13
Getting to Know the HTX-22HD
—Continued
F
AC INLET
The supplied power cord is connected
here. The other end of the power cord
should be connected to a suitable wall
outlet.
G
FRONT SPEAKERS, CENTER
SPEAKER, and SURROUND
SPEAKERS
These push terminals are for connecting
the included front speakers and the
optional SKS-11 center speaker and sur-
round speakers.
H
Cooling fan
This cooling fan operates when the inter-
nal temperature of the HTX-22HD
reaches a certain level.
I
SURROUND BACK PRE OUT
This analog audio output can be con-
nected to another power amplifier and
surround back speakers for 7.1-channel
surround sound.
J
LINE 1 and LINE 2 INPUT
These analog audio inputs are for con-
necting components with an analog audio
output, such as a VCR, TV, or Onkyo RI
Dock.
See pages 16–26 for hookup information.
