INSTRUCTION MANUAL Pedometer Model: HJ-329 ENGLISH Alvita Ultimate
TABLE OF CONTENTS Before using the Monitor Introduction ........................................................................................................... 3 Important Safety Information ................................................................................ 4 Operating the Device .......................................................................... 4 Operating Instructions Know Your Unit ..................................................................................................
INTRODUCTION Thank you for purchasing the OMRON HJ-329 Pedometer. Fill-in for future reference DATE PURCHASED: ___________ • Staple your purchase receipt here • Register your product online at www.register-omron.com This Pedometer features advanced 3D Smart Sensor technology - so it knows exactly when you’re taking a step. It’s more accurate than other pedometers which use a simple pendulum design. Use this in your pocket, bag or on your hip for added convenience.
IMPORTANT SAFETY INFORMATION To assure the correct use of the product basic safety measures should always be followed including the warnings and cautions listed in this instruction manual. SAFETY SYMBOLS USED IN THIS INSTRUCTION MANUAL WARNING Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
KNOW YOUR UNIT Front of unit Display Low battery indicator /▼ button / ● button / ▲button NOTE: Remove the protective film from the face of the unit.
KNOW YOUR UNIT Components Strap and Clip How to attach How to connect How to release and the strap to the the strap and fasten with a clip main unit the clip Create a loop to attach the strap. To release To fasten Holder Attach/remove the holder as illustrated below.
OPTIONAL STRIDE LENGTH MEASUREMENT This pedometer contains a feature to calculate your walking stride, if you would like to adjust it, please follow these instructions. How to measure your stride length 1. Walk 10 steps with your normal stride as illustrated below. 2. Measure the distance from START to END in inches. 3. Calculate your stride length by dividing the total distance by 10.
SETTINGS The unit comes with the battery installed. When you use the unit for the first time, follow the steps below. For setting range details refer to “SPECIFICATIONS”. NOTE: If the initial settings are not correct, the measurement results may not be accurate. 1. Press and hold any button for 2 seconds. After “HELLO” has been displayed, “lb” and “kg” flash on the display. 2. Setting the weight units. A) Press or to select the mode. B) Press to confirm the setting. 3.
USING THE UNIT The unit accurately counts in a pocket, bag or anywhere you want to put it. The unit may be placed in the upper front pocket of your clothing, in the front pocket of your pants, in a bag, or attached to your belt or pants. Simply bring the unit with you wherever you go. NOTE: In order to avoid counting steps that are not part of a walk, the unit does not display the step count for the first 4 seconds of walking.
READING THE CURRENT DISPLAY Press to view the various measurements. Step count display Distance display Calories display Aerobic steps display Calories By measuring the intensity of your activity, the unit can calculate the amount of calories burned. Aerobic steps Aerobic steps are the physical exercise that helps us stay healthy. Aerobic steps are counted separately when walking more than 60 steps per minute and more than 10 minutes successively.
MEMORY FUNCTION The unit stores up to 7 days of data on the unit. The current day’s data is automatically stored in memory when the time reaches 12:00 AM (0:00). The display will return to 0. NOTE: The time must be correctly set in the unit. 1. Press to select the type of measurement you want to see (steps, distance, etc.). 2. Press to view the results (days 1-7) in memory. The display changes with each press of as shown below.
BATTERY LIFE Low battery indicator When the low battery indicator appears on the display, immediately replace the battery with a new CR2032 battery. Blinking Appears continuously Battery power is low. Battery power exhausted. The unit stops measurement. NOTES: • Do not remove the battery around 12:00 AM. The measurement results of the day when the battery was removed will be added to the measurement results for the day the battery was inserted.
BATTERY REPLACEMENT 1. To unlock the battery cover move the lock to the left. Then pull the cover off by pulling it away from the unit. 2. Remove the battery with a toothpick. NOTE: Do not use any type of metal object to remove the battery. CAUTION Dispose of the device, battery, and components according to applicable local regulations. Unlawful disposal may cause environmental pollution. CAUTION Do not throw the battery into fire. The battery may explode. 3.
DELETING ALL RESULTS AND SETTINGS Follow the procedure below to delete all the previous measurement results and settings, including the time, weight, height, and stride length. 1. Press and hold and at the same time. “lb” or “kg” flashes on the display. 2. Press and hold and at the same time again. After “Clr” has been displayed, “lb” and “kg” flash on the display. The measurement results stored in memory and the settings for the time, weight, height and stride length are deleted.
CARE AND MAINTENANCE To keep the unit in the best condition and protect the unit from damage follow the directions listed below: CAUTION Do not disassemble or modify the unit. Changes or modifications not approved by Omron Healthcare will void the user warranty. Clean the unit with a soft dry cloth. Do not use any abrasive or volatile cleaners. Do not immerse the unit or any of the components in water. The unit is not waterproof. Do not wash it or touch it with wet hands.
TROUBLESHOOTING TIPS Problem The low battery indicator blinks or appears continuously. Nothing is displayed. Probable Cause The battery is low or worn. Replace the battery with a new one (CR2032), refer to “BATTERY REPLACEMENT”. Battery saving mode active. Press either of , or , refer to “The battery saving mode” in “READING THE CURRENT DISPLAY”. The polarities of the battery (+ and -) are aligned in the wrong directions. Insert the battery in correct alignement, refer to “BATTERY REPLACEMENT”.
SPECIFICATIONS Model: HJ-329 Product Name Alvita Ultimate Power Supply: 3VDC (1 lithium battery CR2032) Measurement Range: Steps: Distance: Calories: Aerobic steps: Time: 0 to 99,999 steps 0.0 to 621.3 miles / 0.0 to 999.
FCC STATEMENT NOTE: POTENTIAL FOR RADIO/TELEVISION INTERFERENCE (for U.S.A. only) This product has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
LIMITED WARRANTY Your OMRON HJ-329 Pedometer, excluding the battery, is warranted to be free from defects in materials and workmanship appearing within 1 year from the date of purchase, when used in accordance with the instructions provided with the unit. The above warranties extend only to the original retail purchaser. We will, at our option, repair or replace without charge any Pedometer covered by the above warranties.
DISTRIBUTED BY: OMRON HEALTHCARE, INC. 1925 West Field Court Lake Forest, IL 60045 U.S.A. www.omronhealthcare.com © 2014 OMRON HEALTHCARE, INC.
