HTX-22HD_En.book Page 1 Monday, April 7, 2008 2:03 PM Contents Digital Surround System HTX-22HD Instruction Manual Introduction.............................................. 2 Connections ........................................... 16 Turning On & First Time Setup ............. 30 Basic Operation Playing your AV components .................. 39 Thank you for purchasing this Onkyo product. Please read this manual thoroughly before making any connections or plugging in your new Onkyo product.
HTX-22HD_En.book Page 2 Monday, April 7, 2008 2:03 PM WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
HTX-22HD_En.book Page 3 Monday, April 7, 2008 2:03 PM Precautions 1. 2. 3. 4. Recording Copyright—Unless it’s for personal use only, recording copyrighted material is illegal without the permission of the copyright holder. AC Fuse—The AC fuse inside the unit is not userserviceable. If you cannot turn on the unit, contact your Onkyo dealer. Care—Occasionally you should dust the unit all over with a soft cloth.
HTX-22HD_En.book Page 4 Monday, April 7, 2008 2:03 PM Precautions—Continued For British models Replacement and mounting of an AC plug on the power supply cord of this unit should be performed only by qualified service personnel.
HTX-22HD_En.book Page 5 Monday, April 7, 2008 2:03 PM Speaker Precautions Placement Input Signal Warning • The subwoofer cabinet is made out of wood and is therefore sensitive to extreme temperatures and humidity, do not put it in locations subject to direct sunlight or in humid places, such as near an air conditioner, humidifier, bathroom, or kitchen. • Do not put water or other liquids close to the speakers. If liquid is spilled over the speakers, the drive units may be damaged.
HTX-22HD_En.book Page 6 Monday, April 7, 2008 2:03 PM Supplied Accessories Make sure you have the following accessories: Optical digital audio cable (5 ft., 1.5 m) HTX-22HDPAW Amp/Subwoofer Cork spacers for the Amp/Subwoofer (x4) HTX-22HDST Front Speakers Cork spacers for the front speakers (x8) * Remote controller and two batteries (AA/R6) Speaker setup microphone Red and white cables for front speakers (11.5 ft., 3.5 m) or Power cord (Use the power cord that matches your wall outlet.
HTX-22HD_En.book Page 7 Monday, April 7, 2008 2:03 PM Contents Important Safety Instructions .....................2 Precautions...................................................3 Speaker Precautions....................................5 Supplied Accessories ..................................6 Features ........................................................8 Getting to Know the HTX-22HD.................10 Front Panel ...............................................10 Display.................................
HTX-22HD_En.book Page 8 Monday, April 7, 2008 2:03 PM Features HTX-22HDPAW: 5.1-channel Amp/Subwoofer 5.1-channel power amplifier with built-in subwoofer • 2 HDMI*1 inputs, 1 output (with support for up to 1080p, Deep Color, x.v.
HTX-22HD_En.book Page 9 Monday, April 7, 2008 2:03 PM Features—Continued *1 HDMI, the HDMI logo and High Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing, LLC. *2. Manufactured under license under U.S. Patent #’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,226,616; 6,487,535 & other U.S. and worldwide patents issued & pending. DTS is a registered trademark and the DTS logos, Symbol, DTS-HD and DTS-HD Master Audio are trademarks of DTS, Inc. © 1996-2007 DTS, Inc.
HTX-22HD_En.book Page 10 Monday, April 7, 2008 2:03 PM Getting to Know the HTX-22HD Front Panel 1 2 3 4 5 6 7 A Display See “Display” on page 11. B STANDBY indicator Lights up when the HTX-22HD is on Standby and flashes while a signal is being received from the remote controller. C ON/STANDBY button Sets the HTX-22HD to On or Standby. To operate this button, push it down from the top. D Remote-control sensor Receives control signals from the remote controller.
