LCD Multi-Media Display LT37HVS MK0-UM00095G000
Table of C ontents Important Information Important Safety Precautions FCC Statement Introducing the Syntax OLEVIA TV Accessories Installation And Connection Guide Identifying Front Controls and Rear Inputs -Descriptions of Input Types -Connecting the TV's Power Installation -Connecting to an Antenna or Video Equipment with Antenna outlet -Connecting to a VCR -Connecting to an Audio Receiver/Home Theater System -Connecting to a DVD Player with A/V or S Video Cables -Connecting to a DVD Player with Component
Import ant information Caution Risk of electronic shock Do not open To reduce the risk of electronic shock, do not remove cover (or back). No user-serviceable parts inside. Refer service to qualified Repair Technician or Repair Center. Read the following context indicated by the following symbol to the left. It indicates important literature in operating the product. Read the following context indicated by the following symbol to the left.
Import ant safety precautions Cleaning Stand Remember to unplug the AC cord from the AC outlet before cleaning the display unit. And do not use liquid cleaners or aerosol cleaners to clean the display. Do not place the display unit on an unstable place. The TV may fall resulting in serious personal injuries to nearby people as well as damage to the display unit. Ventilation Do not cover or block these vents and openings located on the top and back of the display.
Important safety precautions Never insert objects or spill liquid into the display unit Precautions when transporting the display Never insert any object into the display unit through openings or spill liquid on the display unit. High voltage flows in the display unit, and inserting an object can cause electric shock and/or short internal parts. Carrying the display requires two or more people. Keep away from water and moisture Do not use attachments not recommended by the manufacturer.
Important safety precautions Replacement parts In case the display unit needs replacement parts, make sure that the service technician uses replacement parts specified by the manufacturer, or those with the same characteristics and performance as the original parts. Use of unauthorized parts can result in fire, electric shock and/or other danger.
FCC Statement FCC notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
TM TM Introducing the Syntax OLEVIA TV Welcome! TM TM Thank you for purchasing a Syntax OLEVIA LCD TV. This manual is to be used with the following model: LT37HVS This manual is designed to help you through setting up and operating your LCD TV as quickly as possible. The model and serial numbers are on the back cover of your TV. Write these numbers in the space provided in this manual for your records.
Introducing the SYNTAX Olevia TV TM TM Syntax OLEVIA LCD TV includes many features you will enjoy throughout the usage of your TV. These highlighted features include: Fully Integrated HDTV (High Definition TV): HDTV delivers a stunning picture far beyond the quality of standard televisions. These programs offer crystal clear video with amazing detail played with enhanced audio quality of digital television programs.
Accessories Supplied accessories Remote control & batteries (AAA x 2) VGA cable (D-Sub 15 male) x 1 - User manual booklet x 1 LCD Multi-Media Display LT37HVS QSG x 1 Power cord x 1 08
Accessories Optional accessories Wall mount set AV cable with RCA connector Model# WM-20D S-video cable HDMI cable Audio cable with RCA connector Component cable with RCA connector Audio cable with stereo mini jack Use the proper cable for the device.
TV Installation and Connection Guide Identifying Front and Rear Panels Front Panel POWER Turns display on/off MENU Displays the On Screen Display(OSD) menu. In OSD menu, press it to return to pre-phase CH / CH Source VOL- VOL+ CH CH Menu Power Adjusts Channel. In the OSD menu, both key are used to navigate within menu. VOL+/VOL- Adjusts volume. In OSD menu, both key are used to navigate within menu. Vol+ is used to select the highlighted option.
TV Installation and Connection Guide Identifying Front and Rear Connectors Rear Panel DTV ANT Audio Output Ear Phone L Component-1 R L L Pr/Cr Pr/Cr Pb/Cb Pb/Cb Y VIDEO-1 L HDMI R Component-2 R Y VIDEO-2 R R L L AV AV Service Port VGA R S-Video S-Video Audio Out The Audio Output sends the TV's connected audio signals to an A/V receiver or other equipment. Display features a R/L stereo output. AC IN power cord connects here.
