80
OKIPOS 425D
|
5.7.5.2. Roll paper (Receipt/Journal)
5.7.5.2.1 Paper size and Printing area
OP425_19b.eps
1 First character position
2 Cutting position (for manual cutting)
3 Printing area
A25048.doc
Symbol Designation Standard Value
W Roll paper width 69.5/76.2 mm (2.73/3 inch) +0.5mm (0.02 inch)
φ
A
Roll paper outside diameter
φ
83mm (3.27 inch) or less
φ
B
Core inside diameter 10mm (0.4 inch) or more
C Left margin 3.54 mm (0.14 inch) or less
D Right margin 1.54 mm (0.06 inch) or more
E Printing area width Max 64.35/71.12mm (2.53/2.8 inch)
F Top margin 41.69 mm (1.64 inch) or more
1
2
3
