MULTIFUNCTIONAL DIGITAL COLOR SYSTEMS Quick Start Guide ES9460 MFP ES9470 MFP CX3535 MFP CX4545 MFP
Lineup of Our Manuals Some of these manuals are printouts and others are PDF files recorded in the User Documentation CD-ROM. In the printouts, precautions and basic operations are described. Be sure to read “Safety Information” before using the equipment. In the PDF files, detailed copying functions and other settings are described. Select and read those best suited to your needs. Printouts Safety Information This Safety Information describes the necessary precautions for use.
PDF files Copying Guide TopAccess Guide This Copying Guide describes the operations and settings enabled with the [COPY] button on the control panel. This TopAccess Guide describes procedures for remote setup and management from a web-based utility, “TopAccess”. This “TopAccess” web utility enables you to manage the equipment using the browser on your computer.
How to Read This Manual Symbols in this manual In this manual, some important items are described with the symbols shown below. Be sure to read these items before using this equipment. Indicates a potentially hazardous situation which, if not avoided, could result in death, serious injury, or serious damage, or fire in the equipment or surrounding objects.
CONTENTS How to Read This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Recommended toner cartridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Chapter 1 PREPARATIONS Description of Each Component . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended toner cartridges To assure optimal printing performance, we recommend that you use only genuine OKI toner cartridges. If you use an OKI-recommended toner cartridge, you can utilize the following three functions of this equipment: • Cartridge detecting function: This function checks if the toner cartridge is correctly installed and notifies you if it is not.
Chapter 1 PREPARATIONS Description of Each Component . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Turning Power ON/OFF. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Placing Paper and Originals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Installing Client Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 1 PREPARATIONS Description of Each Component This section describes the names and operations of the equipment, control panel and touch panel. Front / Right side Back side 1 3 2 4 14 7 8 13 5 12 9 11 1. Reversing Automatic Document Feeder (optional, MR-3022) The stack of originals is scanned one sheet at a time. Both sides of the originals can be scanned. A maximum of 100 sheets (80 g/m2 or 20 lb. Bond) can be placed in one go.
Description of Each Component Left / Inner side 1 5 2 3 4 12 11 Yellow Magenta Cyan Black 1 10 9 6 7 8 1. 7. Platen sheet Use this to hold the original on the original glass to scan it. P.44 “Regular Cleaning” in this manual 2. 3. Control panel Use this to set and operate various types of functions such as copying and fax. P.8 “Control panel” in this manual 5. Toner cartridge When toner runs out, the message appears on the touch panel. Replace the cartridge following the procedure below. P.
Chapter 1 PREPARATIONS Control panel Use the buttons on the control panel for various operations and settings in the equipment. 1 2 4 3 5 6 7 8 9 10 11 12 13 14 23 1. 22 21 20 19 18 17 [e-FILING] button Use this button to access stored image data. 2. [COPY] button Use this button to access the copying function. 3. [MENU] button Use this button to display frequently used templates. 4. 5.
Description of Each Component 20. [FAX] button Use this button to access the Fax / Internet Fax function. 21. [PRINT] button Use this button to access the printing functions such as private printing, in this equipment. 22. [SCAN] button Use this button to access the scanning function. 23. Touch panel Use this panel for the various settings of the copying, scanning and Fax functions. This also displays messages, such as when paper runs out or paper jams occur.
Chapter 1 PREPARATIONS Adjustment of the angle of the control panel Adjusting the angle of the control panel The angle of the control panel is adjustable between 7 and 52 degrees. When changing the angle of the control panel, be careful not to catch your hands in the gap between the equipment and the control panel. This could injure you.
Description of Each Component Touch panel When the power is turned ON, the basic menu for copying functions is displayed on this touch panel. The status of the equipment is also displayed on the touch panel with messages and illustrations. The menu shown at the time of turning the power ON can be changed to one for functions other than copying, for example, Fax function. Contact your service technician or representative for details. 1 2 6 1 5 4 1.
