Specifications

Project Name
Fixture Type Quantity
Product Name / Model / Dimensions
Finish
Options
Standard
Brushed Aluminum / BA
Gloss White / GW
Standard
Matte Opal
Acrylic / MA
Standard
LED / LED
SKU Height Projection*
24" 3.25"
36" 3.25"
48" 3.25"
60" 3.25"
34 2560 lumens, 3000K, 85 CRI, 0-10VDC dimming
41 3180 lumens, 3000K, 85 CRI, 0-10VDC dimming
Backplate 24" 4.50" H x 4.50" W
Backplate 36", 48" and 60", 7.00" H x 4.50" W
* Product projection with backplate / BK
Product width .75" no backplate / NBK
Product width with backplate 4.50"
Backplate track allows for flexibility on where backplate is
positioned, from within 1-1/2" of either end of fixture.
1.50"
1.50"
24" no backplate*
24" backplate off center
36" no backplate*
36" backplate centered
48" no backplate*
48" backplate off center
60" no backplate*
60" backplate centered
24"
36"
48"
60"
*When product is ordered with no backplate, driver is installed into wall
24"
4.50"
3.25"
4.50"
Top view
2.00"
no backplate
3.25"
• Multiple Lenas of
any length can be joined
end to end for a
continuous row
• Lena is available with
a backplate / BK or
without backplate / NBK
0.75"
0.75"0.75"
0.75"0.75"
Product Name Sconce 24", 36", 48", 60"
24" no
backplate
24"
backplate
off center
36" no
backplate
48"
backplate
off center
60" no
backplate
Acrylic Lamping Options
Wattage Integrated LED
16 1170 lumens, 3000K, 85 CRI, 0-10VDC dimming
25 1900 lumens, 3000K, 85 CRI, 0-10VDC dimming