TV Installation and Connection Guide Descriptions of Connector Types You may find it necessary to use some of the following connector types during setup. 75-ohm coaxial cable Used for TV cable connection . S-Video Cable High quality video cable for enhanced picture quality.
TV Installation and Connection Guide Connecting the Power Cord Complete other connections prior to connecting the power cord: 1.Connect the power cord to the AC IN connector of the TV 2.Connect the other end of the power cord to the wall outlet.
TV Installation and Connection Guide Installation In the following pages, you will find directions on how to install your tv and choice of video equipment.
TV Installation and Connection Guide Connecting to an Antenna or Video Equipment with Antenna ou tlet Disconnect all power sources before making any connection. 1.Connect a 75-ohm coaxial cable onto the ANT input on the back of the TV's right side panel. Rear of TV DTV Audio Output Ear Phone L R Component-1 75-ohm coaxial cable Component-2 R R L L Pr/Cr Pr/Cr Pb/Cb Pb/Cb Y VIDEO-1 Y VIDEO-2 R R L L If connecting to Video Equipment with Antenna outlet 1.
TV Installation and Connection Guide Connecting to a VCR Disconnect all power sources before making any connections. Use this hookup if you subscribe to a cable TV system that does not require a cable box. DTV ANT Audio Output Ear Phone 1.Using A/V cable and S-Video cables, connect the VCR's Audio and S Video OUT jacks to the TV's Audio and S-Video In jacks.
TV Installation and Connection Guide Connecting to an Audio Receiver / Home Theater System Disconnect all power sources before making any connections. 1.Using an audio cable, connect the TV's audio OUT jack to the audio receiver's audio IN or AUX IN jacks. 2.Using an audio cable, connect the TV's audio Out jack to the subwoofer Audio In or AUX IN jacksreceiver's audio IN or AUX IN jacks.
TV Installation and Connection Guide Connecting to a DVD Player with A/V or S Video Cables Disconnect all power sources before making any connections. Use this hookup if your DVD player does not have component (Y, Pb, Pr) jacks. Note: If your DVD player has component video output connectors, for best picture quality, use the connection described for Connecting to a DVD Player With Component Connectors.(See page.19) DTV ANT Audio Output 1.
TV Installation and Connection Guide Connecting to a DVD Player With Component Cables Disconnect all power sources before making any connections. Use this hookup if your DVD Player has component (Y, Pb, Pr) jacks. 1.Using a component video cable, connect the DVD Player's Y, Pb and Pr jacks to the Y, Pb and Pr jacks on the TV.
TV Installation and Connection Guide Connecting to a Satellite Receiver or Cable Box with A/V Connectors Disconnect all power sources before making any connections. 1.Using Audio and S Video cables, connect the satellite receiver's Audio and S Video OUT jacks to the TV Audio and S Video IN jacks. 2.Connect a 75-ohm coaxial cable from your cable or antenna to the TV Ant (Antenna) jack.
TV Installation and Connection Guide Connecting to a Satellite Receiver or Cable Box With Component Connectors Disconnect all power sources before making any connections. Use this hookup if your Satellite Receiver or Cable Box has component (Y, Pb, Pr) jacks. 1.Using a component video cable, connect the Satellite Receiver or Cable Boxes' Y, Pb and Pr jacks to the Y, Pb and Pr jacks on the TV.
TV Installation and Connection Guide Connecting to a PC with VGA Connector Rear of TV L HDMI Disconnect all power sources before making any connections. VGA R 1.Using a D-Sub 15 pin cable, connect the VGA output terminal of the PC to the TV's VGA signal input terminal. 2.You may need to use a Stereo mini jack to RCA L/R connectors to receive audio.
TV Installation and Connection Guide Other Connections Disconnect all power sources before making any connections. See setup instructions for: Connecting to an Audio Receiver on page 15. Note: Subwoofer speakers must contain an amplifier in order to amplify the signal from the TV.
