HT-S790_En.book Page 1 Friday, February 17, 2006 3:28 PM Contents Introduction ..................................... 2 7.1ch Home Theater System HT-S790 AV Receiver (HT-R540) Front Speakers (SKF-540F) Center Speaker (SKC-540C) Surround Speakers (SKM-540S) Surround Back Speakers (SKB-540) Powered Subwoofer (SKW-540) Instruction Manual Connection .................................... 19 Turning On & First Time Setup..... 34 Basic Operation Playing your AV components ....... 36 Listening to the Radio ...
HT-S790_En.book Page 2 Friday, February 17, 2006 3:28 PM WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
HT-S790_En.book Page 3 Friday, February 17, 2006 3:28 PM Precautions 1. Recording Copyright—Unless it’s for personal use only, recording copyrighted material is illegal without the permission of the copyright holder. 2. AC Fuse—The AC fuse inside the unit is not userserviceable. If you cannot turn on the unit, contact your Onkyo dealer. 3. Care—Occasionally you should dust the unit all over with a soft cloth. For stubborn stains, use a soft cloth dampened with a weak solution of mild detergent and water.
HT-S790_En.book Page 4 Friday, February 17, 2006 3:28 PM Speaker Precautions Placement Input Signal Warning • The speaker cabinets are made out of wood and are therefore sensitive to extreme temperatures and humidity, do not put them in locations subject to direct sunlight or in humid places, such as near an air conditioner, humidifier, bathroom, or kitchen. • Do not put water or other liquids close to the speakers. If liquid is spilled over the speakers, the drive units may be damaged.
HT-S790_En.book Page 5 Friday, February 17, 2006 3:28 PM Enjoying Home Theater Speaker Sets A and B You can use two sets of speakers with the AV receiver: speaker set A and speaker set B. Speaker set A (included speakers) should be used in your main listening room for up to 7.1-channel playback. *While speaker set B is on, speaker set A is reduced to 5.1-channel playback. Speaker set B (not included) can be used in another room and offers 2-channel stereo playback.
HT-S790_En.book Page 6 Friday, February 17, 2006 3:28 PM Package Contents Make sure you have the following items: AV receiver (HT-R540) Subwoofer (SKW-540) (Red) Remote controller & two batteries (AA/R6) (White) Speaker cable for front speakers 15 ft. (4.5 m) Indoor FM antenna (Green) Speaker cable for center speaker 10 ft. (3 m) AM loop antenna (Blue) (Gray) (Brown) (Tan) Speaker cables for surround speakers 30 ft. (9 m) Front speakers (SKF-540F) RCA cable for subwoofer connection 10 ft.
HT-S790_En.book Page 7 Friday, February 17, 2006 3:28 PM Features Amplifier • 7-channel amplifier • 110 watts per channel rms into 8 ohms, 2 channels driven at 1 kHz, less than 0.9% total harmonic distortion (FTC rating) • WRAT (Wide Range Amplifier Technology) • Optimum Gain Volume Circuitry • OR-EQ (OptiResponse Equalizer)*1 function *1 OptiResponse, and OR-EQ are trademarks of Onkyo Corporation. *2 Manufactured under license from Dolby Laboratories.
HT-S790_En.book Page 8 Friday, February 17, 2006 3:28 PM Getting Started in Five Easy Steps 1. Hookup Connect the AV receiver to your AV system.
HT-S790_En.book Page 9 Friday, February 17, 2006 3:28 PM Contents Introduction Basic Operation Important Safety Instructions ....................2 Precautions .................................................3 Speaker Precautions ..................................4 Playing Your AV Components ................ 36 Enjoying Home Theater ..............................5 Listening to the Radio.............................. 38 Speaker Sets A and B ...................................5 Package Contents ......
HT-S790_En.
