BluLoop Multi-LED Light Source Installation and Operation Manual Document Number 000-blulo-110-02-201204 Offices: Ocean Optics, Inc. World Headquarters 830 Douglas Ave., Dunedin, FL, USA 34698 Phone 727.733.2447 Fax 727.733.3962 8 a.m.– 8 p.m. (Mon-Thu), 8 a.m.– 6 p.m. (Fri) EST E-mail: Info@OceanOptics.com (General sales inquiries) Orders@OceanOptics.com (Questions about orders) TechSupport@OceanOptics.
Additional Offices: Ocean Optics Asia 666 Gubei Road, Kirin Tower, Suite 601B, Changning District, Shanghai, PRC. 200336 Phone 86.21.5206.8686 Fax 86.21.5206.8686 E-Mail Sun.Ling@OceanOptics.com Ocean Optics EMEA Sales and Support Center Geograaf 24, 6921 EW DUIVEN, The Netherlands Phone 31-26-3190500 Fax 31-26-3190505 E-Mail Info@OceanOptics.eu Copyright © 2012 Ocean Optics, Inc. All rights reserved.
Important Safety Notices 1. Read this manual before you attempt to use this instrument. 2. Do not remove or modify any installed safety device on this equipment. Doing so will void your warranty and create an unsafe operating environment. 3. Dangerous voltages are present in this device. There are NO user serviceable parts inside. 4. Only allow qualified personnel to service this unit. 5. Before using the optical tool for the first time check for transport damage.
Important Safety Notices B 000-blulo-110-02-201204
Table of Contents About This Manual .......................................................................................................... iii Document Purpose and Intended Audience.............................................................................. iii Document Summary.................................................................................................................. iii Product-Related Documentation ...............................................................................
Table of Contents ii 000-blulo-110-02-201204
About This Manual Document Purpose and Intended Audience This document provides you with an installation section to get your light source up and running. Document Summary Chapter Description Chapter 1: Setup Contains a list of package contents and unpacking instructions. Chapter 2: BluLoop Light Source Specifications Contains a spectral output graph as well as product specifications.
About This Manual iv 000-blulo-110-02-201204
Chapter 1 Setup Overview The BluLoop BluLoop Multi-LED Light Source offers four LEDs combined into a single light source to improve spectral shaping relative to tungsten-halogen light sources. BluLoop offers good, balanced spectral output in the VIS range and is great for color measurements. Unpacking the BluLoop The following sections provide instructions on unpacking and setting up your BluLoop Multi-LED Light Source. Before using the BluLoop light source for the first time, check for transport damage.
1: Setup 2. Inspect the outside of the instrument and make sure that there is no damage. Do not use the instrument if damage is present. 3. Switch on the unit and check if the light source including the fan is working. WARNINGS Do not stare into the source of the light beam. Handle the product with care. Do not let any objects or liquids enter into the device or in the optical path of the light source. 4. Use this instrument in a clean laboratory environment.
1: Setup 2. Slide the SMA holder to the desired position. 3. After setting the right intensity, tighten the stud screw. The system is set to maximum intensity at factory measured with a 1000 µm fiber.
1: Setup 4 000-blulo-110-02-201204
Chapter 2 BluLoop Light Source Specifications Overview This section provides information on the spectral output and the operating environment of the BluLoop light source. Spectral Output The following graph shows a spectral output of a BluLoop measured with a QE65000 spectrometer. Because the output is a combination of four LEDs the output can be manipulated by driving the single LEDs at different currents. The spectral distribution is set at the factory and should be similar to the spectrum shown below.
2: BluLoop Specifications Specifications Specification Value Wavelength Range 395 – 750 nm Stability 0.25 % Drift < 0.3 % per hour Time to stabilize 15 min Output to bulb: Blue LED 500 mA Cyan LED 700 mA White 4500 K LED 700 mA White 6500 K LED 700 mA Bulb lifetime > 10,000 h Characteristic focused Room Temperature 5 -- 35 °C Humidity 5 -- 95 % at 40 °C Lamp Power up to 12 W Weight 0.5 kg Size (HxLxD) 62 mm x 60 mm x 150 mm Spare Parts There are no spare parts available.