Remote Control Guide Remote Function Keys & Description Regular Buttons MUTE Press to mute the sound. 8 1 NUMBER BUTTONS Press the number buttons to select channels on the display. CH RTN ( Channel return )Press to return the previous-channel. 2 MTS Press to select from SAP, Mono or Stereo mode 3 VOL+/ VOL Press to adjust the volume. - 10 4 FAVORITE Press to select favorite channels. Can be preset in OSD Menu. 11 5 DISPLAY Press to display the information of current channel number and time.
Remote Control Guide Hot Keys Tutorial The remote control contains 15 additional "Hotkeys" that represent direct access to a certain function on your TV. Hotkeys enable you to directly change the setting to your preference without having to navigate through the OSD (On Screen Display) Menu. How to use your Hot Keys - HOT KEY FUNCTION TV/VIDEO Press to switch between TV and source as Video 1and Video 2 Mode. HDMI/VGA Press to switch to HDMI or VGA Mode.
Remote Control Guide Battery Installation 1.Push the tab and pull it out as illustrated below. 2.Insert two size AAA batteries (supplied) by matching the (+) and (-) on the batteries to the diagram inside the remote control's battery department. 3.Replace the cover back and make sure the cover "snaps" into the remote control. Note: 1.The display unit comes with two new AAA batteries as accessories.
Adjusting On Screen Displays (OSD) Introduction After you have finished connecting your TV, you are now ready to choose and personalize your TV settings in the OSD (On Screen Display) menu. There are four main sections in the OSD Menu: Video Audio Miscellaneous Screen DTV 1. Press "Menu" button to enter OSD menu mode. - To Operate in the OSD 2. To select between main functions, use the keys "VOL - " and " VOL+" 3. To select the function, press the keys "CH+ " and "CH- " 4.
OSD-Video Adjusting On Screen Displays (OSD) VIDEO Adjusting TV Picture Settings Advance Video Quality In this Setup Index, you can adjust the video and picture settings to suit your personal preferences.
OSD-Video Adjusting On Screen Displays (OSD) Advance P icture Adjust To further adjust specific picture settings, enter this function by pressing the button. Advance Picture Adjust Definition of Terms Item DNR Status Off/Low/Middle/Strong Black Level Extender On/Off White Peak Limitator On/Off Flesh Tone On/Off Adaptive Luma Control On/Off Description and Function DNR-Dynamic Noise Reduction. Reduces high frequency noise dynamically. Off- Dynamic Noise Reduction is disabled.
OSD-Video Adjusting On Screen Displays (OSD) To Adjust S ettings: Use the and as seen below: remote buttons to adjust each Video picture setting, Brightness Saturation Hue To exit, press the Enter Button To Reset Factory Settings If, at any time, you wish to go back to original factory setting, you may do so by choosing the Default setting in the OSD Picture and Audio Sections. Selecting "Default," will reset all OSD settings to the original manufacture settings.
OSD-Audio Adjusting On Screen Displays (OSD) Audio Adjusting Sound Quality Audio setting Definition of Terms Item Treble Bass Balance Surround Adjustment -50~50 -50~50 -20~20 On / Off Equalizer 1 MTS Off, Concert, Living Room, Hall, Arena, Church Off, Rock, Pop, Live, Classic, Soft Mono, Stereo, SAP Speakers On / Off Equalizer 2 Function Adjusts higher pitched sounds Adjusts lower pitched sounds Adjusts volume balance in Left and Right Creates a panoramic stereo audio image by producing deep and
OSD-Audio Adjusting On Screen Displays (OSD) To Adjust S ettings: Use the and seen below: remote buttons to adjust each Audio sound quality, as Treble Bass Balance Surround Sound is an available option for creating a panoramic stereo audio image by producing deep and rich bass tones and clear treble tones. This enables you to enjoy powerful sound effects like those in a movie theater. Speakers Must turn off speakers of the TV when using a Receiver or Home Theater System.
OSD-Audio Adjusting On Screen Displays (OSD) OSD Audio Settings: Equalizer 1 OSD Audio Settings: Equalizer 2 33
OSD-Audio Adjusting On Screen Displays (OSD) MTS System for Stereo TV You can enjoy stereo, bilingual and mono programs. Additionally, you can press the hotkey "MTS" until the desired sound in dication appears.