HTX-22HD_En.book Page 11 Monday, April 7, 2008 2:03 PM Getting to Know the HTX-22HD—Continued Display 1 2 3 4 5 1 Listening mode and format indicators Show the selected listening mode and audio input signal format.
HTX-22HD_En.book Page 12 Monday, April 7, 2008 2:03 PM Getting to Know the HTX-22HD—Continued Rear Panel 1 2 6 7 8 3 4 9 J 5 A HDMI IN 1, 2, and OUT C COAXIAL DIGITAL IN HDMI (High Definition Multimedia Interface) connections carry digital audio and digital video. The HDMI inputs are for connecting components with an HDMI output, such as a DVD player, DVD recorder, or DVR (digital video recorder). They’re assignable, which means you can assign each one to an input selector to suit your setup.
HTX-22HD_En.book Page 13 Monday, April 7, 2008 2:03 PM Getting to Know the HTX-22HD—Continued F AC INLET The supplied power cord is connected here. The other end of the power cord should be connected to a suitable wall outlet. G FRONT SPEAKERS, CENTER SPEAKER, and SURROUND SPEAKERS These push terminals are for connecting the included front speakers and the optional SKS-11 center speaker and surround speakers.
HTX-22HD_En.book Page 14 Monday, April 7, 2008 2:03 PM Remote Controller Installing the Batteries 1 Open the battery compartment, as shown. Aiming the Remote Controller When using the remote controller, point it toward the HTX-22HD’s remote control sensor, as shown below. Remote control sensor STANDBY indicator Approx. 16 ft. (5 m) 2 Insert the two supplied batteries (AA/ R6) in accordance with the polarity diagram inside the battery compartment.
HTX-22HD_En.book Page 15 Monday, April 7, 2008 2:03 PM Remote Controller—Continued Using the Remote Controller These buttons are used to control the HTX-22HD. E Arrow [ ]/[ ]/[ ]/[ ] and ENTER 1 2 3 4 5 6 7 8 9 J K L M buttons Used to select and adjust settings. F VOLUME [ ]/[ ] buttons Adjust the volume of the HTX-22HD. G LISTENING MODE buttons Used to select the listening modes. H DIMMER button Adjusts the display brightness. I TEST TONE button Used with the Test Tone function.
HTX-22HD_En.book Page 16 Monday, April 7, 2008 2:03 PM Connecting the Speakers Enjoying Home Theater Thanks to the HTX-22HD’s superb capabilities, you can enjoy surround sound with a real sense of movement in your own home—just like being in a movie theater or concert hall. You can enjoy DVDs featuring Dolby Digital or DTS. With analog or digital TV, you can enjoy Dolby Pro Logic IIx, DTS Neo:6, or Onkyo’s original DSP listening modes. Speaker positions for a 7.1-channel system are shown below.
HTX-22HD_En.book Page 17 Monday, April 7, 2008 2:03 PM Connecting the Speakers—Continued Affixing the Cork Spacers You can improve the sound quality by affixing the included cork spacers to raise the speakers off the mounting surface thereby reducing the contact area. The spacers also make the speakers stable and prevent them from moving around.
HTX-22HD_En.book Page 18 Monday, April 7, 2008 2:03 PM Connecting the Speakers—Continued Speaker Connection Precautions Read the following before connecting your speakers: • Disconnect the power cord from the wall outlet before making any connections. • Connect only speakers with an impedance of 6 ohms or higher. • Read the instructions supplied with your speakers. • Pay close attention to speaker wiring polarity.
HTX-22HD_En.book Page 19 Monday, April 7, 2008 2:03 PM Connecting the Speakers—Continued Connecting only the Front Speakers The following hookup diagram shows how to connect the included front speakers for 2.1-channel operation. Front right speaker Red terminal Front left speaker Red line White line Red line White terminal White line Supplied speaker cable Supplied speaker cable Connecting 5.