Chapter 1 PREPARATIONS Setting letters The following menu is displayed when the entry of any letter is required for scanning or e-Filing, etc. Use the buttons on the touch panel for letter entry. After entering the letters, press [OK]. The menu will be changed. The following buttons are used for letter entry. [Basic]: Press this to access the basic keys. [Symbol]: Press this to access the symbol keys. [Other]: Press this to access the special keys.
Turning Power ON/OFF Turning Power ON/OFF This section explains how to turn the power ON and OFF as well as the energy saving mode. How to turn the power ON differs between when the MAIN POWER lamp (red) on the control panel is lit and when it is not. Turning the power ON When the MAIN POWER lamp (red) on the control panel does not light: 1 Open the main power switch cover and turn the power ON there. When the MAIN POWER lamp (red) on the control panel lights: • The equipment starts warming-up.
Chapter 1 PREPARATIONS Turning the power OFF (Shutdown) When turning the power of the equipment OFF, be sure to shut it down according to the procedure below. Check the following three points before shutdown. • No jobs should be left in the print job list. • None of the PRINT DATA lamp (green) or the MEMORY RX / LINE lamps (green) should be blinking. (If the equipment is shut down while any of the above lamps is blinking, jobs in progress such as FAX reception will be aborted.
Description of Each Component Saving energy when not in use – energy saving modes – This equipment supports three energy saving modes; the Automatic Energy Save mode, Sleep mode and Super Sleep mode. The table below shows the procedures to switch modes manually and the conditions under which the equipment enters into or recovers from each mode.
Chapter 1 PREPARATIONS Placing Paper and Originals This section explains how to set paper and originals. Incorrect setting causes image skews or paper jams. Follow the procedure below. Placing paper 1 4 2 1 Pull out the drawer and set the end guide so that it matches the paper size. 2 Push in the drawer. 1 Be careful not to catch your fingers when pushing the drawer back. 3 3 2 This could injure you.
Description of Each Component Placing originals Original glass 1 Reversing Automatic Document Feeder (optional) 1 1 Raise the Original Cover (optional) or the Reversing Automatic Document Feeder (optional). 2 Place the original with its face down on the original glass and align it against the left rear corner. 3 Place the originals face up on the original feeder tray. 2 Align the side guides to the original length.
Chapter 1 PREPARATIONS Installing Client Software How to install the client software such as the printer driver from the Client Utilities CD-ROM co-packed with the equipment is described as follows. Recommended installation The recommended client software such as the printer driver can be installed all in one go. 1 Turn the power ON and confirm that “READY” appears on the touch panel. 2 Insert the Client Utilities CD-ROM in the CD-ROM drive of a Windows computer. P.
Description of Each Component 7 When the installation is completed, click [Finish]. • For details of the Client Utilities CD-ROM, see the following page. P.61 “Client Utilities CD-ROM“ in this manual • For details of the recommended installation, refer to the following guide. Software Installation Guide (PDF): “Chapter 2: RECOMMENDED INSTALLATION” 8 1 Click [Exit] and then [Yes] to finish the installation.
Chapter 1 PREPARATIONS 20
Chapter 2 BASIC OPERATION Basic Copying Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Basic Fax Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 Basic Scanning Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 Basic e-Filing Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 Basic Printing Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 2 BASIC OPERATION Basic Copying Operation The basic copying procedures, such as enlargement/reduction copying and duplex copying as well as bypass copying, are as follows. Making copies Press the [COPY] button on the control panel. Place the original(s). Select the copy modes as required. P.17 “Placing originals” in this manual You can switch the color mode. There are 3 color modes as shown below. FULL COLOR: All originals are copied in full color.
Basic Copying Operation Enlargement and reduction copying Selecting finishing mode (sorting) Press [ZOOM]. 1 Select the desired paper size, 2 press [AMS], and then 3 [OK]. 2 1 Press [FINISHING]. When you use the Reversing Automatic Document Feeder (optional), the sorting mode is automatically set. 2 1 Press [SORT] and then 2 [OK]. 1 3 2 Align the originals according to the desired paper size and direction. The size of the originals will be automatically determined.