HT-S790_En.book Page 11 Friday, February 17, 2006 3:28 PM Getting to Know the AV Receiver—Continued J TONE, [–], and [+] buttons (44) Q TUNING MODE button (38) Used to adjust the bass and treble. Selects the Auto or Manual tuning mode for AM and FM radio. K STEREO button (46) R RETURN button Selects the Stereo listening mode. Selects the previously displayed setup menu. L LISTENING MODE [ ]/[ ] buttons (46) S SETUP button Select the listening modes. Used to access the setup menus.
HT-S790_En.book Page 12 Friday, February 17, 2006 3:28 PM Getting to Know the AV Receiver—Continued Rear Panel B (North American model only) 3 4 5 6 1 XM ANTENNA SURROUND BACK SPEAKERS AM DIGITAL IN COMPONENT VIDEO VIDEO 2 IN VIDEO 1 IN 7 DVD IN SURROUND SPEAKERS FRONT SPEAKERS A CENTER SPEAKER FM 75 L L R R OUT COA XIAL Y VIDEO 2 VIDEO 1 DVD OPTICAL 1 PB V 2 PR S IN OUT IN IN IN OUT IN FRONT MONITOR OUT AC OUTLET AC 120V 60Hz SWITCHED TOTAL 120W 1A MAX.
HT-S790_En.book Page 13 Friday, February 17, 2006 3:28 PM Remote Controller Installing the Batteries 1 To open the battery compartment, press the small hollow and slide open the cover. Aiming the Remote Controller When using the remote controller, point it toward the AV receiver’s remote control sensor, as shown below. Remote control sensor AV receiver STANDBY indicator 2 3 Insert the two supplied batteries (AA/R6) in accordance with the polarity diagram inside the battery compartment.
HT-S790_En.book Page 14 Friday, February 17, 2006 3:28 PM Remote Controller—Continued Using the Remote Controller RECEIVER/TAPE Mode Including the AV receiver, the remote controller can be used to control up to seven different components. The remote controller has a specific operating mode for use with each type of component. Modes are selected by using the six REMOTE MODE buttons. ■ RECEIVER/TAPE Mode In RECEIVER/TAPE mode, you can control the AV receiver and an Onkyo cassette recorder connected via .
HT-S790_En.book Page 15 Friday, February 17, 2006 3:28 PM Remote Controller—Continued For detailed information, see the pages in parentheses. A ON/STANDBY button (34) Sets the AV receiver to On or Standby. B INPUT SELECTOR buttons (36) Used to select the input sources. C MULTI CH button (37) P SETUP button Used to access the setup menus. Q CINE FLTR button (50) Used with the CinemaFILTER function. R L NIGHT button (50) Used with the Late Night function. Selects the multichannel DVD input.
HT-S790_En.book Page 16 Friday, February 17, 2006 3:28 PM Remote Controller—Continued A ON/STANDBY button DVD Mode Sets the DVD player to On or Standby. By default, the remote controller is set to control an Onkyo DVD player. To select your DVD player as the input source, press: RECEIVER or 6 DVD B Number buttons Used to enter title, chapter, and track numbers and times for locating specific points. C DISC +/– button Selects discs on a DVD changer.
HT-S790_En.book Page 17 Friday, February 17, 2006 3:28 PM Remote Controller—Continued A ON/STANDBY button CD/MD/CDR/HDD Mode Sets the component to On or Standby. By default, the remote controller is set to control an Onkyo CD player. To select the input source, press: 9 Selects discs on a CD changer, or the next or previous album on an HDD-compatible component.
HT-S790_En.book Page 18 Friday, February 17, 2006 3:28 PM Speakers Subwoofer (SKW-540) For detailed information, see the pages in parentheses. A STANDBY/ON indicator ■ Front Red: Subwoofer in standby mode Green: Subwoofer on With the Auto Standby function, the SKW-540 automatically turns on when an input signal is detected in Standby mode. When there’s no input signal for a while, the SKW-540 automatically enters Standby mode.
HT-S790_En.book Page 19 Friday, February 17, 2006 3:28 PM Connecting Your Speakers Speaker Connection Precautions Connecting Speaker Set A Read the following before connecting your speakers: • You can connect speakers with an impedance of 8 ohms or higher. If you use speakers with a lower impedance, and use the amplifier at high volume levels for a long period of time, the built-in protection circuit may be activated. • Disconnect the power cord from the wall outlet before making any connections.
