Wireless Thermo-Hygro Clock Model : RMR616HGA User Manual RMR616HGA lab test cover R2 1 1/8/04, 7:05 PM
View Alarm Settings ............................................... 9 Contents ................................................................... 1 Set Alarm ............................................................... 9 Introduction .............................................................. 2 Activate Alarm ...................................................... 10 About Oregon Scientific .......................................... 2 Silence Alarm ...............................................
EN INTRODUCTION ABOUT OREGON SCIENTIFIC Thank you for selecting the Oregon ScientificTM Wireless Thermo-Hygro Clock (RMR616HGA). This device bundles precise time keeping, dual alarm, and temperature and humidity monitoring features into a single tool you can use from the convenience of your home. Visit our website (www.oregonscientific.com) to learn more about other Oregon Scientific products such as digital cameras, hand-held organizers, health and fitness gear, and projection clocks.
EN PRODUCT OVERVIEW FRONT VIEW 1. ALARM button: view alarm status; set alarm 1 4 2. UP button: increase setting /activate radiocontrolled clock /activate or deactivate alarm 2 5 3. DOWN button: decrease setting /deactivate radiocontrolled clock /activate or deactivate alarm 3 6 4. MODE button: change display / settings 5. CHANNEL button: switch remote sensor 6. MEM button: view current,maximum and minimum temperature /humidity readings 7.
EN BACK VIEW 1 1. 2 2. RESET hole °C / °F switch 3. Battery compartment 4.
EN REMOTE SENSOR (THGR122NX) 1 1 2 2 3 4 1. LCD display 1. 2. LED Status indicator 2. Wall mount hole RESET 3. Channel number (1 - 3) 4.
EN CHANGE SETTINGS GETTING STARTED BATTERIES Batteries are not supplied with this product. You will need to purchase 2 x UM-3 (AA) 1.5V alkaline batteries for the main unit, and 2 x UM-4 (AAA) 1.5V alkaline batteries for the remote sensor. 1. Press and hold MODE for 2 seconds to enter setting mode. 2. Press UP or DOWN to change settings. 3. Press MODE to confirm. REMOTE SENSOR (THGR122NX) Insert batteries before first use, matching the polarity as shown in the battery compartment.
Insert the batteries, matching the polarity as shown in the battery compartment. 2. Set the channel. The switch is located in the battery compartment. For best results: • Insert the batteries and select the channel and temperature unit before you mount the sensor. SWITCH OPTION • Place the sensor out of direct sunlight and moisture. Channel Channel 1 - 3. If you are using more than one sensor, select a different channel for each sensor.
EN ICON --- shows in Temp / Humidity Areas DESCRIPTION CLOCK Main unit is searching for sensors. At least 1 channel has been found. Channel 1 is selected (number will change depending on the sensor you select) This product can track the date and time for up to 2 locations (Clock with Offset Hour). The US Atomic Clock in Boulder, Colorado automatically updates this information unless you disable the feature. The signals are collected by the main unit when it is within 1500 km (932 miles) of a signal.
SWITCH CLOCK DISPLAY Perform this step if you cannot receive Atomic Clock signals. Press and hold DOWN for 2 seconds. Then, manually set the clock following the "Set Clock" instructions (below). Press MODE to toggle between Clock with Seconds, Clock with Weekday and Calendar, and Clock with Offset Hour display. The signal icon indicates that the Atomic Clock feature is ON. No icon means that it is OFF.
EN ACTIVATE ALARM TEMPERATURE AND HUMIDITY Press ALARM to switch to Weekday or Single Alarm view. To activate or deactivate the alarm, press UP or DOWN. This product can display current, minimum, and maximum temperatures and humidity percentage information collected by the remote sensors. • Alarm deactivated: --:-- Data is collected and displayed every 40 seconds. • Alarm activated: Alarm time is shown SELECT TEMPERATURE UNIT The bell icons mode selected.
NOTE When you press RESET, all settings will return to default value, and you will lose all stored information. SAFETY AND CARE NOTE If you use a sensor that collects only temperature data, humidity will not be shown. Clean the product with a slightly damp cloth and alcoholfree mild detergent. Avoid dropping the product or placing it in a high-traffic location. MINIMUM / MAXIMUM RECORDS WARNINGS Press MEM to toggle between current, maximum (MAX) and minimum (MIN) records for the selected sensor.
EN Do not make any changes or modifications to this product. Unauthorized changes may void your right to use the product. The technical specification of this product and contents of this user guide are subject to change without notice. Images not drawn to scale. Problem Symptom Remedy Remote sensor Cannot locate remote sensor Cannot change channel Check batteries ( TROUBLESHOOTING Check here before contacting our customer service department.
Outdoor Range Resolution RELATIVE HUMIDITY Range Resolution Alarm °C or °F -5 °C to 50 °C (23 °F to 122 °F) -20 °C to 60 °C (-4 °F to 140 °F) 0.1 °C (0.2 °F) Weekday and Single Alarm; 2- minute crescendo POWER Main unit batteries 2 x UM-3 (AA) 1.5V alkaline Sensor batteries 2 x UM-4 (AAA) 1.5V alkaline 25% to 95% 1% FCC STATEMENT REMOTE SENSOR (THGR122NX) RF frequency 433 MHz Range This device complies with Part 15 of the FCC Rules.
EN DECLARATION OF CONFORMITY The information below is not to be used as contact for support or sales. Please call our customer service number (listed on our website at www.oregonscientific.com, or on the warranty card for this product) for all inquiries instead. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
© 2004 Oregon Scientific. All rights reserved. P/N.