Chapter 2 BASIC OPERATION Setting duplex copy Setting original mode Press [2-SIDED]. 1 Select the desired duplex mode and then 2 press [OK]. Press [ORIGINAL MODE]. 1 Select the desired original mode and then 2 press [OK]. 1 1 2 2 You can choose from 5 types. For example, the following settings can be made. 1-sided original to 2-sided copy: 2-sided original to 2-sided copy: 24 The selectable original mode differs depending on the color mode.
Basic Copying Operation Density adjustment You can manually adjust the density by or . pressing either To lighten the density, press , to darken it, press . Bypass copying Place paper face down on the bypass tray. 1 Press the button corresponding to the size of paper set on the bypass tray and then 2 [OK]. 2 Press [AUTO] to adjust the density automatically. 1 2 Press [PAPER TYPE] if the type of the paper you placed on the bypass tray is other than plain paper.
Chapter 2 BASIC OPERATION Basic Fax Operation The basic procedures for sending a fax (the FAX Unit is optional), such as specifying fax numbers in the address book or setting the transmission conditions, are as follows. Sending a fax Press the [FAX] button on the control panel. Place the original(s). P.17 “Placing originals” in this manual Key in the fax number of the recipient by pressing [INPUT FAX No.] on the touch panel or the digital keys on the control panel.
Basic Fax Operation Specifying recipients in the address book Specifying recipients one by one Confirming recipients Press [DESTINATION]. The recipient list screen is displayed. 1 Press the [SINGLE] tab to display the list of addresses, and then 2 the recipient’s fax icon. 1 2 2 Specifying recipients in groups 1 Press [GROUP] tab to display the list of the groups, and then 2 the group name. 2 Select the recipient you want to delete, and then press [DELETE].
Chapter 2 BASIC OPERATION Setting the transmission conditions Press [OPTION]. The transmission condition setting screen is displayed. Press or to switch the pages. Canceling reserved transmissions Press [JOB STATUS]. 1 Press [FAX], 2 select the reserved transmission you want to delete, and then 3 press [DELETE]. 1 2 3 RESOLUTION: Set the resolution based on the fineness of the original. ORIGINAL SIZE: Set the scan size of the original. 28 After each item is set, press [OK].
Basic Fax Operation Checking communication status (log) Registering recipients Press [JOB STATUS]. 1 Select the [LOG] tab and then 2 press [SEND]. Press the [USER FUNCTIONS] button on the control panel and then [ADDRESS] on the touch panel. 1 Press an open button to create a new recipient and then 2 [ENTRY]. 2 1 2 1 Press [RECEIVE] to check the fax reception log. The communication status list is displayed. If [OK] is indicated in the “Status”, the transmission succeeded.
Chapter 2 BASIC OPERATION Basic Scanning Operation How to store the scanned data in a shared folder and store these data in a Windows computer is described as follows. Storing the scanned data in a shared folder Press the [SCAN] button on the control panel. Place the original(s). Press [FILE] on the touch panel. P.17 “Placing originals” in this manual 1 Set [FILE NAME], 2 FILE FORMAT, etc. and then 3 press [OK]. 2 1 30 3 5 Change the scan settings as required.
Basic Scanning Operation To store the scanned data of a shared folder in a Windows computer Start up Windows Explorer. Enter the name of the shared folder, in which the IP address of the equipment and the scanned data are stored, in the address bar with the following format, and then press the [Enter] button. Format: \\[IP address of the equipment] \file_share e.g.) When the IP address of the equipment is 172.16.16.110, enter \\172.16.16.110\file_share in the address bar of Windows Explorer.
Chapter 2 BASIC OPERATION Basic e-Filing Operation e-Filing is a function to store documents in the hard disk of the equipment, they can then be printed as required. Storing documents The originals are stored as e-Filing documents in the equipment. Press the [COPY] button on the control panel. 1 Specify the box to be stored and the document name, and then 2 press [OK]. 1 2 Place the original(s). P.
Basic e-Filing Operation Printing Documents The procedure for printing documents stored in e-Filing is as follows. Press the [e-FILING] button on the control panel. Select the box on the touch panel that contains the document you want to print. 2 1 Select the document you want to print, and then 2 press [PRINT]. Printing starts. 1 2 Selected documents can be previewed in thumbnailed form. Selected documents can be deleted from e-Filing.