HT-S790_En.book Page 20 Friday, February 17, 2006 3:28 PM Connecting Antennas This section explains how to connect the supplied indoor FM antenna and AM loop antenna, and how to connect commercially available outdoor FM and AM antennas. The AV receiver won’t pick up any radio signals without any antenna connected, so you must connect the antenna to use the tuner.
HT-S790_En.book Page 21 Friday, February 17, 2006 3:28 PM Connecting Antennas—Continued Connecting an Outdoor FM Antenna Connecting an Outdoor AM Antenna If you cannot achieve good reception with the supplied indoor FM antenna, try a commercially available outdoor FM antenna instead. If good reception cannot be achieved using the supplied AM loop antenna, an outdoor AM antenna can be used in addition to the loop antenna, as shown.
HT-S790_En.book Page 22 Friday, February 17, 2006 3:28 PM Connecting Your Components AV Connection Color Coding About AV Connections RCA-type AV connections are usually color coded: red, white, and yellow. Use red plugs to connect right-channel audio inputs and outputs (typically labeled “R”). Use white plugs to connect left-channel audio inputs and outputs (typically labeled “L”). And use yellow plugs to connect composite video inputs and outputs.
HT-S790_En.book Page 23 Friday, February 17, 2006 3:28 PM Connecting Your Components—Continued Connecting Audio and Video Signals to the AV Receiver By connecting both the audio and video outputs of your DVD player and other AV components to the AV receiver, you can switch the audio and video signals simultaneously simply by changing the input source on the AV receiver. : Signal Flow Video Video Audio Audio TV, projector, etc. Speakers (see page 19 for hookup details) DVD player, etc.
HT-S790_En.book Page 24 Friday, February 17, 2006 3:28 PM Connecting Your Components—Continued Connecting a TV or Projector Step 1: Video Connection Choose a video connection that matches your TV ( A , B , or C ), and then make the connection. Step 2: Audio Connection Choose an audio connection that matches your TV ( a , b , or c ), and then make the connection. • With connection a , you can listen to and record audio from your TV and listen via speaker set B.
HT-S790_En.book Page 25 Friday, February 17, 2006 3:28 PM Connecting Your Components—Continued Connecting a DVD player Step 1: Video Connection Choose a video connection that matches your DVD player ( A , B , or C ), and then make the connection. You must connect the AV receiver to your TV via the same type of connection. Step 2: Audio Connection Choose an audio connection that matches your DVD player ( a , b , or c ), and then make the connection.
HT-S790_En.book Page 26 Friday, February 17, 2006 3:28 PM Connecting Your Components—Continued Hooking Up the Multichannel DVD Input If your DVD player supports multichannel audio formats such as DVD-Audio or SACD, and it has a multichannel analog audio output, you can connect it to the AV receiver’s multichannel DVD input. Use a multichannel analog audio cable, or several normal audio cables, to connect the AV receiver’s DVD IN FRONT L/R, CENTER, SURROUND L/R, SURR BACK L/R, and SUBWOOFER jacks to the 7.
HT-S790_En.book Page 27 Friday, February 17, 2006 3:28 PM Connecting Your Components—Continued Connecting a VCR or DVD Recorder for Playback Hint! With this hookup, you can use your VCR’s tuner to listen to your favorite TV programs via the AV receiver, useful if your TV has no audio outputs. Step 1: Video Connection Choose a video connection that matches your VCR or DVD recorder ( A , B , or C ), and then make the connection. You must connect the AV receiver to your TV via the same type of connection.
HT-S790_En.book Page 28 Friday, February 17, 2006 3:28 PM Connecting Your Components—Continued Connecting a VCR or DVD Recorder for Recording Step 1: Choose a video connection that matches your VCR or DVD recorder ( A or B ), and then make the connection. The video source to be recorded must be connected to the AV receiver via the same type of connection. Step 2: Make the audio connection a .