OSD-Miscellaneous Adjusting On Screen Displays (OSD) MISCELLANEOUS Adjusting Personal TV Settings In this Section, you can adjust additional TV settings to your personal preference, including channel setup, choosing tuner modes, setting up timer, closed caption services, parental controls, and viewing the OSD in your preferred language.
OSD-Miscellaneous Adjusting On Screen Displays (OSD) Setting the Channels After you finish connecting your TV, you can run Auto Scan program to setup your channels. The program will scan and preset all receivable channels automatically. To Cancel Auto Program Exit auto scan program by pressing "menu" Key. Note: The Auto Scan is set to scan cable TV channels by default. You cannot receive and set the cable TV channels VHF/ UHF channels at the same time.
OSD-Miscellaneous Adjusting On Screen Displays (OSD) Watching favorite channels To watch your favorite channels after specifying your preferences, just press the Hotkey "FAVORITE" to browse through each favorite channel. Editing Channels You can also edit channels to your personal preference. Once you edit a channel, it will be skipped when surfing through TV channels. To Skip or Lock a Channel 1.Make sure Channel Skip or Channel Lock is highlighted. 2.
OSD-Miscellaneous Adjusting On Screen Displays (OSD) Personal Channel Preferences: Channel Naming You can also create personal names for each channel, which will show up in the upper Right hand corner of the TV screen. To Name a Channel: 1. Enter Channel Name sub-page 2. Enter Channel name using alphabet-numerical keypad as seen below: 3. Press "Okay" to exit keypad when naming is complete.
OSD-Miscellaneous Adjusting On Screen Displays (OSD) Setting up the TV Timer To setup the time on the TV: 1.Using and keys, enter in HH: MM: SS Enter the time using the number keys found on the remote. 2.press "Enter" when complete. NOTE: Clock will NOT BE affected when Factory Default settings are reset.Under Activate, "ON" allows the start/stop time to be ongoing whereas, "ONCE" allows it to only function once.
OSD-Miscellaneous Adjusting On Screen Displays (OSD) Timer: Start Time / Stop Time You can set the TV to turn On and/or Off automatically at a predetermined time through the timer function. Use the Start Time to setup the hour and minute preferences. Your TV will automatically turn on at the set time. Use the Stop Time to setup the hour and minute preferences. Your TV will automatically turn off at the set time. Note: Alarm WILL BE affected when Factory Default settings are reset.
OSD-Miscellaneous Adjusting On Screen Displays (OSD) TV OSD Languages There are nine language formats available for the OSD Menu. You may choose from the following: English, Chinese Traditional, Chinese Simplified, Deutsch, ~ Francese, Italiano, Espanol, Portugues and Pycc KNN~. ^ Using the Parental Control Feature To block programs you feel unsuitable for your children, you need to Set the TV for desired rating systems.
OSD-Miscellaneous Adjusting On Screen Displays (OSD) Parental Control 1. This function allows programs to be restricted and controlled by parents based on FCC regulation. It prevents children from watching program contents that may be prohibited by parents. 2. Restriction of programs is based on three Rating Systems: MPAA Rating, TV (Child) Rating and TV (Entire Audience) Rating. The MPAA Rating restricts based on age. TV (Child) rating and TV (Entire Audience) Rating restrict based on age and contents.
OSD-Miscellaneous Adjusting On Screen Displays (OSD) Activating the Parental Control Feature Once you enter the highlighted section of Parental Control, you will have to enter your password. The Factory Default password is"9999". Once you enter the Parental Control Menu, you may change the password to your personal preference. To setup, enter each sub-menu to setup your parental controlled TV channels.
OSD-Miscellaneous Adjusting On Screen Displays (OSD) MPAA Rating controls channels and movies that are rated from G, PG-13, R, NC-17, and X. TV Rating controls channels and movies that have been rated from TV-Y, TV Y-7, TV-G, TV-PG, TV-14, and TV-MA. To Block Unrated Channels You may choose "YES" for Block MPAA Unrated and Block TV None Rating. This will lock you from accessing any channels that do not contain MPAA or TV Ratings.
