FDMF6823A — Extra-Small, High-Performance, High-Frequency DrMOS Module
Electrical Characteristics
Typical values are V
IN
= 12 V, V
CIN
= 5 V, V
DRV
= 5 V, and T
A
= T
J
= +25°C unless otherwise noted.
Symbol Parameter Condition Min. Typ. Max. Unit
Basic Operation
I
Q
Quiescent Current I
Q
=I
VCIN
+I
VDRV
, PWM=LOW or HIGH or Float 2 mA
V
UVLO
UVLO Threshold V
CIN
Rising 2.9 3.1 3.3 V
V
UVLO_Hys
UVLO Hysteresis 0.4 V
PWM Input (V
CIN
= V
DRV
= 5 V ±10%)
R
UP_PWM
Pull-Up Impedance
V
PWM
=5 V
10 kΩ
R
DN_PWM
Pull-Down Impedance
V
PWM
=0 V
10 kΩ
V
IH_PWM
PWM High Level Voltage 3.04 3.55 4.05 V
V
TRI_HI
3-State Upper Threshold 2.95 3.45 3.94 V
V
TRI_LO
3-State Lower Threshold 0.98 1.25 1.52 V
V
IL_PWM
PWM Low Level Voltage 0.84 1.15 1.42 V
t
D_HOLD-OFF
3-State Shut-Off Time 160 200 ns
V
HiZ_PWM
3-State Open Voltage 2.20 2.50 2.80 V
t
PWM-OFF_MIN
PWM Minimum Off Time 120 ns
PWM Input (V
CIN
= V
DRV
= 5 V ±5%)
R
UP_PWM
Pull-Up Impedance
V
PWM
=5 V
10 kΩ
R
DN_PWM
Pull-Down Impedance
V
PWM
=0 V
10 kΩ
V
IH_PWM
PWM High Level Voltage 3.22 3.55 3.87 V
V
TRI_HI
3-State Upper Threshold 3.13 3.45 3.77 V
V
TRI_LO
3-State Lower Threshold 1.04 1.25 1.46 V
V
IL_PWM
PWM Low Level Voltage 0.90 1.15 1.36 V
t
D_HOLD-OFF
3-State Shut-Off Time 160 200 ns
V
HiZ_PWM
3-State Open Voltage 2.30 2.50 2.70 V
t
PWM-OFF_MIN
PWM Minimum Off Time 120 ns
DISB# Input
V
IH_DISB
High-Level Input Voltage 2 V
V
IL_DISB
Low-Level Input Voltage 0.8 V
I
PLD
Pull-Down Current 10 µA
t
PD_DISBL
Propagation Delay
PWM=GND, Delay Between DISB# from
HIGH to LOW to GL from HIGH to LOW
25 ns
t
PD_DISBH
Propagation Delay
PWM=GND, Delay Between DISB# from
LOW to HIGH to GL from LOW to HIGH
25 ns
SMOD# Input
V
IH_SMOD
High-Level Input Voltage 2 V
V
IL_SMOD
Low-Level Input Voltage 0.8 V
I
PLU
Pull-Up Current 10 µA
t
PD_SLGLL
Propagation Delay
PWM=GND, Delay Between SMOD# from
HIGH to LOW to GL from HIGH to LOW
10 ns
t
PD_SHGLH
Propagation Delay
PWM=GND, Delay Between SMOD# from
LOW to HIGH to GL from LOW to HIGH
10 ns
Continued on the following page…