HT-S790_En.book Page 29 Friday, February 17, 2006 3:28 PM Connecting Your Components—Continued Connecting a Satellite, Cable, Set-top box, or Other Video Source Hint! With this hookup, you can use your satellite or cable receiver to listen to your favorite TV programs via the AV receiver, useful if your TV has no audio outputs. Step 1: Video Connection Choose a video connection that matches the video source ( A , B , or C ), and then make the connection.
HT-S790_En.book Page 30 Friday, February 17, 2006 3:28 PM Connecting Your Components—Continued Connecting a CD Player or Turntable ■ CD Player or Turntable (MM) with Built-in Phono Preamp Step 1: Choose a connection that matches your CD player ( a , b , or c ). Use connection a for a turntable with a built-in phono preamp.
HT-S790_En.book Page 31 Friday, February 17, 2006 3:28 PM Connecting Your Components—Continued Connecting an HDD-compatible Component As of this printing, the Onkyo Remote Interactive Dock is the only HDD-compatible component available. ■ For HDD-compatible components that don’t support video Connect your HDD-compatible component’s analog audio output jacks to the AV receiver’s TAPE IN L/R jacks.
HT-S790_En.book Page 32 Friday, February 17, 2006 3:28 PM Connecting Your Components—Continued Connecting a Cassette, CDR, MiniDisc, or DAT Recorder Step 1: Choose a connection that matches the recorder ( a , b , or c ), and then make the connection.
HT-S790_En.book Page 33 Friday, February 17, 2006 3:28 PM Connecting Your Components—Continued Connecting Onkyo Components Step 1: Make sure that each Onkyo component is connected to the AV receiver with an analog audio cable (connection a in the hookup examples) (see pages 24 to 32). Step 2: Make the connection. Step 3: If you’re using an MD, CDR, or HDD component, change the input Display (see page 35).
HT-S790_En.
HT-S790_En.book Page 35 Friday, February 17, 2006 3:28 PM First Time Setup Assigning Digital Inputs to Input Sources 1 Changing the Input Display If you connect an -capable Onkyo MiniDisc recorder, CD recorder or next generation HDD-compatible component to the TAPE IN/OUT or VIDEO 2 IN jacks, for to work properly, you must change this setting. This setting can only be changed on the AV receiver.
HT-S790_En.
HT-S790_En.book Page 37 Friday, February 17, 2006 3:28 PM Playing Your AV Components—Continued Displaying Source Information ON/STANDBY REMOTE MODE DVD RECEIVER TAPE INPUT SELECTOR RECEIVER M D/CDR 1 2 3 V1 V2 V3 You can display various information about the current input source as follows.
HT-S790_En.book Page 38 Friday, February 17, 2006 3:28 PM Listening to the Radio Tuning into AM/FM Radio Stations Listening to AM/FM stations ■ Auto Tuning Mode TUNER TUNING 1 TUNING MODE MASTER VOLUME TUNING PRESET STANDBY/ON STANDBY Press the [TUNING MODE] button so that the AUTO indicator appears on the display.
HT-S790_En.book Page 39 Friday, February 17, 2006 3:28 PM Listening to the Radio—Continued ■ Tuning into Stations by Frequency You can tune into AM and FM stations directly by entering the appropriate frequency. ON/STANDBY Press the [MEMORY] button. The MEMORY indicator appears and the preset number flashes.
HT-S790_En.book Page 40 Friday, February 17, 2006 3:28 PM Listening to the Radio—Continued Listening to XM Satellite Radio® (North American Models Only) Important XM Radio Information To receive XM Radio on this receiver you need to purchase an optional XM Passport System and subscribe to XM’s paid programming. Please note that XM is currently only licensed to provide service to the contiguous 48 United States (not available in Alaska and Hawaii) and portions of Canada.
