds the data from
among those
displayed.
Select the name of
the partition which
holds the program
from among those
displayed.
OK
Select the name of
the partition which
holds the data from
among those
displayed.
Remarks
For black and white print out only.
For black and white print out only.
If “Low” is selected here, the print
speed will be higher than when
“High” is selected.
Displayed only when there is
appropriate data on the Hard Disk.
Displayed only when there is
appropriate program data on the
Hard Disk.
Only when the optional Hard Disk
is installed.
Displayed only when there is
appropriate data on the Hard Disk.