OSD-Miscellaneous Adjusting On Screen Displays (OSD) Setting up Parental Control Password Enter the password sub-page. Enter the current password. If this is the first time, you do not have to enter a password. You will have to enter and confirm your password before changing to a new password. Please keep password within 4 numbers. If you enter the incorrect password, you will see an error page. Please re-enter the new password and confirmation password again.
OSD-Miscellaneous Adjusting On Screen Displays (OSD) Factory Default Option Reset Factory Settings: Initiating Factory Default will reset all OSD settings to original manufacture settings.
Adjusting On Screen Displays (OSD) Adjusting Screen Modes There are two options in Screen Mode, "Aspect & View." Aspect will allow user to select different aspect ratios, whereas the View function will display different modes of viewing between 2 different sources.
OSD-Screen Adjusting On Screen Displays (OSD) Changing the View Modes You can select four view types of picture modes that best suits the program you are watching. You can set a different view mode for each video mode for each input and store it manually. View Modes Function PIP Picture-in-Picture has a Main screen and small screen view Split Screen Full Screen split in two Views Picture in Picture (PIP) Allows you to view a main screen (Picture 1)and a secondary small screen (Picture 2).
OSD-Screen Adjusting On Screen Displays (OSD) OSD View TV View 49
OSD-Screen Adjusting On Screen Displays (OSD) PIP mode You may adjust setting for each Picture source. Pic 1 allows for a TV, AV1, AV2 an d HDMI sources while Pic 2 supports all other input sources.
OSD-Screen Adjusting On Screen Displays (OSD) Split Screen Allows you to view two separate screens simultaneously (Picture 1 and Picture 2). Press 'source' button to switch from P1 to P2 and vice versa.
Adjusting On Screen Displays (OSD) Split Screen mode You may adjust setting for each Picture source. Only Pic1 supports a TV input source, while Pic2 supports all other TV input sources. Item Pic1 Pic2 Adjustment TV1, AV1, AV2, HDMI AV1, AV2, S-Video1, S-Video2, YpbPr1, YpbPr2, HDMI, VGA Function Switches the source of Picture 1 Switches the source of Picture 2 Note: Pic 1 allows for a TV, AV1, AV2 and HDMI.
OSD-DTV Adjusting On Screen Displays (OSD) DTV:Adjusting DTV Settings Introduction to DTV A Brief Look at Broadcast and Digital Television Broadcast television is a traditional way of watching TV programs simply by installing an antenna. This is called analog TV.In recent years, many countries have begun to mandate a transition from analog to digital television. Digital TV provides noise-free, high-definition picture quality, Dolby AC-3 sound effects, and a handy EPG (electronic program guide).
OSD-DTV Adjusting On Screen Displays (OSD) DTV Functions The HDTV-ST Digital HDTV Receiver can receive channels from both VHF band and UHF band TV signals. All the major free-to-air station numbers currently available in your area are listed in the on-screen menu. To watch the channel, simply select the channel number. The receiver is fully ATSC / MPEG-2 (digital video broadcast) compliant, delivering High Definition crystal-clear video and Dolby AC-3 sound.
OSD-DTV Adjusting On Screen Displays (OSD) Setting Up the DTV RECEIVER From your DTV OSD Menu, you can personalize your TV options in the following settins: Channel Caption Setup Lock Channel Before you can use any of the channel buttons (CH , FAV.), the available channels must first be scanned and memorized. Initial Screen The first time the receiver is powered on, you will see the message "Press (Menu) key and then select Channel to run Auto/Manual Scan".
OSD-DTV Adjusting On Screen Displays (OSD) Auto Scan To automatically scan your channels, follow these steps: 1.Edit 2.Auto Scan 3.Manual Scan Press or buttons to highlight AUTO SCAN , and then press Enter. An AUTO-SCAN window will display the SCAN status. The receiver scans Off-Air channels searching for both NTSC analog and ATSC digital signals from channel 2 to channel 69. The percentage bar shows the progress being made.