HTX-22HD_En.book Page 20 Monday, April 7, 2008 2:03 PM Connecting the Speakers—Continued Connecting Surround Back Speakers For 7.1-channel surround sound, in addition to the 5.1 speakers shown in the hookup diagram on page 19, you’ll need a pair of surround back speakers and a power amp to drive them. Using an RCA audio cable, connect the HTX-22HD’s SURROUND BACK PRE OUT jacks to the audio input on the power amp, as shown below.
HTX-22HD_En.book Page 21 Monday, April 7, 2008 2:03 PM Connecting AV Components About AV Connections • Before making any AV connections, read the manuals supplied with your other AV components. • Don’t connect the power cord until you’ve completed and double-checked all AV connections. Optical Digital Jacks The HTX-22HD’s optical digital jacks have shutter-type covers that open when an optical plug is inserted and close when it’s removed. Push plugs in all the way.
HTX-22HD_En.book Page 22 Monday, April 7, 2008 2:03 PM Connecting AV Components—Continued Connecting Components with Digital Outputs You can connect components with digital audio outputs to the HTX-22HD’s COAXIAL IN, OPTICAL IN 1, and IN 2 inputs. Choose a digital input (coaxial or optical) that matches the digital audio output on your source component. To enjoy Dolby Digital and DTS, you must connect your DVD player with an optical or coaxial digital audio cable.
HTX-22HD_En.book Page 23 Monday, April 7, 2008 2:03 PM Connecting AV Components—Continued Connecting Components with Analog Outputs You can connect components with analog audio outputs to the HTX-22HD’s LINE 1 and LINE 2 inputs and enjoy surround sound with Dolby Pro Logic IIx, DTS Neo:6, and Onkyo’s original DSP listening modes. Notes: • After you connect a component to an input jack, you must assign that input jack to an input selector. See “Audio Input Setup” on page 36.
HTX-22HD_En.book Page 24 Monday, April 7, 2008 2:03 PM Connecting AV Components—Continued Connecting Components with HDMI About HDMI Designed to meet the increased demands of digital TV, HDMI (High Definition Multimedia Interface) is a new digital interface standard for connecting TVs, projectors, DVD players, settop boxes, and other video components. Until now, several separate video and audio cables have been required to connect AV components.
HTX-22HD_En.book Page 25 Monday, April 7, 2008 2:03 PM Connecting AV Components—Continued Making HDMI Connections You can connect components with HDMI outputs to the HTX-22HD’s HDMI IN 1 and IN 2 inputs and connect your HDMI TV to the HTX-22HD’s HDMI OUT. You need HDMI cables to make HDMI connections. Note: • By default, the HDMI1 and HDMI2 inputs are assigned to the VCR/DVR and CBL/SAT input selectors. To change these assignments, see “HDMI Input Setup” on page 37.
HTX-22HD_En.book Page 26 Monday, April 7, 2008 2:03 PM Connecting AV Components—Continued Connecting Onkyo Components Connecting an Onkyo DVD player or RI Dock with iPod to the HTX-22HD with an and RCA audio cable will alow you to use the following system control functions. An is a special cable for use with Onkyo’s (Remote Interactive) control system.
HTX-22HD_En.book Page 27 Monday, April 7, 2008 2:03 PM Connecting AV Components—Continued • To use functionality with your Onkyo MiniDisc recorder, CD recorder, or RI Dock, connect it to the LINE 1 or LINE 2 input, and assign that input to the TAPE input selector. Then, change the Input Display to MD, CDR, or DOCK as appropriate (see page 38). • Use only cables for connections. cables are supplied with Onkyo players (DVD, CD, etc.). • Some components have two jacks.
HTX-22HD_En.book Page 28 Monday, April 7, 2008 2:03 PM Connecting AV Components—Continued Controlling an Onkyo DVD Player The following buttons can be used to control an Onkyo DVD player that’s connected with . See page 26 for hookup and setting information. F Pause [ ] button Pauses playback. G Next [ ] button Selects the next chapter. H Previous [ ] button Restarts the current chapter. Press it twice to select the previous chapter. 1 K L 2 3 ] button Press and hold to rewind.