HT-S790_En.book Page 41 Friday, February 17, 2006 3:28 PM Listening to the Radio—Continued Signing Up for XM Satellite Radio Before you can use XM Satellite Radio, you must first sign up for an account. You’ll need a major credit card and your XM Satellite Radio ID, which you can get from the AV receiver, as explained below, or from the Passport System package and itself. 1 TUNING PRESET Use the TUNING Up and Down [ ]/[ ] buttons to select channel 0. Your XM Satellite Radio ID number is displayed.
HT-S790_En.
HT-S790_En.book Page 43 Friday, February 17, 2006 3:28 PM Listening to the Radio—Continued ENTER XM Radio Messages TUNING The following messages may appear while using XM radio.
HT-S790_En.book Page 44 Friday, February 17, 2006 3:28 PM Common Functions This section explains functions that can be used with any input source. ON/STANDBY REMOTE MODE Press [RECEIVER] first DVD RECEIVER TAPE INPUT SELECTOR M D/CDR 1 2 3 CD V1 V2 V3 HDD 4 5 6 MULTI CH DVD 7 8 TAPE DIMMER +10 0 --/--- DIMMER 12 SLEEP SAT ENT TV SLEEP CH VOL TONE Press the AV receiver’s [TONE] button repeatedly to select either Bass or Treble.
HT-S790_En.book Page 45 Friday, February 17, 2006 3:28 PM Common Functions—Continued Using the Sleep Timer Adjusting Speaker Levels With the sleep timer, you can set the AV receiver so that it turns off automatically after a specified period. SLEEP Press the remote controller’s [SLEEP] button repeatedly to select the required sleep time. You can set the sleep time from 90 to 10 minutes in 10 minute steps. The SLEEP indicator appears on the display when the sleep timer has been set, as shown.
HT-S790_En.book Page 46 Friday, February 17, 2006 3:28 PM Using the Listening Modes Selecting with the Remote Controller Selecting Listening Modes TV For a description of each listening mode, see “About the Listening Modes” on page 48. • While a pair of headphones is connected, you can select only the Pure Audio (not North American model), Mono, Direct, or Stereo listening mode.
HT-S790_En.book Page 47 Friday, February 17, 2006 3:28 PM Using the Listening Modes—Continued The following table shows which listening modes can be used with each input signal format. Source format 3/2.1 2/2.1 CD, TV, radio, cassette, etc. Listening mode DTS/DTS 96/24*2 Dolby Digital Analog, PCM*1 2/0 1/0, 1+1 Other 3/2.1 2/2.1 DVD, DTV, etc. DTS-ES 2/0 Discrete Matrix DVD, CD, etc.
HT-S790_En.book Page 48 Friday, February 17, 2006 3:28 PM Using the Listening Modes—Continued About the Listening Modes The AV receiver’s listening modes can transform your listening room into a movie theater or concert hall, with high fidelity and stunning surround sound. The illustration shows which speakers are active in each listening mode with 7.1 channel speaker system.
HT-S790_En.book Page 49 Friday, February 17, 2006 3:28 PM Using the Listening Modes—Continued DTS-ES Matrix This mode is for use with DTS-ES Matrix soundtracks, which use a matrix-encoded back-channel for 6.1/7.1-channel playback. Use it with DVDs that bear the DTS-ES logo, especially those with a DTS-ES Matrix soundtrack. Onkyo Original DSP Modes Mono Movie This mode is suitable for old movies and other mono sources.
HT-S790_En.
HT-S790_En.book Page 51 Friday, February 17, 2006 3:28 PM Using the Listening Modes—Continued 4 Press the [SETUP] button. Setup closes. SETUP The Audio Adjust settings are explained below. Input Channel Settings ■ Multiplex This setting determines which channel is output from a stereo multiplex source. Use it to select audio channels or languages with multiplex sources, multilingual TV broadcasts, and so on. Main: The main channel is output (default). Sub: The sub channel is output.
