Brunel V1.0 - Datasheet

March 2017

1www.openbionics.comAuthor: M Simons

Humanoid Robotic Hand

Features

Lightweight - ideal for low-payload robot arms

Mechanically compliant features - robust and shock resistant

High-grip pads on the palm and fingers

9 degrees of freedom (underactuated)

4 degrees of actuation

Current feedback on motors to determine grip strength

ROS compatible

Arduino IDE compatible

Fully open source hardware and software

Fully controllable RGB status LED

9 axis IMU

USB programmable

Removable wrist connector

Key specifications

Mass: 371 g

Major dimensions: 198 x 127 x 66 mm

Operating voltage: 6-12V

Materials: PLA plastic, TPU and urethane

Description

The Brunel Hand is the second robotic hand released by Open

Bionics after the Ada Hand. Key improvements include

integrated finger friction pads, a more stable pinch grip, and a

revised custom control printed circuit board. The Chestnut

V1.0 (PCB) is based around the SAMD21G18 microcontroller

with I

C connectivity plus breakout pins. The hand is CE

marked and comes pre-assembled, so there is no need to

waste any time before getting started.

This is not a medical device.

Summary of content (7 pages)

PAGE 1
Brunel V1.0 - Datasheet March 2017 Humanoid Robotic Hand Description The Brunel Hand is the second robotic hand released by Open Bionics after the Ada Hand. Key improvements include integrated finger friction pads, a more stable pinch grip, and a revised custom control printed circuit board. The Chestnut V1.0 (PCB) is based around the SAMD21G18 microcontroller with I2C connectivity plus breakout pins.
PAGE 2
Brunel V1.0 - Datasheet March 2017 Applications Perfect for the scientist, researcher, roboticist, educator or hobbyist. The Brunel Hand is ideal for dexterous manipulation tasks, as well as robot - human interaction studies. Components The design files (.blend), print files (.stl), and other documentation for the components that make up the Brunel Hand can be found online at: www.openbionics.com/downloads or www.github.
PAGE 3
Brunel V1.0 - Datasheet March 2017 License This work is licensed under the Creative Commons AttributionShareAlike 4.0 International License. To view a copy of this license, visit: http://creativecommons.org/licenses/by-sa/4.0/ You are free to copy and redistribute the material in any medium or format. You may remix, transform, and build upon the materialcially. Attribution — You must give appropriate credit to Open Bionics, provide a link to the license, and indicate if changes were made.
PAGE 4
Brunel V1.0 - Datasheet March 2017 Fist Grip Palm Grip Handle: Tested up to 5.0 kg payload Bulk object: 2.2 kg payload Tested up to 8.0 kg payload (holds comfortably) Tripod Grip Pinch Grip Bulk object: 2.0 kg payload Small object: 0.4 kg payload Bulk object: 1.0 kg payload Small object: 0.1 kg payload Point Gesture Payloads are approximate Bulk object taken as Ø93 mm Author: M Simons www.openbionics.
PAGE 5
Brunel V1.0 - Datasheet March 2017 Wrist Interface All units in mm Drawing not to scale Printed parts subject to 0.5 mm tolerance Wrist connector depth: 15 mm 2 mm bolts present on each wrist connector face Author: M Simons www.openbionics.
PAGE 6
Brunel V1.0 - Datasheet March 2017 Wrist Cabling Drawing not to scale Printed parts subject to 0.5 mm tolerance All units in mm Cabling entry depth: 6.3 mm Author: M Simons www.openbionics.
PAGE 7
Brunel V1.0 - Datasheet March 2017 Dedication Isambard Kingdom Brunel (1806-1859) revolutionised public transport and modern engineering. No dream was too big. Dionysium Lardner, a celebrated academic, on Brunel's plan to cross the Atlantic Ocean with a coal powered ship: "As the project of making the voyage directly from Liverpool to New York [...] they might as well talk of making the voyage from New York to the moon...