Chapter 2 BASIC OPERATION Basic Printing Operation The basic operations of the printer are as follows. This is for printing from a Windows computer with a PCL Printer Driver which needs to be installed in advance. Select [Print] in the [File] menu of the application. 1 Select the printer driver of the equipment, and then 2 click [Preferences] ([Properties]). 1 2 Set the print options as required and click [OK]. Click [Print] ([OK]). Printing starts.
Basic Printing Operation Setting PCL Printer Driver To specify paper size or number of copy sets Click the [Basic] tab in the property dialog box of the printer driver. 2 To specify 2-sided printing or N-up printing Click the [Finishing] tab in the property dialog box of the printer driver. If the Finisher (optional) is installed, “Staple” or “Hole Punch” can be selected. Select “NUMBER OF PAGES PER SHEET” to print several pages on one sheet.
Chapter 2 BASIC OPERATION Basic Menu Operation Press the [MENU] button on the control panel to use templates and check the print counter. When the user management function is enabled, log in and press the [MENU] button on the control panel. The menu screen for a logged in user is displayed. You can register frequently used templates, a group of templates or the shortcut of the External Interface Enabler (GS-1020, optional).
Chapter 3 MAINTENANCE / TROUBLESHOOTING Replacing Toner Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 Replacing Waste Toner Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39 Replacing Staple Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 Regular Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 3 MAINTENANCE / TROUBLESHOOTING Replacing Toner Cartridge When “Install new *** toner cartridge” appears on the touch panel, replace the toner cartridge according to the following procedures. 1 4 2 1 Open the front cover. 2 Y Pull out the seal. Then remove the seal on the toner cartridge board. M 1 C K 5 Y 2 Remove the color toner cartridge you want to replace. Install the new toner cartridge. 3 6 10 Shake the new toner cartridge well to loosen the toner inside.
Replacing Waste Toner Box Replacing Waste Toner Box When “Dispose of used toner” appears on the touch panel, replace the waste toner box according to the following procedures. 1 4 Open the waste toner box cover. Holding the upper section, remove the waste toner box. 2 5 3 Pull out the waste toner box until the opening appears. Set a new waste toner box. 3 6 2 1 Screw the lid on the opening of the waste toner box. Close the waste toner box cover. Never attempt to incinerate waste toner boxes.
Chapter 3 MAINTENANCE / TROUBLESHOOTING Replacing Staple Cartridge When “Check staple cartridge” appears on the touch panel, replace the staple cartridge according to the following procedures. Stapler Unit of Finisher (MJ-1101) 40 1 4 Open the front cover of the Finisher. Install a new staple case into the staple cartridge. 2 5 Take off the staple cartridge. Install the staple cartridge. 3 6 Take the empty staple case out of the staple cartridge. Close the front cover of the Finisher.
Replacing Staple Cartridge Stapler Unit of Saddle Stitch Finisher (MJ-1106) 1 4 Open the front cover of the Finisher. Install a new staple case into the staple cartridge. 2 5 3 Take off the staple cartridge. Install the staple cartridge. 3 6 Take the empty staple case out of the staple cartridge. Close the front cover of the Finisher.
Chapter 3 MAINTENANCE / TROUBLESHOOTING Saddle Stitch Unit of Saddle Stitch Finisher (MJ-1106) 1 4 2 3 1 2 1 Open the front cover of the Finisher, and then pull out the saddle stitch unit. Install a new staple case into the staple cartridge and remove the seal bundling the staples. 2 5 1 1 2 2 2 2 1 1 Take out two empty staple cartridges. Install two new staple cartridges. 3 6 2 1 2 3 1 Take the empty staple case out of the staple cartridge.