HTX-22HD_En.book Page 29 Monday, April 7, 2008 2:03 PM Connecting AV Components—Continued Controlling an RI Dock (iPod) The following buttons can be used to control an Onkyo RI Dock with iPod that’s connected with . See page 26 for hookup and setting information. D Previous [ ] button Restarts the current song. Press it twice to select the previous song. E Fast Forward [ ] button Press and hold to fast forward. F Rewind [ ] button Press and hold to rewind.
HTX-22HD_En.book Page 30 Monday, April 7, 2008 2:03 PM Turning On the HTX-22HD Connecting the Power Cord Power cord varies from country to country To wall outlet Supplied power cord Before connecting the power cord, connect all of your speakers and other components. 1 2 Connect the supplied power cord to the HTX-22HD’s AC INLET. Plug the other end of the power cord into a suitable wall outlet. The STANDBY indicator lights up.
HTX-22HD_En.book Page 31 Monday, April 7, 2008 2:03 PM Turning On the HTX-22HD—Continued Turning On and Standby STANDBY indicator ON/STANDBY ON/STANDBY Remote controller HTX-22HD On the HTX-22HD, press the [ON/STANDBY] button. On the remote controller, press the [ON/STANDBY] button. or The HTX-22HD comes on, the display lights up, and the STANDBY indicator goes off. To turn off the HTX-22HD, press the [ON/STANDBY] button, or press the remote controller’s [ON/STANDBY] button.
HTX-22HD_En.book Page 32 Monday, April 7, 2008 2:03 PM First Time Setup This section explains the settings that you need to make before using the HTX-22HD for the very first time. Automatic Speaker Setup (Audyssey 2EQ) With the supplied calibrated microphone, Audyssey 2EQ automatically determines the number of speakers connected, their size for purposes of bass management, optimum crossover frequencies to the subwoofer (if present), and distances from the primary listening position.
HTX-22HD_En.book Page 33 Monday, April 7, 2008 2:03 PM First Time Setup—Continued Using Audyssey 2EQ 1 2, 6 1 3–5 Notes: • If the HTX-22HD is muted, it will be unmuted automatically when the automatic speaker setup starts. • It takes about 10 minutes to complete the automatic speaker setup for three positions. Total measurement time varies depending on the speakers. • Do not connect or disconnect any speakers during the automatic speaker setup. 1 Turn on the HTX-22HD.
HTX-22HD_En.book Page 34 Monday, April 7, 2008 2:03 PM First Time Setup—Continued 3 Press [ENTER]. 5 Once you’ve pressed [ENTER], stand by a wall or in a corner so that your body doesn’t interfere with the test signals. The automatic speaker setup starts. You can cancel the automatic speaker setup at any point in this procedure simply by disconnecting the setup microphone. A test tone is output by each speaker in turn, as the Audyssey 2EQ function determines which speakers are connected.
HTX-22HD_En.book Page 35 Monday, April 7, 2008 2:03 PM First Time Setup—Continued Error Messages While the automatic speaker setup is in progress, one of the following error messages may appear: ❑ Ambient noise is too high ❑ Write Error This message appears if saving fails. To Retry the Automatic Speaker Setup This message appears if there’s too much background noise and the measurements cannot be performed properly. Remove the source of the noise and try again.
HTX-22HD_En.book Page 36 Monday, April 7, 2008 2:03 PM First Time Setup—Continued Audio Input Setup 2 Use the Up and Down [ ]/[ buttons to select “1.Input Assign,” and then press [ENTER]. 3 Use the Up and Down [ ]/[ ] buttons to select “Audio Input,” and then press [ENTER].
