Connecting the Speakers
—Continued
You can improve the sound quality by affixing the included cork spacers to raise the speakers
off the mounting surface thereby reducing the contact area. The spacers also make the speakers
stable and prevent them from moving around.
■
Cork Spacers for the Amp/Subwoofer
■
Cork Spacers for the Front Speakers
Note:
• Before you wall-mount the front speakers, check the strength of the wall. The supporting
strength of the screws depends on the wall material and the position of the studs. Use screws
as thick and long as possible, with a head diameter of 10 mm or less and a thread diameter of
4 mm or less. (We recommend that you consult a professional home electronics installer.)
Affixing the Cork Spacers
HTX-22HDPAW
Cork spacer
Bottom
Side
Cork spacer
HTX-22HDST
bottom
HTX-22HDST top
Keyhole mounting slot
If you intend to wall-mount the front speakers using
their keyhole slots, affix two cork spacers to the rear of
each speaker for a added stability.
Cork spacer
