Developer’s Guide: English 69
5.4 Physical Characteristics
5.4.1 Printhead
Print method: Impact dot matrix
Number of dot wires: 9 wires
Dot wire diameter: 0.34 mm (0.013")
5.4.2 Printer
1 Outside dimensions (without Tractor)
265 mm (10.43") (W) x 218 mm (8.58") (H) x 337 mm (13.27") (D)
OP425_09b.eps
265mm (10.43inch)
25.5mm (1inch)
337mm (13.27inch)
218mm (8.58inch)
2 Outside dimensions (with Tractor)
265 mm (10.43") (W) x 218 mm (8.58") (H) x 422 mm (16.61") (D)