OSD-DTV Adjusting On Screen Displays (OSD) Adding Channels Manually You can add channels manually if they aren't detected by the Auto Scan utility using the following steps: On the Channel menu page, select "Manual Scan", and then use the or button to select the channel connection: Air, Cable STD, Cable IRC, or Cable HRC. Press Enter to highlight the input column, then press numeric buttons to input the channel number. The channel frequency is automatically shown on right side of the input column.
OSD-DTV Adjusting On Screen Displays (OSD) Edit Channels (Block or Add to Favorites List) You can block access to channels or add them to your favorites list using the following steps: On the "Channel" menu, press the numeric key to input the default password "0000" or your password. Press and to highlight Edit, and then press Enter. To block channels, press and buttons to highlight the channel BLOCK column and press ENTER.
OSD-DTV Adjusting On Screen Displays (OSD) Closed Caption Options Follow these steps to turn on closed captioning: Press buttons to highlight the "Caption" icon and press ENTER. Font Size: Press and buttons and the ENTER button to select the desired Closed Caption font size. Font Style: Press and buttons and the ENTER button to select the desired Closed Caption font style.
OSD-DTV Adjusting On Screen Displays (OSD) Closed Caption Background Color: Press and buttons and the ENTER button to select the desired Closed Caption background color. Closed Caption Foreground Color: Press and buttons and the ENTER button to select the desired Closed Caption foreground color. Closed Caption Background Opacity: Press and buttons and the ENTER button to select the desired Closed Caption background opacity.
OSD-DTV Adjusting On Screen Displays (OSD) Closed Caption Edge Style: Press and buttons and the ENTER button to select the desired Closed Caption edge style. Closed Caption Edge Color: Press and buttons and the ENTER button to select the desired Closed Caption edge color. Press EXIT button to return to the main menu or press MENU button to exit the menu system.
OSD-DTV Adjusting On Screen Displays (OSD) Setup Press MENU, then use the access these sub-menus: 1.Format 2.Opacity 3.I-Plate 4.Time Zone 5.Language 6.About buttons to highlight the "Setup" menu to Format (Screen Format Setup) On the "Setup" menu, press press ENTER. Press and and aspect ratio. buttons to highlight the "Format" and buttons to select your screen type, video resolution Press the EXIT button to return to the main menu page or press the MENU button to exit the menu system.
OSD-DTV Adjusting On Screen Displays (OSD) Aspect Ratio Your options on the Screen Format menu depend on the type of TV or monitor you are using with the Receiver. 4:3 (Letterbox): Select this when receiving a 16:9 source signal to see the original 16:9 format. Blank panels appear at the top and bottom of the screen. 4:3 (Zoom): Select this and no blank panels will be added. 4:3 (Full): Select this when receiving a 16:9 signal and you want the image to fill the entire screen.
OSD-DTV Adjusting On Screen Displays (OSD) Opacity (Transparency of On-Screen-Display) Press buttons to highlight Opacity and press Enter. Use the buttons to change the percentage of the On-ScreenDisplay's transparency. Press the EXIT button to return to the main menu or press the MENU button to exit the menu system. I-Plate (Display time of the information-Plate) Select I-Plate, then press and buttons to change the Information-Plate display time to 2, 4, 6 seconds or to turn it off.
OSD-DTV Adjusting On Screen Displays (OSD) Time Zone Press or buttons to highlight TIME ZONE and press ENTER. If you are receiving a digital signal, the Receivers time will be set automatically. Press the hours. or buttons to change the time display format to 12 or 24 Press the Enter button to highlight the input column, and then press or buttons to change the time zone 30 minutes at a time. Press the EXIT button to return to the main menu or press the MENU button to exit the menu system.
OSD-DTV Adjusting On Screen Displays (OSD) About (Receiver Information) Press or buttons to highlight About and press the ENTER button to see the information window containing hardware and software information. Press the EXIT button to return to the main menu or press the MENU button to exit the menu system. Lock Rating (Lock Programs by Rating) Press buttons to highlight the "Lock" icon and press ENTER. Enter the password correctly.
