Quick Start Guide

Chapter 5 INFORMATION ABOUT EQUIPMENT
Specications of Options
This section describes the specications of the options sold separately. For details other than the specications, see  P.64
“Options” in this manual.
72
Reversing Automatic Document Feeder
Model name MR-3022
Copy sides 1-side, Duplex
Number of originals
(A4 or LT)
100 originals (35 - 80 g/m
2
, 9.3 - 20 lb. Bond) or 16 mm/0.63 or less in height (more than 80 g/m
2
, 20 lb. Bond)
Feeding speed 45 sheets/min. (600 dpi)
Acceptable originals
A3, A4, A4-R, A5-R, B4, B5, B5-R, FOLIO, LD, LG, LT, LT-R, ST-R, COMP
(A5 and ST size are not acceptable.)
Paper weight 1-sided original: 35 - 157 g/m
2
, 9.3 - 41.8 lb., 2-sided original: 50 - 157 g/m
2
, 13.3 - 41.8 lb.
Power source DC 24 V (supplied from the equipment)
Dimensions 575 mm (22.6) (W) x 528 mm (20.8) (D) x 135 mm (5.3) (H)
Weight Approx. 12.5 kg (27.6 lb.)
Power consumption 49.5 W max.
Large Capacity Feeder
Model name KD-1028
Acceptable paper
size
A4 or LT
Paper weight 64 - 105 g/m
2
, 17-28 lb. Bond
Maximum capacity 2500 sheets (80 g/m
2
, 20 lb. Bond), 2000 sheets (90 g/m
2
, 28 lb. Bond) (Height: approx. 137 mm or 5.4 x 2)
Power source DC 5 V, DC 24 V (supplied from the equipment)
Dimensions 623 mm (24.5) (W) x 642.3 mm (25.3) (D) x 307.5 mm (12.1) (H) (incl. Stabilizer)
Weight Approx. 27 kg (59.5 lb.)
Paper Feed Pedestal (1 drawer type)
Model name KD-1027
Acceptable paper
size
A3, A4, A4-R, A5-R, B4, B5, B5-R, FOLIO, LD, LG, LT, LT-R, ST-R, COMP (A5, ST and non-standard size are not
acceptable.)
Paper weight 64 - 256 g/m
2
(17 - 80 lb. Bond, -140 lb. Index)
Maximum capacity 550 sheets (80 g/m
2
, 20 lb. Bond), 500 sheets (105 g/m
2
, 24 or 28 lb. Bond)
Power source DC 5 V, DC 24 V (supplied from the equipment)
Dimensions 623 mm (24.5) (W) x 642.3 mm (25.3) (D) x 320 mm (12.6) (H) (incl. Stabilizer)
Weight Approx. 21.5 kg (47 lb.)
Additional Drawer Module
Model name MY-1035
Acceptable paper
size
A3, A4, A4-R, A5-R, B4, B5, B5-R, FOLIO, LD, LG, LT, LT-R, ST-R, COMP (A5, ST and non-standard size are not
acceptable.)
Paper weight 64 - 256 g/m
2
(17 - 80 lb. Bond, - 140 lb. Index)
Maximum capacity 550 sheets (80 g/m
2
, 20 lb. Bond), 500 sheets (105 g/m
2
, 24 or 28 lb. Bond)
Weight Approx. 3.7 kg (8.2 lb.)