Replacing Staple Cartridge Stapler Unit of Hanging Finisher (MJ-1031) 1 4 1 1 2 3 2 2 Push the lever to separate the Hanging Finisher from the equipment, and then open the cover. Press down the transparent cover and pull out the seal. 2 5 3 1 2 2 4 3 Take off the staple cartridge, and then take the empty staple case out of the staple cartridge. Install the staple cartridge. 3 6 1 2 2 Install a new staple case into the staple cartridge.
Chapter 3 MAINTENANCE / TROUBLESHOOTING Regular Cleaning Poor quality printing such as uneven and soiled images can be improved by simple cleaning. This section describes the cleaning methods for the equipment. Cleaning for the scanning area, original glass, guide and platen sheet We recommend you to clean the following items weekly, so that the originals can be scanned in unsoiled conditions. Be careful not to scratch the parts that you are cleaning. • Be careful not to scratch the portions in cleaning.
Troubleshooting Troubleshooting When problems such as paper jams occur, see the following explanation or refer to the Troubleshooting Guide (PDF) according to P.45 “References to the Troubleshooting Guide” in this manual. About Troubleshooting Guide The Troubleshooting Guide (PDF) describes the causes and the troubleshooting of problems when you use the equipment.
Chapter 3 MAINTENANCE / TROUBLESHOOTING Symbols and messages appear on the touch panel Symbols or messages of such as for paper jams occasionally appear on the touch panel.
Troubleshooting Covers of the Finisher, the Hole Punch Unit and the Bridge Unit (all optional) The covers of the Finisher, Hole Punch Unit and Bridge Unit to be opened when paper jams occur are as indicated by the arrows in the following illustrations.
Chapter 4 ADVANCED FUNCTIONS Advanced Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 4 ADVANCED FUNCTIONS Advanced Functions In Chapter 2 in this manual, the basic functions are described. This section describes the advanced functions to help you get the best out of your equipment. Examples of the advanced functions describing in this section Copying different-sized originals and stapling copies (LT) (LD) (LT) (LD) P.51 in this manual P.55 in this manual Copying or scanning originals without blank sheets 1 5 Attaching the scanned data to an Email 3 1 3 6 5 6 P.
Advanced Functions COPY FAX SCAN e-FILING PRINT Copying different-sized originals and stapling copies (LT) 1 (LT) (LD) (LD) Place the originals on the Reversing Automatic Document Feeder. 5 P.17 “Placing originals” in this manual The procedure of how to copy 5 sets of different-sized originals (A4 or LT: 1 sheet, A3 or LD: 4 sheets) and staple the copies is as follows. The Reversing Automatic Document Feeder and the Finisher (optional) are required.
Chapter 4 ADVANCED FUNCTIONS COPY FAX SCAN e-FILING PRINT Copying or scanning originals without blank sheets You can copy or scan originals omitting blank sheets while maintaining the original page sequence. 1 5 3 1 3 6 5 6 When copying 1 Place the originals. 2 Press the [EDIT] tab, and then in the basic menu for the copying functions. 3 Press [OMIT BLANK PAGE] and then [OK]. P.17 “Placing originals” in this manual When scanning 1 Place the originals.
Advanced Functions COPY FAX SCAN e-FILING PRINT Storing data in a shared folder as well as sending a fax You can store documents in a shared folder in the equipment or in a computer connected to the network as well as sending a fax. 1 Place the original(s). 2 Press [STORAGE] on the touch panel. 3 1 Specify details such as the file name, shared folder and file format and then 2 press [OK]. P.17 “Placing originals” in this manual 1 4 4 2 Specify the recipient and press [SEND].
Chapter 4 ADVANCED FUNCTIONS COPY FAX SCAN e-FILING PRINT Registering frequently used scan settings in templates If you register frequently used scan settings in templates, you can easily perform scan operations only by recalling the templates. How to register scan settings (scan data are stored in PDF format in a shared folder) in templates (PUBLIC TEMPLATE GROUP) is described here. 1 Press [FILE] on the touch panel. 6 Press [PASSWORD], enter the administrator password and press [OK].
