4.0 LED INDICATORS
4.1 Media Converter Modules
The Media Converter Modules have LED indicators to provide information
on how the module is communicating to its link partner. The LED indicators
can also be used to troubleshoot problems with the connections.
Media Converter Module
LED Function Color OFF State ON State
Power "Pwr" Yellow No Power On: Module has power
Fiber "FDX" Green Fiber in Half Duplex On: Fiber in Full Duplex
Fiber "Lk Act" Green No Fiber Link On: Fiber Link is Active
Blinking: Data Activity
UTP "AN" Green UTP is in Manual
Negotiation
On: UTP has Auto-Negotiation
Enabled.
UTP "100" Green UTP not Linked at
100Mbps
On: UTP Linked at 100Mbps
UTP "10" Green UTP not Linked at
10Mbps
On: UTP Linked at 10Mbps
UTP " FDX" Green UTP in Half Duplex On: UTP in Full Duplex
UTP "Lk Act" Green No UTP Link On: UTP Link is Active
Blinking: Data Activity
Media Converter Module LED Indicators
