OLIMEX© 2013 OLIMEXINO-85 user's manual
GPIO-1 connector
Pin # Signal name Processor pin
1 0 5
2 1 6
3 2 7
4 3 2
5 4 3
6 #RST 1
7 GND 4
8 VCC 8
5.3 Jumper description
The board has no hardware jumpers.
5.4 Additional hardware components
The components below are mounted on OLIMEXINO-85 but are not discussed above. They are
listed here for completeness:
Reset button – used to reset the board
PWR LED – green LED that turns on upon powering the board
STAT LED – programmable general-purpose red LED