HTX-22HD_En.book Page 37 Monday, April 7, 2008 2:03 PM First Time Setup—Continued 5 Press the [SETUP] button. Setup closes. Notes: • When an HDMI IN is assigned to an input selector in “HDMI Input Setup” on page 37, this input assignment is automatically set to the same HDMI IN, and in addition to the COAX, OPT1, OPT2, etc., inputs here, you will also be able to select the HDMI inputs. • To enjoy Dolby Digital and DTS, you must connect your DVD player with a digital audio connection.
HTX-22HD_En.book Page 38 Monday, April 7, 2008 2:03 PM First Time Setup—Continued 4 Use the Up and Down [ ]/[ ] buttons to select an input selector, and use the Left and Right [ ]/[ ] buttons to select: Changing the Input Display If you connect an -capable Onkyo MiniDisc recorder, CD recorder, or RI Dock to the HTX-22HD’s LINE 1 or LINE 2 input, for to work properly, you must change this setting. HDMI1:Select if the component is connected to HDMI IN 1.
HTX-22HD_En.book Page 39 Monday, April 7, 2008 2:03 PM Playing Your Components Basic HTX-22HD Operation 3 1 3 1 1 HTX-22HD Press the HTX-22HD’s [INPUT] button repeatedly to select an input source. To select an input source with the remote controller, use its [INPUT SELECTOR] buttons. Remote controller Depending on which input selectors you have assigned to input jacks (page 36), you can select the following input selectors: DVD, VCR/DVR, CBL/SAT, GAME/TV, TAPE, TUNER, CD.
HTX-22HD_En.book Page 40 Monday, April 7, 2008 2:03 PM Playing Your Components—Continued Using the Sleep Timer DIMMER SLEEP MUTING Setting the Display Brightness You can adjust the brightness of the display. Press the remote controller’s [DIMMER] button repeatedly to select dim, dimmer, or normal brightness. Muting the HTX-22HD You can temporarily mute the output of the HTX-22HD. Press the remote controller’s [MUTING] button. The output is muted and the MUTING indicator flashes on the display.
HTX-22HD_En.book Page 41 Monday, April 7, 2008 2:03 PM Playing Your Components—Continued DISPLAY Displaying Source Information You can display various information about the current input source as follows. Press the remote controller’s [DISPLAY] button repeatedly to cycle through the available information.
HTX-22HD_En.book Page 42 Monday, April 7, 2008 2:03 PM Using the Listening Modes Selecting the Listening Modes For a description of each listening mode, see “About the Listening Modes” on page 49. • The Dolby Digital and DTS listening modes can only be selected if your DVD player is connected to the HTX-22HD with a digital audio connection (coaxial, optical, or HDMI). • The listening modes that you can select depends on the format of the input signal.
HTX-22HD_En.book Page 43 Monday, April 7, 2008 2:03 PM Using the Listening Modes—Continued Listening Modes Available for Each Source Format Analog and PCM Sources PCM Source format 32–96 kHz*1 176.4/ 192 kHz*2 Multi channel Analog Multichannel PCM 32–96 kHz*1 176.
HTX-22HD_En.book Page 44 Monday, April 7, 2008 2:03 PM Using the Listening Modes—Continued Dolby Digital and Dolby Digital Plus Sources Dolby Digital Source format Multichannel 2ch Dolby Digital Plus Mono/ Multiplex Multichannel 2ch Mono/ Multiplex Media DVD, DTV, etc.
HTX-22HD_En.book Page 45 Monday, April 7, 2008 2:03 PM Using the Listening Modes—Continued DTS Sources DTS, DTS 96/24 Source format Multichannel 2ch Mono DTS Discrete/Matrix Media DVD, CD, etc. DVD, CD, etc.
HTX-22HD_En.
HTX-22HD_En.
HTX-22HD_En.book Page 48 Monday, April 7, 2008 2:03 PM Using the Listening Modes—Continued DTS Express and DSD Sources DTS Express Source format Multichannel 2ch Mono DSD*1 Multichannel (5.