Advanced Functions COPY FAX SCAN e-FILING PRINT Attaching the scanned data to an E-mail The procedure for attaching the scanned data to an E-mail and sending it to the specified E-mail address is as follows. 1 Place the original(s). 2 Press [E-MAIL] and then [TO] on the touch panel. 3 1 Specify the E-mail address and then 2 press [OK]. P.17 “Placing originals” in this manual 1 2 4 Define the settings for the file as required and then press [OK]. 5 Press [SCAN] on the touch panel.
Chapter 4 ADVANCED FUNCTIONS COPY FAX SCAN e-FILING PRINT Adding date and time to document files The procedure for printing a document file stored in e-Filing with the date and time added at the bottom is as follows. 2011 . 5 . 10 11:11 1 Select the box in which the desired document is stored. 2 1 Select the document and then 2 press [SETTINGS]. 1 2 3 Press [TIME STAMP]. 4 1 Press [LOWER] and then 2 [OK]. 1 2 5 56 Press [PRINT] on the touch panel. Printing starts.
Advanced Functions COPY FAX SCAN e-FILING PRINT Printing a PDF file stored in the USB device The procedure for printing 1 set of a PDF file stored in the USB device is as follows. 1 Connect the USB device to the USB port. 2 Press the [PRINT] button on the control panel. 3 Click the pull-down menu, and then select [USB]. 4 1 Select a PDF file to be printed and 2 press [PRINT]. Printing starts. 4 1 2 • Press [SETTINGS], then you can set such as duplex printing and stapling.
Chapter 4 ADVANCED FUNCTIONS COPY FAX SCAN e-FILING PRINT Printing only allowed data set on the control panel The procedure for printing only allowed data set on the control panel is as follows. This will stop you from forgetting to remove printed sheets. 1 1 2 3 Open a file to be printed on a Windows computer, and then select [Print] from the file menu of the application. Select the printer driver of the equipment, and then click [Preferences] ([Properties]).
Chapter 5 INFORMATION ABOUT EQUIPMENT Items Included in This Product . . . . . . . . . . . . . . . . . . . . . . . . . . . 60 Client Utilities CD-ROM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61 Client Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62 Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64 Logging in . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 5 INFORMATION ABOUT EQUIPMENT Items Included in This Product The following items are co-packed with the equipment. Check that you have them all. Contact your service technician or representative if any are missing or damaged. Items included in this product Safety Information Quick Start Guide (This manual) Client Utilities CD-ROM User Documentation CD-ROM 60 The Safety Information describes the necessary precautions for use. For your added security, be sure to read this booklet first.
Client Utilities CD-ROM Client Utilities CD-ROM The Client Utilities CD-ROM contains the following client software such as the printer drivers and the utility software. Client software For Windows For Macintosh For UNIX/Linux Client Software Installer PCL Printer Driver PS printer driver XPS printer driver TWAIN driver File downloader Fax driver AddressBook Viewer Remote Scan driver WIA driver e-Filing Backup/Restore Utility PPD file for Mac OS X 10.2.4 to Mac OS X 10.3.x PPD file for Mac OS X 10.
Chapter 5 INFORMATION ABOUT EQUIPMENT Client Software This section describes the outlines of the client software of the equipment. It is necessary to install software except e-Filing Web utility and TopAccess in the computer before it is used. Client software for the printing functions PCL printer driver PS printer driver XPS printer driver PPD file for Macintosh UNIX/Linux filter CUPS This PCL Printer Driver is installed with the Recommended Installation. This driver is generally used.
Client Software Client software for the e-Filing functions TWAIN driver File downloader e-Filing Web utility e-Filing Backup/Restore Utility This driver enables you to obtain documents stored in e-Filing as an image in application supporting TWAIN on Windows computers.
Chapter 5 INFORMATION ABOUT EQUIPMENT Options The following options are sold separately, and upgrade the performance of the equipment if installed. For details, contact your service technician or representative. 1 10 7 2 8 3 9 4 1. Original Cover (KA-3511PC) 7. This is used to hold an original. 2. 3. 8. Paper Feed Pedestal (KD-1027) This pedestal enables you to install the Additional Drawer Module (optional, MY-1035). 5.