HT-S790_En.book Page 52 Friday, February 17, 2006 3:28 PM Advanced Setup Advanced Speaker Settings ON/STANDBY 3 Use the Up and Down [ ]/[ ] buttons to select “2. SP Distance,” and then press the [ENTER] button. 4 While “Unit” is displayed, use the Left and Right [ ]/[ ] buttons to select “feet” or “meters”. feet: Distances in feet. Can be set from 1 to 30 feet in 1-foot steps. meters: Distances in meters. Can be set from 0.3 to 9 meters in 0.3-meter steps.
HT-S790_En.book Page 53 Friday, February 17, 2006 3:28 PM Advanced Setup—Continued Speaker Levels With this function, you can adjust the volume of each speaker so that all speakers can be heard equally at the listening position. The speaker levels cannot be adjusted while a pair of headphones is connected, speaker set B is on, or the AV receiver is muted. 1 RECEIVER Press the [RECEIVER] button followed by the [SETUP] button on the remote controller.
HT-S790_En.book Page 54 Friday, February 17, 2006 3:28 PM Advanced Setup—Continued Speaker Configuration, Crossover Frequency, and Double Bass settings only need to be changed if you’re not using the speakers in this package. These settings cannot be changed while headphones are connected, speaker set B is on, or the multichannel DVD input is being used. 4 Note: • If the Subwoofer setting in step 3 is set to No, this setting is fixed at Large and does not appear.
HT-S790_En.book Page 55 Friday, February 17, 2006 3:28 PM Advanced Setup—Continued 7 8 Use the Down [ ] button to select “Surr Back,” and use the Left and Right [ ]/[ ] buttons to select Small, Large, or None. Small: Select if the surround back speakers are small. Large: Select if the surround back speakers are large. None: Select if no surround back speakers are connected. Notes: • If the Surround setting in step 6 is set to None, this setting does not appear.
HT-S790_En.book Page 56 Friday, February 17, 2006 3:28 PM Advanced Setup—Continued Digital Input Signal Formats Correcting Sound and Picture Sync The following table shows the display indicator for each digital signal format. Format Display Dolby Digital When using progressive scanning on your DVD player, you may find that the picture and sound are out of sync. With this setting, you can correct this by delaying the audio signals. You can set it from 0 to 100 milliseconds (ms) in 20 millisecond steps.
HT-S790_En.book Page 57 Friday, February 17, 2006 3:28 PM Recording This section explains how to record the selected input source to a component with recording capability, and how to record audio and video from different sources. Recording the Input Source You can only record to a component that’s connected to the TAPE OUT or VIDEO 1 OUT jacks. See pages 22–33 for information on connecting your AV components.
HT-S790_En.book Page 58 Friday, February 17, 2006 3:28 PM Controlling Other Components You can use the AV receiver’s remote controller (RC-649M) to control your other AV components, including those made by other manufacturers. This section explains how to enter the necessary remote control code for the component that you want to control (e.g., DVD player, TV, or VCR). 2 REMOTE MODE DVD M D/CDR CD While holding down the REMOTE MODE button that you want to set, press the [DISPLAY] button for 3 seconds.
HT-S790_En.book Page 59 Friday, February 17, 2006 3:28 PM Controlling Other Components—Continued Remote Control Codes for Onkyo Components Connected via Onkyo components that are connected via are controlled by pointing the remote controller at the AV receiver, not the component. This allows you to control components that are out of view, in a rack, for example. Resetting REMOTE MODE Buttons You can reset a REMOTE MODE button to its default remote control code.
HT-S790_En.book Page 60 Friday, February 17, 2006 3:28 PM Controlling Other Components—Continued To control another component, point the remote controller at it and use the buttons explained below. (You must select the appropriate remote control mode first.) With some AV components, certain buttons may not work as expected, and some may not work at all.
HT-S790_En.book Page 61 Friday, February 17, 2006 3:28 PM Troubleshooting If you have any trouble using the 7.1ch Home Theater System, look for a solution in this section. If you can’t resolve the issue yourself, try resetting the AV receiver before contacting your Onkyo dealer. To reset the AV receiver to its factory defaults, turn it on and, while holding down the [VIDEO 1] button, press the [STANDBY/ON] button. “Clear” will appear on the display and the AV receiver will enter Standby mode.
