Symbol Designation Standard Value
W Paper width 76.2~215.9mm (3~8.5 inch)
L Paper length 76.2~355.6mm (3~14 inch)
The length must be the one obtained via
multiplying 25.4mm (1 inch) by an integer
A Heading position 10.31mm (0.41 inch)
B Top margin (on the 1
st
page) 25.4mm (1 inch)
C Bottom margin, recommended 19.05mm (3/4 inch)
D Bottom margin, printable 6.35mm (1.4 inch)
E Top margin, recommended 25.4mm (1 inch)
F Top margin, printable 10.31mm (0.41 inch)
G Bottom margin, recommended 198mm (7.8 inch)
H Bottom margin, printable 19.6mm (0.77 inch)
I Unprintable left margin 11.43mm (9/20 inch)
J Unprintable right margin Paper width is 203.2mm (8 inch) or less:
11.43~21.59mm (9/20~0.85 inch)
Paper width is 215.9mm (8.5 inch):
20.39~21.59mm (0.8~0.85 inch)
Note 1 Though you can print within the light shaded area (printable area), feeding may be less accurate.
Note 2 The print quality on the last page is not warrantied.
Note 3 Printing out of the designated printing area may result in poor printing quality or malfunction of the unit. Set the
printing format cautiously.
Note 4 The horizontal perforated line should be placed in the middle of the sprocket hole interval. A horizontal perforated
line close to a sprocket hole may let the paper slip off the holes, resulting in a paper jam.
Note 5 Auto parking function of Sprocket paper can operate up to 14".