Options Other options available are as follows. Contact your service technician or representative for details. Work Table (KK-4550) Antenna (GN-3010) This is a small table for placing originals while the equipment is being operated. • Installed on the right-hand side of the equipment. • Cannot be installed with e-BRIDGE ID Gate at the same time. This is used when the Wireless LAN Module or Bluetooth Module is installed.
Chapter 5 INFORMATION ABOUT EQUIPMENT Logging in When the equipment is controlled under department or user management, copying and other functions can be performed if you log in according to the following procedure. Department management You can restrict users or manage copy volumes made by an individual group or department in your company using the department codes. When the equipment is controlled under the department code, turn the power on and enter the code.
Logging in User management You can restrict users or manage available functions and past records by means of user management. When the equipment is managed under this function, turn the power ON and enter the information required (e.g. user name, password). The menu for entering user information also appears when you press the [ACCESS] button on the control panel or automatic function clear has worked. Enter the information according to the procedure below.
Chapter 5 INFORMATION ABOUT EQUIPMENT The menu for user authentication appears. Press [PASSWORD]. Enter the password (maximum 64 letters) and then press [OK]. Press [OK]. 7 The equipment becomes being ready to perform copying and other functions. MFP local authentication Windows Domain authentication, LDAP authentication The domain name previously set by the network administrator is displayed in [DOMAIN].
Specifications of Equipment Specifications of Equipment This section describes the types of acceptable paper, sheet capacity of each feeder and the specifications of the equipment. Acceptable paper Feeder Media type Weight Maximum sheet capacity Paper size 2 Drawers (Including optional drawers) *1 Large Capacity Feeder (optional) 600 sheets (64 g/m , 17 lb. Bond) 550 sheets (80 g/m2, 20 lb. Bond) 500 sheets (81 - 105 g/m2, 24 lb. Bond, 28 lb. Bond) PLAIN, RECYCLED PAPER 64 - 105 g/m2 17 - 28 lb.
Chapter 5 INFORMATION ABOUT EQUIPMENT Paper only acceptable for printing functions Feeder Media type Weight Maximum sheet capacity Paper size 2 PLAIN Bypass tray THICK1 *1 *2 90 - 105 g/m 24 - 28 lb. Bond 106 - 163 g/m2 - 90 lb. Index 1 sheet *1, *2 305 mm x 1200 mm (12.00" x 47.24") Place the sheets one by one on the bypass tray.
Specifications of Equipment ES9460 MFP/ES9470 MFP/CX3535 MFP/CX4545 MFP Specifications Model name Type Original glass Printing (copying) system Developing system Fixing method Photosensor type ES9460 MFP/ES9470 MFP/CX3535 MFP/CX4545 MFP Desktop type Fixed Indirect electrophotographic method 2-component magnetic brush developing Belt fusing OPC Flat surface scanning system Original scanning system (When the Reversing Automatic Document Feeder is installed: Fixed scanning system through feeding the original
Chapter 5 INFORMATION ABOUT EQUIPMENT Specifications of Options This section describes the specifications of the options sold separately. For details other than the specifications, see “Options” in this manual. P.64 Reversing Automatic Document Feeder Model name Copy sides Number of originals (A4 or LT) Feeding speed MR-3022 1-side, Duplex 100 originals (35 - 80 g/m2, 9.3 - 20 lb. Bond) or 16 mm/0.63 or less in height (more than 80 g/m2, 20 lb. Bond) 45 sheets/min.
Specifications of Options Finisher (MJ-1101) Model name Type Acceptable paper size Acceptable paper weight Number of sheets stapled at a time (Including 2 covers (64256 g/m2, 17 lb. Bond to 140 lb. Index)) Stapling position Power source Dimensions Weight Power consumption MJ-1101 Floor type (Console type) A3, A4, A4-R, A5-R, B4, B5, B5-R, FOLIO, 305 mm x 457 mm, LD, LG, LT, LT-R, ST-R, COMP, 8.5SQ, 13LG, 12 x 18, 8K, 16K, 16K-R 64 - 280 g/m2, 17 lb. Bond - 150 lb. Index 64 - 80 g/m2 17 - 20 lb.
