Specifications
Subwoofer system with built-in amplifier (HTX-22HDPAW)
■ Digital Audio Inputs/Outputs
■ Analog Audio Inputs/Outputs
Front Speaker (HTX-22HDST)
Specifications and features are subject to change without notice.
Type: Bass-reflex with built-in amplifier
Rated Output Power (IEC): 5 ch (FL/FR/C/SL/SR)
×
25 W at 6 ohms, 1 kHz, 1ch driven, THD 1%
1 ch (SW)
×
50 W at 3 ohms, 100 Hz, 1ch driven, THD 1%
Subwoofer Frequency Response: 35 Hz–200 Hz
Amp Frequency Response: FL/FR: 10 Hz–100 kHz (Direct mode)
FL/FR/C/SL/SR: 150 Hz–20 kHz, +1 dB–3dB
SW: 20 Hz–150 Hz, +1 dB–3dB (Crossover at 150 Hz)
Input Sensitivity and Impedance: 150 mV/ 47 k Ω (FL/FR)
Signal to Noise Ratio: 105 dB (LINE1/LINE2, Direct mode, IHF-A)
Cabinet capacity: 7 L
Power Supply: AC 230 V, 50 Hz
Power Consumption: 130 W
Dimensions (W × H × D): 207 × 325 × 327 mm (incl. grille and projection)
Weight: 10.6 kg
Drivers unit: 16 cm A-OMF cone
Other: Magnetic shielding
Inputs: 3 (OPT1, OPT2, Coaxial)
Video/Audio inputs: 2 (HDMI1, HDMI2)
Video/Audio output: 1 (HDMI)
Inputs: 2 (LINE1, LINE2)
Output: 1 (PREOUT SBL/SBR)
Type: 2 Way
Input Sensitivity/Impedance: 6 Ω
Maximum input power: 40 W
Output sound pressure level: 80 dB/W/m
Frequency response: 70 Hz–50 kHz
Crossover frequency: 9 kHz
Cabinet capacity: 1.1 L
Dimensions (W × H × D): 101 × 175 × 111 mm (incl. grille and projection)
Weight: 0.8 kg
Drivers unit: 8 cm A-OMF cone woofer
2 cm balanced-dome tweeter
Terminal: Spring type
Other: Magnetic shielding