OSD-DTV Adjusting On Screen Displays (OSD) After the password is entered, the screen will display these three submenus: 1.Rating 2.Password 3.Reset Box Press buttons to highlight the "Rating", and then press Enter to access the rating control menu. This menu lists both MPAA and USTV (FCC) Parental ratings. You can independently lock the MPAA and TV ratings. The locked ratings are indicated by the lock symbol.
OSD-DTV Adjusting On Screen Displays (OSD) Important information About "Parental Rating" Explanation of the MPAA and TV (FCC) Rating Systems: USTV (FCC) Age-Based Ratings TV-MA Mature audiences only. This program may contain mature themes, profane language, graphic violen ce and explicit sexual content. TV-14 Parents strongly cautioned. This program may contain sophisticated themes, sexual content, strong language and more intense violence. TV-PG Parental guidance suggested.
OSD-DTV Adjusting On Screen Displays (OSD) Change Password Access to the "Lock" or "Channel" menus is controlled by a Password. You need to enter the correct password to access these functions. Press the MENU button on the remote control. Press or buttons to highlight the Lock icon. Then press or buttons to highlight the Password and press ENTER. Follow the description on the pop-up window to press numeric buttons to input the new password and confirm it.
OSD-DTV Adjusting On Screen Displays (OSD) You must reset the Receiver back to its default status if you forget the password. You will lose all your settings after the Receiver has been reset. Using the "POWER button on the front panel or remote control, cycle the power off and back on again. When the front panel LED displays "boot", press these buttons in a sequence: " ", " ", " " and " MENU-SELECT". The Receiver will be reset as the default status automatically.
OSD-DTV Adjusting On Screen Displays (OSD) Next Program Press the button to display information for the NEXT program. Press the button to display information for the PREVIOUS program. Extended Program Information Press the DISPLAY button again to display extended program information for the current TV channel. Press the DISPLAY button again to close the I-Plate or Extension window, or press the EXIT button to exit the I-Plate window.
OSD-DTV Adjusting On Screen Displays (OSD) EPG (Electronic Program Guide) Press the EPG button to display the Program Guide window. The current program will be highlighted automatically in yellow. Press or buttons to scroll the program list to the left or right and view up to 12 hours of program guide information. Press or buttons and scroll through the program list upward or downward to view the program guide for different channels.
OSD-DTV Adjusting On Screen Displays (OSD) CLOSED CAPTIONS If the I-Plate indicates that there is Closed Caption data on the current channel, pressing the CC/CS button on the remote control will display the C.C. Options list on the TV screen. Use and keys to highlight the desired CC signal and press the ENTER button. Press the EXIT or CC/CS key to close the CC Options list and view the program with Closed Captions.
OSD-DTV Adjusting On Screen Displays (OSD) FAVORITE CHANNEL LIST When you are watching broadcast or cable TV channels, you can press the "FAV" button on the remote control to display the Favorite Channel List. Use and keys to select the "ALL", "ATSC", "NTSC" or "FAV" program lists. Use and keys to highlight the program you want and press the ENTER button. Note: The channel table of the Receiver will follow settings in this menu. To view ATSC channels only, select the ATSC channel list.
OSD-DTV Adjusting On Screen Displays (OSD) Selecting Digital Channels Selecting digital channel numbers is different from selecting traditional channel numbers. For example, To select digital channel number: 10 - 2 1. press numeric key "1" and "0" 2. press the " "button 3. press the numeric key "2" Freezing the Picture Press the "FREEZE" button on the remote control to freeze the picture. The "Freeze" message will appear in the upper right corner of the screen.
OSD-DTV Adjusting On Screen Displays (OSD) DTV Channel Table Information *Log on to the website http://www.antennaweb.org and select "Choose An Antenna". Enter your address and find the DTV stations airing the EDTV / HDTV signal in your local area and then visit the local station websites for program schedules. Usually the website names are the same as the station's name. For example, DTV station WCBS (channel 56) New York's website is http://www.wcbs.
Specifications TFT LCD Panel Specifications Panel size 37" Aspect Ratio 16:9 Pixels 1366 X 768 Dynamic Contrast Ratio 1600:1 H/V(View Angle) 178 (H) / 178 (V) Gray to Gray Response Time 8 ms Video/Graphic Processing PC compatible frequency 30~85 KHz(H) / 50~80Hz(V) Max.