Chapter 5 INFORMATION ABOUT EQUIPMENT Saddle Stitch Finisher (MJ-1106) Model name Type Acceptable paper size Acceptable paper weight Number of sheets stapled at a time (including 2 covers (64 256 g/m2, 17 lb. Bond to 140 lb. Index) Stapling position MJ-1106 Floor type (Console type) A3, A4, A4-R, A5-R, B4, B5, B5-R, FOLIO, 305 mm x 457 mm, 320 mm x 450 mm, 320 mm x 460 mm, 330 mm x 483 mm, LD, LG, LT, LT-R, ST-R, COMP, 8.5"SQ, 13"LG, 12" x 18", 13" x 19", 8K, 16K, 16K-R 64 - 280 g/m2 (17 lb.
Specifications of Options Hanging Finisher (MJ-1031) Model name Type Acceptable paper size Acceptable paper weight Number of sheets stapled at a time (Including 2 covers (64 256 g/m2, 17 lb. Bond to 140 lb. Index)) Stapling position Power source Dimensions Weight Power consumption *1 *2 MJ-1031 Hanging-type A3, A4, A4-R, A5-R, B4, B5, B5-R, FOLIO, 305 mm x 457 mm *1, 320 mm x 450 mm *2, 320 mm x 460 mm *2, LD, LG, LT, LT-R, ST-R, COMP, 8.5SQ, 13LG, 12 x 18 *1, 8K, 16K, 16K-R 64 - 280 g/m2, 17 lb.
Chapter 5 INFORMATION ABOUT EQUIPMENT Hole Punch Unit (MJ-6103 Series) Model name Acceptable paper size Acceptable paper weight Dimensions Weight MJ-6103 Series A3, A4, A4-R, B4, B5, B5-R, FOLIO, LD, LG, LT, LT-R, COMP, 8.5SQ, 13LG, 8K, 16K, 16K-R 64 - 256 g/m2, 17 lb. Bond - 140 lb. Index (OHP film and specially treated paper are not available.) 112 mm (4.41) (W) x 573 mm (22.56) (D) x 323 mm (12.72) (H) (excl. Lower cover) Approx. 7 kg (15.4 lb.
INDEX A, B Acceptable paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69 [ACCESS] button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Additional Drawer Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6, 64, 72 Alarm lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Alert message indication area . . . . . . .
OKI CONTACT DETAILS OkicontactName. Oki Systems (UK) Limited OkicontactAddress.550 Dundee Road Slough Trading Estate Slough Berkshire SL1 4LE Tel: +44 (0) 1753 819819 Fax: +44 (0) 1753 819899 http://www.oki.co.uk Oki Systems (Iberica), S.A.U C/Teide, 3 San Sebastian de los Reyes 28703, Madrid Tel: +34 91 3431620 Fax: +34 91-3431624 Atención al cliente: 902 36 00 36 Website: www.oki.es Oki Service Serviço de apoio técnico ao Cliente Tel: 808 200 197 E-mail: okiserv@oki.
AlphaLink Bulgaria Ltd. 2 Kukush Str. %XLOGLQJ ³$QWLP 7RZHU´ À 6R¿D %XOJDULD Oki Systems (Sweden) AB Borgafjordsgatan 7 Box 1191 164 26 Kista tel: +359 2 821 1160 fax: +359 2 821 1193 Website: http://bulgaria.oki.com Tel. +46 (0) 8 634 37 00 e-mail: info@oki.se för allmänna frågor om Oki produkter Oki Data(Australia) Pty Ltd. 146 O’Riordan Street Mascot, NSW 2020, Australia Tel: +61 (02) 9667 7240 Fax: +61 (02) 9667 7333 http://www.oki.com.au support@oki.
©2012 Oki Data Corporation All rights reserved Under the copyright laws, this manual cannot be reproduced in any form without prior written permission of Oki Data.
ES9460 MFP/ES9470 MFP CX3535 MFP/CX4545 MFP
Oki Data Corporation 4-11-22 Shibaura, Minato-ku,Tokyo 108-8551, Japan www.okiprintingsolutions.