HTX-22HD_En.book Page 49 Monday, April 7, 2008 2:03 PM Using the Listening Modes—Continued About the Listening Modes The HTX-22HD’s listening modes can transform your listening room into a movie theater or concert hall, with high fidelity and stunning surround sound. This illustration shows which speakers are active in each listening mode with 7.1-channel speakers.
HTX-22HD_En.book Page 50 Monday, April 7, 2008 2:03 PM Using the Listening Modes—Continued Dolby Digital Plus DTS Neo:6 Developed for use with HDTV, including the new video disc formats Blu-ray and HD DVD, this is the latest multichannel audio format from Dolby. It supports up to 7.1 channels with 48 kHz sampling rate. This mode expands any 2-channel source for 7.1-channel playback.
HTX-22HD_En.book Page 51 Monday, April 7, 2008 2:03 PM Using the Listening Modes—Continued Multich Full Mono This mode is for use with HDMI multichannel sources. In this mode, all speakers output the same sound in mono, so the sound you hear is the same regardless of where you are within the listening room. DSD DSD stands for Direct Stream Digital and is the format used to store digital audio on Super Audio CDs (SACD). This mode can be used with SACDs that feature multichannel audio.
HTX-22HD_En.book Page 52 Monday, April 7, 2008 2:03 PM Using the Listening Modes—Continued 4 SETUP Use the Up and Down [ ]/[ ] buttons to select an option, and use the Left and Right [ ]/[ ] buttons to change it. The Audio Adjust menu items are explained below. ENTER Using the Audio Adjust Settings 5 With the Audio Adjust settings, you can adjust the sound and listening modes as you like. 1 When you’ve finished, press the [SETUP] button. Setup closes. Press the [SETUP] button.
HTX-22HD_En.book Page 53 Monday, April 7, 2008 2:03 PM Using the Listening Modes—Continued PLIIx/Neo:6 Neo:6 Music PLIIx Music (2 ch Input) ■ Center Image These settings apply to only 2-channel stereo sources. If you’re not using any surround back speakers, these settings apply to Dolby Pro Logic II, not Dolby Pro Logic IIx. The DTS Neo:6 Music listening mode creates 6-channel surround sound from 2-channel stereo sources.
HTX-22HD_En.book Page 54 Monday, April 7, 2008 2:03 PM Using the Listening Modes—Continued T-D (Theater-Dimensional) Dynamic EQ ■ LstnAngl (Listening Angle) ■ Dynamic EQ With this setting, you can optimize the Theater-Dimensional listening mode by specifying the angle of the front left and right speakers relative to your listening position. Ideally, the front left and right speakers should be equidistant from your listening position and at an angle close to one of the two available settings.
HTX-22HD_En.book Page 55 Monday, April 7, 2008 2:03 PM Using the Listening Modes—Continued CH SEL L NIGHT • The effect of the Late Night function depends on the material that you are playing and the intention of the original sound designer, and with some material there will be little or no effect when you select the different options. • The Late Night function is set to Off when the HTX-22HD is set to Standby.
HTX-22HD_En.book Page 56 Monday, April 7, 2008 2:03 PM Advanced Setup Manual Speaker Setup This section explains how to set the speaker settings manually. This can be useful for checking the speaker setting or making changes if you add additional speakers to your system after running the automatic speaker setup. Some of the speaker settings are set automatically by the Automatic Speaker Setup function (see page 32). 1 Press the [SETUP] button. 2 Use the Up and Down [ ]/[ ] buttons to select “2.
HTX-22HD_En.book Page 57 Monday, April 7, 2008 2:03 PM Advanced Setup—Continued 5 Press the Down [ ] button to select “Cntr” (Center), and then use the Left and Right [ ]/[ ] buttons to select: 7 Small: Select if the center speaker is small. Large: Select if the center speaker is large. None: Select if no center speaker is connected. Note: • If the Front setting in step 4 is set to Small, the Large option cannot be selected. 6 Small: Select if the surround back speakers are small.