Specifications TFT LCD Panel Output Terminals Audio Output(Rear) Output 1: Stereo Audio R/L x1 Audio Output(Front) Output 1: Earphone 1/8" Others Power (Voltage) 100~240 VAC / 50-60 Hz (Power Consumption) 180W Stand-by < 3W Dimensions (W x D x H) 45.6 in x 5.9 in x 26.3 in Carton Dimensions (W x D x H) 51 in x 14.2 in x 31 in Weight 64.32 Ibs Weight w/ stand 71.66 Ibs Gross weight 94.82 Ibs Dimensional drawing 5.9in 24.2in 34.5in 26.3in 11.7in 45.
Timing Mode for VGA and DVI Source Resolution YPbPr 480p 59.94 31.469 27 720p 60 45 74.25 1080i 60 33.75 74.25 512 x 384 60.147 24.48 15.667 640 x 350 85 37.861 31.5 640 x 400 85 37.861 31.5 56 24.823 21.05 59 30.296 24.964 59 30.295 25.024 66 35 30.24 66 34.975 31.34 66 35 30.24 72 37.861 31.5 75 37.5 31.5 75 39.375 31.5 85 43.269 36 720 x 350 70 31.469 28.32 720 x 400 70 31.469 28.32 85 37.927 35.5 87 39.444 35.5 56 35.
Timing Mode for VGA and DVI Source Resolution VGA 1024 x 768 Horizontal frequency (Khz) Pixel rate (MHZ) 75 60.241 80 75 62.937 84.6 75 61.08 86 75 60.023 78.75 77 62.04 84.4 85 68.677 94.5 70.012 63.851 94.5 75 67.5 108 1152 x 870 75.062 68.681 100 1152 x 900 65.95 61.795 92.9 66.004 61.846 94.5 76.047 71.713 105.6 76.149 71.809 108 60 63.36 89.2 61.399 65.286 92.9 1280x 960 60 60 108 1280 x 720 60 45 74.25 1280 x 768 60 48.36 81.
Pixels Policy Syntax's D.O.A. Policy for LCD TVs for Defective Pixels on LCD Panels (Applicable to the LCD TV sold within USA & Canada only) Syntax TM LCD TVs are evaluated at a distance of approximately 50 centimeters (approximately 20 inches) between the LCD panel and the eyes of the user at a 90 degrees viewing angle. All LCD panels have been tested to ensure they comply with our factory standards.
Glossary 3:2 pull down - Process of converting 24 frames per second film to video by repeating one film frame as three fields, then the next film frame as two fields. 1 1 1 2 2 1 1 1 2 2 480I - 480 lines of display every 1/60 of a second; image is displayed by interlace scanning. See also Interlaced 480P - 480 lines of display every 1/60 of a second; image is displayed by progressive scanning. See also Progressive.
Glossary Color - The term refers to the amount of color present. This varies between each user, as each person perceives colors differently. Color Temperature - Feature on the OSD for the Syntax Olevia models that enables warm, normal or cool color settings. Warm emphasizes red, cool emphasizes blue, and normal doesn't emphasize any of the primary colors. This setting may affect each person individually depending on how color is perceived.
Glossary Interlaced - Images are the result of lines of data reassembled. Interlaced refers to the process of an image's odd lines reassembled from top to bottom taking about 1/60 of a second, before reassembling the even lines which results in a full picture. Antonym: Progressive Language - Feature on the OSD for the Syntax Olevia models that enables the OSD to be read in different languages.
Glossary Swap - Button featured on the Olevia remote. Used in the POP3 or PIP12 views to swap the sub viewable boxes with the main viewable box. Tint - Adjusts the whiteness level within the color. Similar to Hue. Under- scanning Term used where the image displayed is smaller than the display area. Up convert - Process of converting a 480P/I signals to 720P or 1080I. V-Chip - Chip that controls access to forbidden content specified by an adult. VGA - 1. Video Graphics Array (DB15) 2.
