Developer’s Guide: English 53
3.3 Clearing Paper Jams
When Roll Paper gets jammed, remove the paper, following the procedure shown below:
1. Press Cover Open Bar and open the printer cover.
* Print head may be very hot. Exercise caution.
o425_31.jpg and o425_32.jpg
2. Remove the rewinder and cut the Roll Paper at the location shown below.
1 Roll Paper (Receipt) not yet printed
2 Roll Paper (Journal) not yet printed
3 Cut Positions
1
3
2
