Replacement Part List

4
32
30
29
28
27
01
26
25
31
18
24
23
22
13
14
12
15
16
17
21
20
19
18
11
09
10
08
07
06
05
04
03
02
01
33
REPLACEMENT PARTS (ref. pages 4 & 5)
Not all components of the tool are replacement items, but are illustrated as a convenient reference of location and
position in the assembly sequence. When ordering parts, please give the Model number, part number and parts
description. Call or write for current pricing: SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153, U.S.A.
E-Mail: [e-mail] Tel: [phone] Fax: [phone]
Item No. Part No. Description Qty.
1 - Screw 8
2 - Hammer Housing 1
3 - Anvil Bushing 1
4 * O-Ring 1
5 * Socket Retainer 1
6 * Retainer O-Ring 1
7 -
1/2” Anvil 1
3/8” Anvil 1
8 - Hammer Pin 2
9 - Hammer Cage 1
10 - Hammer Dog 2
11 - Motor Housing 1
12 208012 Trigger 1
13 * Throttle Bushing 1
14 * Valve Stem 1
15 - Spring 1
16 - Exhaust Deector 1
17 - Inlet Bushing 1
Item No. Part No. Description Qty.
18 - Ball Bearing 2
19 - Front Plate 1
20 - Cylinder 1
21 - Cylinder Pin 1
22 - Rotor 1
23 * Rotor Blade 6
24 - Rear Plate 1
25 * Gasket 1
26 - Housing Cap 1
27 * O-Ring 1
28 - Reverse Valve 1
29 * Spring 1
30 * Steel Ball 1
31 * Retainer 1
32 - Grip 1
33 208033
Grip Assembly
(Includes # 12)
1
34 82001-99 Repair Kit *
82001 Replacement Parts:
* Signies part of repair kit.
** Installation of replacement parts may require specials skills and knowledge.
