20 Switch Mode Power Supply S8VS
Note: The illustration is the S8VS-24024A Model.
■ DIN Rail (Order Separately)
Note: All units are in millimeters unless otherwise indicated.
Mounting Rail (Material: Aluminum)
Mounting Rail (Material: Aluminum)
End Plate
125.3
120.3
34.9
10
50
94
100
115
Seven, M4
with square washer
Track stopper
4.5 (Sliding: 15 max.)
S8VS-24024 (240-W)
S8VS-24024@@ (240-W)
Track stopper
4.5
15 25 25
10 10
1,000 (500) *
25 25 15(5) *
35
±
0.3
7.3
±
0.15
27
±
0.15
1
*Values in parentheses
are for the PFP-50N.
PFP-100N
PFP-50N
4.5
15 25 25
10 10
1,000
25 25 15
1 1.5
29.2242735
±
0.3
16
PFP-100N2
1.3
4.8
35.5
35.5
1.8
1.8
10
6.2
1
50
11.5
10
PFP-M
M4 spring washer
M4×8 pan-
head screw