HT-S790_En.book Page 62 Friday, February 17, 2006 3:28 PM Troubleshooting—Continued • The surround back speakers are not used with all listening modes. Select another listening mode (page 48). • Not much sound may be produced by the surround back speakers with some sources. • Make sure the speakers are configured correctly (page 54). The subwoofer produces no sound • The level of the input signal was too low so the subwoofer entered Standby mode. Increase the subwoofer level slightly on the HT-R540.
HT-S790_En.book Page 63 Friday, February 17, 2006 3:28 PM Troubleshooting—Continued Tuner Reception is noisy, stereo FM reception suffers from hiss, or the FM STEREO indicator doesn’t appear • Relocate your antenna. • Move the AV receiver away from your TV or computer. • Listen to the station in mono (page 38). • When listening to an AM station, operating the remote controller may cause noise. • Passing cars and airplanes can cause interference. • Concrete walls weaken radio signals.
HT-S790_En.book Page 64 Friday, February 17, 2006 3:28 PM Troubleshooting—Continued The AV receiver contains a microcomputer for signal processing and control functions. In very rare situations, severe interference, noise from an external source, or static electricity may cause it to lockup. In the unlikely event that this happens, unplug the power cord from the wall outlet, wait at least five seconds, and then plug it back in again.
HT-S790_En.book Page 65 Friday, February 17, 2006 3:28 PM Specifications Amplifier Section General Rated Output Power (FTC) All channels: 110 watts minimum continuous power per channel, 8 ohm loads, 2 channels driven at 1 kHz, with a maximum total harmonic distortion of 0.
HT-S790_En.book Page 66 Friday, February 17, 2006 3:28 PM Specifications—Continued ■ Speaker ■ Powered Subwoofer (SKW-540) ■ Center Speaker (SKC-540C) Type: Bass-reflex Input sensitivity/impedance: 330 mV / 100 kΩ Maximum output power: 230 W (Dynamic Power) Frequency response: 25 Hz–150 Hz Cabinet capacity: 1.36 cubic feet (38.5 L) Dimensions (W × H × D): 10-13/16" × 18-5/8" × 17-11/16" (275 × 473 × 449 mm) Weight: 25.4 lbs. (11.
HT-S790_En.
HT-S790_En.book Page 68 Friday, February 17, 2006 3:28 PM Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN Tel: 072-831-8023 Fax: 072-831-8124 ONKYO U.S.A. CORPORATION 18 Park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 201-785-2600 Fax: 201-785-2650 http://www.us.onkyo.com/ ONKYO EUROPE ELECTRONICS GmbH Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY Tel: +49-8142-4401-0 Fax: +49-8142-4401-555 http://www.eu.onkyo.
Remocon Codes.fm Page 1 Tuesday, March 7, 2006 9:25 AM Remote Control Codes 1. While holding down the REMOTE MODE button that you want to set, press the [DISPLAY] button for 3 seconds. 2. Use the number buttons to enter the 4-digit remote control code. REMOTE MODE DVD 1 2 3 4 5 6 7 8 9 M D/CDR CD HDD DISPLAY TV VCR 0 CABLE SAT Codes de télécommande Códigos de control remoto 1. Maintenez le bouton REMOTE MODE à initialiser enfoncé et appuyez sur le bouton [DISPLAY] durant 3 secondes.
Remocon Codes.
Remocon Codes.
Remocon Codes.
Remocon Codes.
Remocon Codes.
Remocon Codes.
Remocon Codes.
Remocon Codes.
Remocon Codes.
Remocon Codes.
Remocon Codes.fm Page 12 Tuesday, March 7, 2006 9:25 AM Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN Tel: 072-831-8023 Fax: 072-831-8124 ONKYO U.S.A. CORPORATION 18 Park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 201-785-2600 Fax: 201-785-2650 http://www.us.onkyo.com/ ONKYO EUROPE ELECTRONICS GmbH Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY Tel: +49-8142-4401-0 Fax: +49-8142-4401-555 http://www.eu.onkyo.
