OKIPOS 425D
|
2.1.2 LED Function
A25004.doc
No. LED ON OFF Blinking
1 POWER Green Powered On Powered off -
2 LED 1
(ERROR)
Red Recoverable Alarms
*Slip Feed/Eject
Alarm
*Auto Loading Alarm
*Auto Parking Alarm
*Media Mismatch
Alarm (1)
*Media Mismatch
Alarm (2)
*Cover Open Alarm
(Only OKI
standard type)
Normal state *Unrecoverable Alarms
(blinking pattern indicates
alarm type)
*See the table in section 4.1
*SP Thermal alarm
(LED2 blinks concurrently)
*LF Thermal Alarm
3 LED2
(Status)
Orange Paper is not fed
(In sheet-insertion
wait state)
Paper has
been fed
(in print ready
state)
*In sheet-extraction wait
state
*SP Thermal Alarm
(LED1 blinks concurrently)
Orange In Slip Mode In Validation
mode
*Quick
blinking
In MICR
Mode
*Slow
blinking
4 LED3/
LED4
(Mode)
Green
In Receipt + Journal
Mode
In Tractor
Mode
In Receipt
Mode
* Quick
blinking
In Journal
Mode
* Slow
blinking
When “Cover Open Alarm” is set to No in Menu, Cover Open Alarm is disabled (printing does not stop).
* Media Does Not Match Alarm (1) is detected by monitoring the option tractor lever. Media Does Not
Match Alarm (2) is detected by the Validation sensor monitoring (media manually inserted into the
validation opening).