HTX-22HD_En.book Page 58 Monday, April 7, 2008 2:03 PM Advanced Setup—Continued Speaker cone diameter SETUP ENTER Crossover Frequency This setting is set automatically by the Automatic Speaker Setup function (see page 32). This setting only applies to the speakers that you specified as Small in the “Speaker Configuration” on page 56.
HTX-22HD_En.book Page 59 Monday, April 7, 2008 2:03 PM Advanced Setup—Continued Double Bass Speaker Distances This setting is not set automatically by the Automatic Speaker Setup function (see page 32). These settings are set automatically by the Automatic Speaker Setup function (see page 32). With the Double Bass function, you can boost bass output by feeding bass sounds from the front left, right, and center channels to the subwoofer.
HTX-22HD_En.book Page 60 Monday, April 7, 2008 2:03 PM Advanced Setup—Continued 5 While “Unit” is displayed, use the Left and Right [ ]/[ ] buttons to select “feet” or “meters,” and then press [ENTER]. feet: Distances can be set in feet. Range: 1 to 30 feet in 1-foot steps. meters:Distances can be set in meters. Range: 0.3 to 9 meters in 0.3-meter steps.
HTX-22HD_En.book Page 61 Monday, April 7, 2008 2:03 PM Advanced Setup—Continued 2 3 Surr BkL: Surround back left speaker. Surr L: Surround left speaker. Subwfr: This subwoofer. Use the Up and Down [ ]/[ ] buttons to select “2. Speaker Setup,” and then press [ENTER]. Notes: • Speakers that you set to No or None in the “Speaker Configuration” on page 56 cannot be selected.
HTX-22HD_En.book Page 62 Monday, April 7, 2008 2:03 PM Advanced Setup—Continued 4 ENTER Equalizer Settings These settings are set automatically by the Automatic Speaker Setup function (see page 32). With the Equalizer settings, you can adjust the tone of each speaker. 62 Press the [SETUP] button. 2 Use the Up and Down [ ]/[ ] buttons to select “2. Speaker Setup,” and then press [ENTER]. 3 Use the Up and Down [ ]/[ ] buttons to select “Equalizer,” and then press [ENTER].
HTX-22HD_En.book Page 63 Monday, April 7, 2008 2:03 PM Advanced Setup—Continued 6 Use the Up and Down [ ]/[ ] buttons to select a frequency. Use the Left and Right [ ]/[ ] buttons to adjust the level at that frequency. The volume at each frequency can be adjusted from –6 to +6 dB in 1 dB steps. Tip: Low frequencies (e.g., 63Hz) affect bass sounds; high frequencies (e.g., 16000Hz) affect treble sounds.
HTX-22HD_En.book Page 64 Monday, April 7, 2008 2:03 PM Advanced Setup—Continued Source Setup 3 Use the Up and Down [ ]/[ ] buttons to select an item, and then press [ENTER]. 4 Use the Left and Right [ buttons to change it. This section explains items on the Source Setup menu. Items can be set individually for each input selector. SETUP ]/[ ] The Source Setup menu items are explained below. ENTER INPUT SELECTOR 5 When you’ve finished, press the [SETUP] button. Setup closes.
HTX-22HD_En.book Page 65 Monday, April 7, 2008 2:03 PM Advanced Setup—Continued A/V Sync Name Edit When using your DVD player’s progressive scanning function, you may find that the picture and sound are out of sync. With the A/V Sync setting, you can correct this by applying a delay to the audio signal. The delay can be set from 0 to 100 milliseconds (msec) in 10 millisecond steps. Use the Left and Right [ ]/[ ] buttons to set the delay. To view the TV picture while setting the delay, press [ENTER].
HTX-22HD_En.book Page 66 Monday, April 7, 2008 2:03 PM Advanced Setup—Continued 6 Repeat step 5 to enter up to 10 characters. To move the cursor to the left or right, press the Left or Right [ ]/[ ] button respectively. To delete the character at the current cursor position, press the [MUTING] button. The character will be deleted and any characters to the right of it will be moved one place to the left.
