30.0 WB technical data sheet

8.31

(211)

6.18

(157)

2.91

(74)

2.95

(75)

11.81 (300)

4.88 (124)

1.1 (28)

Dimensions WxDxH inches (mm) Wt lbs (kg)

Product Box

TBD TBD

Master Carton

TBD TBD

05052010

800.MOUNT.IT (800.668.6848)

OmniMount, an innovator of A/V mounts and

furniture for more than a quarter century, is the

choice of professional installers and the brand most

recommended by ﬂat panel manufacturers. The

Stainless Steel Series is our patented top-of-the-line

speaker mounting solution which combines

quality, durability and ease-of-installation. The

30.0 WB is the proven choice for mounting

bookshelf speakers up to 30 lbs (13.6 kg) with

a wall-to-bottom or wall-to-top connection.

Product Speciﬁcations

Fits most: Bookshelf speakers

Supports up to: 30 lbs (13.6 kg)

Pan: 180º

Color: Black and White

Product Beneﬁts

• Polymer-injected ball controls resonance

frequencies for better sound

• Ball and clamp design for greater mounting ﬂexibility

• Includes clamp and jaw

• Connects from wall to bottom or top of eclosure

• Provides a wide range of horizontal and vertical movement

• Stainless steel hardware for strength and durability

• Suitable for all-weather use

• Includes complete hardware kit

Color Stock Code Packaging UPC MC UPC

Americas

Black 724114IFK 728901007217 728901700705

International

Black NA NA NA

Americas

White 724124IFK 728901007538 728901700781

International

White NA NA NA

Box Contents Qty

Wall bracket 1

Ball shaft 1

Polymer ball 1

Plastic cover 1

Box Contents Qty

Clamp assembly 1

Complete installation hardware kit 1

Instruction manual 1