HTX-22HD_En.book Page 67 Monday, April 7, 2008 2:03 PM Advanced Setup—Continued 4 Use the Up and Down [ ]/[ ] buttons to select an item, and use the Left and Right [ ]/[ ] buttons to change it. The items are explained below. 5 HDMI Setup This section explains items on the HDMI Setup menu. 1 Press the [SETUP] button. 2 Use the Up and Down [ ]/[ buttons to select “6. HDMI Setup,” and then press [ENTER]. 3 Use the Up and Down [ ]/[ ] buttons to select an item, and then press [ENTER].
HTX-22HD_En.book Page 68 Monday, April 7, 2008 2:03 PM Advanced Setup—Continued Audio TV Out Lip Sync This setting determines whether audio received by an HDMI input is output by the HDMI OUT. You may want to change this setting to On if your TV is connected to the HDMI OUT and you want to listen to audio from an HDMI component through your TV’s speakers instead of the HTX-22HD’s speakers. Normally, this should be set to Off. Off: HDMI audio is not output (default). On: HDMI audio is output.
HTX-22HD_En.book Page 69 Monday, April 7, 2008 2:03 PM Advanced Setup—Continued • Select Disable if a connected component is incompatible or you’re not sure about its compatibility. • If operation is unreliable when set to Enable, select Disable instead. • When the Audio TV Out setting is set to On, or TV Control is set to Enable and you’re listening through your TV’s speakers (see page 24), if you turn up the HTX22HD’s volume control, the sound will be output by the HTX-22HD’s speakers.
HTX-22HD_En.book Page 70 Monday, April 7, 2008 2:03 PM Advanced Setup—Continued 3 SETUP ENTER Specifying the Digital Signal Format Normally, the HTX-22HD detects the format of digital input signals automatically. However, if you experience either of the following issues when playing PCM or DTS sources, you can specify the signal format manually. • If the beginnings of tracks from a PCM source are cut off, try the PCM setting.
HTX-22HD_En.book Page 71 Monday, April 7, 2008 2:03 PM Troubleshooting If you have any trouble using the HTX22HD, look for a solution in this section. If you can’t resolve the issue yourself, contact your Onkyo dealer. Before you contact your Onkyo dealer, try resetting the HTX-22HD, as follows: To reset the HTX-22HD to its factory defaults, turn it on and, while holding down the [LISTENING MODE] button, press the [ON/STANDBY] button.
HTX-22HD_En.book Page 72 Monday, April 7, 2008 2:03 PM Troubleshooting—Continued The surround back speakers produce no sound • The surround back speakers are not used with all listening modes. Try another listening mode (page 42). • Not much sound may be produced by the surround back speakers with some sources. • Check the Speaker Configuration (page 56). The subwoofer produces no sound • If the source material contains no audio in the LFE channel, the subwoofer produces no sound.
HTX-22HD_En.book Page 73 Monday, April 7, 2008 2:03 PM Troubleshooting—Continued The HTX-22HD contains a microcomputer for signal processing and control functions. In very rare situations, severe interference, noise from an external source, or static electricity may cause it to lockup. In the unlikely event that this happens, unplug the power cord from the wall outlet, wait at least 5 seconds, and then plug it back in again.
HTX-22HD_En.
HTX-22HD_En.
HTX-22HD_En.book Page 76 Monday, April 7, 2008 2:03 PM Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN Tel: 072-831-8023 Fax: 072-831-8163 ONKYO U.S.A. CORPORATION 18 Park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 201-785-2600 Fax: 201-785-2650 http://www.us.onkyo.com/ ONKYO EUROPE ELECTRONICS GmbH Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY Tel: +49-8142-4401-0 Fax: +49-8142-4401-555 http://www.eu.onkyo.
